In Stock
Ships by Monday, August 17
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6ES7131-4BD01-0AA0
-
Product Model6ES7131-4BD01-0AA0
-
Product ParametersSIMATIC DP Digital input electronic module
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.4x5.5x8.5cm
-
ManufacturerSiemens
-
Weight0.04 kg
-
Supply voltage24 V DC
-
permissible range, lower limit (DC)20.4 V
-
permissible range, upper limit (DC)28.8 V
-
Reverse polarity protectionYes
-
from backplane bus 3.3 V DC, max10 mA
-
from supply voltage L+, max.Dependent on encoder
-
Output voltagemin. L+ (-0.5 V), under load
-
Output current, rated value500 mA
-
Output current, permissible range0 to 500 mA
-
Power loss, typ0.7 W
-
with packing4 bit
-
Type of input voltageDC
-
Rated value,DC 24 V
-
for signal-30 to +5 V
-
for signal15 to 30 V
-
Isolation tested with500 V DC
Description
The SIEMENS 6ES7131-4BD01-0AA0 SIMATIC DP Digital Input Electronic Module is a compact digital input module for the SIMATIC ET 200S distributed I/O system. It is to acquire binary signals from field devices and transmit the input status to a higher-level SIMATIC controller through the ET 200S station interface.
The module provides four digital input channels for 24 V DC signals. It can be used to monitor the switching status of sensors, limit switches, pushbuttons, proximity switches, contactors, relays, and other binary field devices. Each input channel processes the field signal and transfers the corresponding ON/OFF status to the control system.
The 6ES7131-4BD01-0AA0 uses the ET 200S modular I/O architecture. The electronic module is installed on the appropriate terminal module and forms part of a distributed station. The terminal module provides the electrical connection for field wiring, while the electronic module handles signal processing and communication with the ET 200S backplane.
The module provides four digital input channels for 24 V DC signals. It can be used to monitor the switching status of sensors, limit switches, pushbuttons, proximity switches, contactors, relays, and other binary field devices. Each input channel processes the field signal and transfers the corresponding ON/OFF status to the control system.
The 6ES7131-4BD01-0AA0 uses the ET 200S modular I/O architecture. The electronic module is installed on the appropriate terminal module and forms part of a distributed station. The terminal module provides the electrical connection for field wiring, while the electronic module handles signal processing and communication with the ET 200S backplane.
Information
Overview
Manuals
Application Notes
Product Applications
Module Insertion
Features:
- 4 Digital Inputs (DI) at 24 V DC Standard
- Ultra-Compact 15 mm Module Width
- Pack of 5 Modules per Packing Unit
- Wide Cable Length Support: Up to 1000 m Shielded
The module is suitable for standard industrial digital signal acquisition. Its 24 V DC input design is widely used in machine automation, production equipment, material handling systems, packaging lines, process plants, and other industrial control applications. The input signals can be used for equipment status monitoring, interlocking, position detection, alarm monitoring, and sequence control.
The 6ES7131-4BD01-0AA0 SIEMENS SIMATIC DP Digital input electronic module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6ES7131-4BD01-0AA0 SIMATIC DP Digital input electronic module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 6ES7131-4BD01-0AA0 supports extensive cable lengths for flexible installation. The 6ES7131-4BD01-0AA0 accommodates cable lengths up to 1000 m for shielded cables and 600 m for unshielded cables, enabling distributed I/O configurations across large industrial facilities without signal degradation. The supply voltage for the 6ES7131-4BD01-0AA0 is 24 V DC, sourced from the ET 200S power module. The typical power loss of the 6ES7131-4BD01-0AA0 is only 0.7 W, contributing to energy-efficient system operation.
The 6ES7131-4BD01-0AA0 operates in ambient temperatures from 0°C to +60°C with IP20 protection rating. The 6ES7131-4BD01-0AA0 is designed for DIN rail mounting within the ET 200S rack system. The 6ES7131-4BD01-0AA0 is compatible with PROFIBUS DP and PROFINET communication interfaces when used with the appropriate ET 200S interface module, enabling seamless integration into Siemens distributed control architectures.
- Water/Wastewater: Collects pump status, float switch thresholds, and valve feedback
- HVAC/Building: Monitors airflow switches, filter-clog indicators, and damper confirmations
- Maritime: Deployed in vessel monitoring with DNV/Bureau Veritas type approvals
- Conveyor/Handling: Reads proximity/photo-eye signals for track, position, and sorting
- Packaging/Bottling: Processes high-speed sensor feedback for filling, capping, and labeling
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mount the Terminal Module: Ensure your chosen TM is already snapped onto the 35mm DIN rail and connected to the adjacent modules.
Align the Module: Hold the electronic module (6ES7131-4BD01-0AA0) straight in front of the TM slot.
Insert: Push the module firmly into the terminal module until you hear a distinct click, confirming the latching mechanism is securely engaged.
Alternative Names
6ES7131-4BD01-0AAO
6ES7131-4BD01-OAA0
6ES7131-4BD0I-0AA0
6ES7131-4BDO1-0AA0
6ES7131-48D01-0AA0
6ES713I-4BD01-0AA0
6ES7I31-4BD01-0AA0
6ES 7131-4BD01-0AA0
6ES 7131-4BD01-0AAO
6ES 7131-4BD01-OAA0
6ES 7131-4BD0I-0AA0
6ES 7131-4BDO1-0AA0
6ES 7131-48D01-0AA0
6ES 713I-4BD01-0AA0
6ES 7I31-4BD01-0AA0
6ES71314BD010AA0
Technical notes
The 6ES7131-4BD01-0AA0 is for installation in industrial control cabinets as part of an ET 200S distributed I/O station. The modular construction allows the input module to be installed close to the field devices, reducing wiring complexity and supporting flexible distributed control system layouts.
FAQs
-
What is the 6ES7131-4BD01-0AA0 ?
+The Siemens 6ES7131-4BD01-0AA0 is a digital electronic module for the SIMATIC DP ET 200S distributed I/O system, featuring 4 standard digital inputs rated at 24V DC. -
Which terminal module do I need to wire this module?
+The 6ES7131-4BD01-0AA0 requires a 15mm-wide terminal module from the ET 200S system. The terminal base handles the physical wiring connection while the electronic module plugs directly into it. -
Is hot-swapping supported?
+Yes, you can replace the module under voltage during operation if the terminal module is mounted on an active bus unit. -
How do I address this module in STEP 7 or TIA Portal?
+The 4DI module takes up 1 byte of input process image data. If you insert multiple 4DI modules, their addresses will automatically increment based on the order and byte configuration set in your hardware configuration
