      Siemens 6DD1606-3AC0
      Siemens 6DD1606-3AC0
      Siemens 6DD1606-3AC0
      Siemens 6DD1606-3AC0
      Siemens 6DD1606-3AC0
      Siemens 6DD1606-3AC0
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Ships by Saturday, November 14

      6DD1606-3AC0

      Mixed Signal Expansion Module

      Require for Quote:

      Shipping Information

      • For inventory products, we support same day shipping upon payment.
      • For urgent needs, we offer same-day shipping on most items for orders placed before 2:00 PM UTC+8 Simply mention your preferred next-day shipping when place the order, and your order will be prioritized to minimize downtime.
      • For indent items, typical turnaround is 1-3 weeks, depending on parts availability and scarcity.
      Customs & Documentation
      We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
      Documents checked before dispatch · Shipment details confirmed · Global tracking provided
      Payment
      Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
      Product Condition
      Factory New These are new and current items that are procured directly from the manufacturer.
      New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
      New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
      Quantity
      Mobile *
      Country/Region *
      E-mail *
      Company
      Content *
      Upload
      (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Amikong please read our privacy policy.

      • 20+

        years in automation

      • ISO 9001

        certified quality system

      • 12 months

        amikon warranty

      • 2-hour reply

        from your account manager

      • Success Story

        solutions in action
      PART NUMBER SEARCH

      Find another automation part

      • Please try to be as accurate as possible with your search.
      • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
      • We can't find any results for “”.
        SEE MORE
          SEE PRODUCTS IN SEARCH PAGE ()
          PRODUCT DESCRIPTION

          6DD1606-3AC0 Mixed Signal Expansion Module

          Siemens 6DD1606-3AC0 is the IT41 mixed-signal expansion module for compatible SIMADYN D processor arrangements. It extends the engineered control application with binary, analog and incremental-encoder connections.

          The IT41 provides sixteen binary inputs and outputs, four analog inputs and outputs, and connections for up to four incremental encoders. Its analog-input conversion is twelve-bit and analog-output conversion sixteen-bit. Encoder voltage selection, processor association and connector assignments must match the hardware manual.
          BEFORE YOU BUY

          Confirm the complete mixed signal expansion module

          Send a label photo for review >>
          ACTUAL APPLICATIONS

          Application context for 6DD1606-3AC0

          6DD1606-3AC0 is a mixed signal expansion module for SIMADYN D IT41. It supports compatible automation projects in metals production, pulp and paper, mining. Suitability depends on the configured system, connected interfaces and documented operating limits.
          • 01 · METALS PRODUCTION

            Metal Processing and Rolling Processing

            Steel Rolling Process ControlMetal Forming and Finishing
          • 02 · PULP & PAPER

            Pulp Processing and Paper Processing

            Pulp Preparation and ProcessingPaper Production and Converting
          • 03 · MINING

            Mining and Mineral Processing Processing

            Mineral Processing and BeneficiationOre Extraction and Material Handling

          Technical specifications for 6DD1606-3AC0

          • Product Model
            6DD1606-3AC0
          • Product Parameters
            Mixed Signal Expansion Module
          • In stock
            2 units
          • Manufacturer
            Siemens
          • Binary channel allocation
            16 inputs and 16 outputs
          • Analog channel allocation
            4 inputs and 4 outputs
          • Incremental encoder capacity
            4 encoders
          • Analog input range
            −10 to +10 V
          • Analog input resolution
            12 bits
          • Maximum analog conversion time
            45 µs
          • Analog input resistance
            470 kΩ
          • Input filter cutoff
            1.5 kHz at −3 dB
          • Analog output resolution
            16 bits
          • Analog output drive
            ±10 mA
          • Binary input delay
            50 µs
          • Typical binary input current
            3 mA at signal one
          • Binary output rated current
            50 mA
          • Maximum binary switching delay
            15 µs
          • Maximum encoder track frequency
            1 MHz
          View all additional
          Ask for Quote

          Alternative Names

          6DD1606-3AC0 SIMADYN D IT41 Mixed Signal Expansion Module D IT41 16 inputs and 16 outputs binary channel allocation
          SYSTEM & REPLACEMENT CHECK

          Information needed before ordering

          Three direct checks to secure your system integration and minimize ordering risks.

          Information

          System integration Replacement check Manuals & support
          SYSTEM INTEGRATION

          Integrate 6DD1606-3AC0 mixed signal expansion module

          Integrate 6DD1606-3AC0 only in the documented SIMADYN D IT41 configuration. Match the installed interfaces and the engineered application before selecting this mixed signal expansion module.
          The IT41 provides sixteen binary inputs and outputs, four analog inputs and outputs, and connections for up to four incremental encoders. Its analog-input conversion is twelve-bit and analog-output conversion sixteen-bit. Encoder voltage selection, processor association and connector assignments must match the hardware manual.
          Use the applicable controlled instructions for SIMADYN D IT41. Validate the assigned signals, communication or output behaviour and retain the accepted configuration for 6DD1606-3AC0.

