Technical specifications for 6SL3040-1LA00-0AA0
-
Product Model6SL3040-1LA00-0AA0
-
Product ParametersSINAMICS S120 control unit CU310-2 DP
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size18.5x7.3x8cm
-
ManufacturerSiemens
-
Weight0.75 kg
-
Number11
-
Voltage-3 ... 30 V
-
Low level-3 ... 5 V
-
High level15 ... 30 V
-
Power consumption at 24 V DC, typ3.5 mA
-
VoltageDC 24 V
-
Voltage-10 ... 10 V
-
Encoder frequency, max300 kHz
-
SSI baudrate100 ... 1,000 kBaud
-
Operation0 ... 55 °C (32 ... 131 °F)
-
Storage-25 ... 55 °C (-13 ... 131 °F)
-
Transport-40 ... 70 °C (-40 ... 158 °F)
Description
The 6SL3040-1LA00-0AA0 is a control unit from the Siemens SINAMICS S120 drive system family, designated as the CU310-2 DP. It is a single-axis control module designed for operation connected to a Power Module in blocksize or chassis formats, implementing all open-loop and closed-loop control functions for one motor drive.
The control unit operates from a 24 V DC electronics power supply with a permissible range of 20.4 to 28.8 V DC. Current consumption is 0.8 A without DRIVE-CLiQ and digital outputs. Maximum power loss is less than 20 W. The unit is hot-pluggable and requires firmware version V4.4 or higher, stored on a separately ordered CompactFlash card (6SL3054-0EE00-1BA0).
Eleven isolated digital inputs accept -3 to +30 V DC signals with 50 µs typical delay for low-to-high transitions and 150 µs for high-to-low transitions. Eight bidirectional digital inputs/outputs are non-isolated and configurable per application. Four of these (DI/DO 12–15) are rapid inputs with 5 µs delay, usable as probe inputs or external zero mark inputs. As outputs, they provide 24 V DC at 500 mA maximum per channel with short-circuit, ground fault, and overload protection.
The control unit operates from a 24 V DC electronics power supply with a permissible range of 20.4 to 28.8 V DC. Current consumption is 0.8 A without DRIVE-CLiQ and digital outputs. Maximum power loss is less than 20 W. The unit is hot-pluggable and requires firmware version V4.4 or higher, stored on a separately ordered CompactFlash card (6SL3054-0EE00-1BA0).
Eleven isolated digital inputs accept -3 to +30 V DC signals with 50 µs typical delay for low-to-high transitions and 150 µs for high-to-low transitions. Eight bidirectional digital inputs/outputs are non-isolated and configurable per application. Four of these (DI/DO 12–15) are rapid inputs with 5 µs delay, usable as probe inputs or external zero mark inputs. As outputs, they provide 24 V DC at 500 mA maximum per channel with short-circuit, ground fault, and overload protection.
Alternative Names
6SL3040-1LA00-0AAO
6SL3040-1LA00-OAA0
6SL3040-1LA0O-0AA0
6SL3040-1LAO0-0AA0
6SL3040-ILA00-0AA0
6SL304O-1LA00-0AA0
6SL3O40-1LA00-0AA0
6SL3040 1LA00 0AA0
6SL3040 1LA00 0AAO
6SL3040 1LA00 OAA0
6SL3040 1LA0O 0AA0
6SL3040 1LAO0 0AA0
6SL3040 ILA00 0AA0
6SL304O 1LA00 0AA0
6SL3O40 1LA00 0AA0
6SL30401LA000AA0
Information
Overview
Manuals
Application Notes
Product Applications
Wiring & Connections
Features:
- SINAMICS S120 CU310-2 DP control unit
- PROFIBUS DP communication interface
- Integrated DRIVE-CLiQ connection
- 24 VDC power supply
The control unit features an integrated PROFIBUS DP interface for communication with PLCs and higher-level automation systems. A built-in DRIVE-CLiQ interface enables direct connection to compatible motors, encoder systems, and Siemens drive components, supporting automatic device identification and efficient parameter exchange throughout the drive system.
The 6SL3040-1LA00-0AA0 SIEMENS SINAMICS S120 control unit CU310-2 DP may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6SL3040-1LA00-0AA0 SINAMICS S120 control unit CU310-2 DP Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
For machine interfacing, the CU310-2 DP provides 11 digital inputs, 8 configurable digital I/O channels, and one configurable analog input supporting either voltage (±10 V) or current (±20 mA) signals. These integrated interfaces allow direct connection of sensors, switches, command signals, and process feedback devices without requiring additional interface hardware for many standard motion applications.
The onboard encoder interface supports TTL, HTL, and SSI encoder technologies with encoder frequencies up to 300 kHz and absolute encoder resolutions up to 30 bits. These capabilities provide accurate position, speed, and motion feedback for servo systems used in demanding industrial automation equipment.
- Machine Tools: Controls primary movements, feeds, and auxiliary axes in milling, turning, and cutting
- Conveyors/Handling: Coordinates single-axis transport, stop-start tracks, and sorting mechanisms
- Packaging Lines: Powers wrapping, filling, capping, and sealing axes synchronized with sensors
- Robotics/Pick-and-Place: Manages Cartesian gantries and material positioning arms
- Printing/Converting: Drives web-tensioning rolls, feed rollers, and winding axes
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Grounding (PE): Always connect the protective earth (PE) using the M5 screw located at the bottom of the unit. Use a braided shield with a maximum cross-section of 6 mm² (AWG 10) to prevent electromagnetic interference.
Electronics Power Supply: Connect a regulated 24V DC supply (tolerance: 20.4V to 28.8V) to the top 2-pin connector. The maximum conductor cross-section is 2.5 mm² (AWG 14).
Communication & Encoder: Connect your PROFIBUS cable to the designated Sub-D port and your DRIVE-CLiQ cable to the Drive-CLiQ port for communication with the Power Module and encoders
Technical notes
Communication interfaces include one PROFIBUS DP port (X21) for integration into automation networks, one RS232 serial interface (X22) for commissioning and service, one DRIVE-CLiQ interface (X100) for connection to Power Modules and motor modules, and one LAN Ethernet port (X127) with Auto MDI(X) support for web server access and engineering.
FAQs
-
What is the 6SL3040-1LA00-0AA0?
+The Siemens 6SL3040-1LA00-0AA0 is a SINAMICS S120 CU310-2 DP Control Unit designed for advanced industrial motion control applications. -
What is the primary function of this Control Unit?
+It is a processor module (CU310-2 DP) designed to handle communication, logic, and motion control (closed-loop) tasks for a single drive, commonly paired with the SINAMICS S110 or S120 drive systems. -
Does it come with a memory card?
+No, the unit is typically supplied without the necessary CompactFlash (CF) or SD memory card. The firmware and parameter configurations must be loaded using a Siemens memory card. -
What communication protocol does it use?
+It features a PROFIBUS DP interface for fast, reliable data exchange and integration with industrial networks and PLCs.