          Features:

          • Binary channel allocation: 16 inputs and 16 outputs
          • Analog channel allocation: 4 inputs and 4 outputs
          • Incremental encoder capacity: 4 encoders
          The 6DD1606-3AC0 mixed signal expansion module requires appropriate configuration before system integration and commissioning.
          INTERCHANGEABILITY

          Verify 6DD1606-3AC0 mixed signal expansion module

          Confirm the complete 6DD1606-3AC0 identity and installed SIMADYN D IT41 execution before replacement. Compare the connector arrangement and the technical values required by the existing project.
          Record the mixed signal expansion module connections, project settings and associated accessories. Preserve the accepted configuration and isolate the affected circuits before exchange.
          After fitting 6DD1606-3AC0, restore the verified configuration and test every affected function. Retain the identification, diagnostic results and final acceptance record for the SIMADYN D IT41 equipment.

          Features:

          • Binary channel allocation: 16 inputs and 16 outputs
          • Analog channel allocation: 4 inputs and 4 outputs
          • Incremental encoder capacity: 4 encoders
          The 6DD1606-3AC0 mixed signal expansion module requires replacement verification against the complete installed configuration and current manufacturer documentation.
          DOCUMENTATION STATUS

          Browse the Manuals, Datasheets, Official Documents, Links

          Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.

          Features:

          • Verify document identity before procurement or installation
          • Match the complete order to the manufacturer document scope
          • Accessories are supplied only when listed in the quotation
          Documentation for the 6DD1606-3AC0 mixed signal expansion module must be checked for document applicability before installation or commissioning.

          Also searched as

          6DD1610-0AK0 6DD1610-0AG1 6DD1683-0BC0 6DD1600-0AH0 6DD1606-1AA0

          Important notice

          Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
          This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
          BUYER INFORMATION

          Commercial terms without hidden steps

          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
          • 01

            Shipping & delivery

            Dispatch
            Eligible stock: same / next day
            Carriers
            DHL, FedEx or UPS
            Ship from
            Xiamen, China
            Packed size
            2.014 × 23.34 × 22cm
            Shipping weight
            0.60kg
          • 02

            Payment & customs

            Payment
            Bank transfer (T/T)
            Currencies
            USD · EUR · GBP · RMB
            Credit cards
            Not accepted
            HS reference
            8538900000
            Origin
            Germany
          • 03

            Warranty & returns

            Warranty
            12 months from AMIKON
            Inspection
            Label, condition and packing checks
            Returns
            Prior RMA authorisation required
            Compatibility
            Confirm before order
            OEM warranty
            Does not apply
          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.

          • Part checked

            Full suffix recorded

          • Condition checked

            Label and appearance

          • Packing checked

            Antistatic protection

          • Tracking supplied

            Established couriers

          • Sandy Lin

            Dedicated account manager · 15+ years
          FREQUENTLY ASKED QUESTIONS

          Questions buyers ask about 6DD1606-3AC0

          Direct answers about identity, compatibility, stock, warranty, payment and shipping.

          • What binary channel allocation does IT41 provide?

            For 6DD1606-3AC0, the documented binary channel allocation is 16 inputs and 16 outputs. Compare this limit with the installed SIMADYN D IT41 configuration.

          • How many analog inputs and outputs are on IT41?

            For 6DD1606-3AC0, the documented analog channel allocation is 4 inputs and 4 outputs. Compare this limit with the installed SIMADYN D IT41 configuration.

          • How many incremental encoders can IT41 accommodate?

            For 6DD1606-3AC0, the documented incremental encoder capacity is 4 encoders. Compare this limit with the installed SIMADYN D IT41 configuration.

          • What voltage range is measured by IT41 analog inputs?

            For 6DD1606-3AC0, the documented analog input range is −10 to +10 V. Compare this limit with the installed SIMADYN D IT41 configuration.

          • What analog input resolution is specified?

            For 6DD1606-3AC0, the documented analog input resolution is 12 bits. Compare this limit with the installed SIMADYN D IT41 configuration.

          • What is the maximum IT41 analog conversion time?

            For 6DD1606-3AC0, the documented maximum analog conversion time is 45 µs. Compare this limit with the installed SIMADYN D IT41 configuration.

          • What identification supports ordering the SIMADYN D IT41 spare?

            Specify 6DD1606-3AC0, quantity and the installed SIMADYN D IT41 arrangement. Include label and connector photographs, and identify any required accessories separately.

          • Which incoming checks apply to the mixed signal expansion module?

            Compare the 6DD1606-3AC0 label, connector condition and supplied accessories with the quotation. Verify the accepted SIMADYN D IT41 configuration before replacing the installed item.
