Technical specifications for 5466-348
-
Product Model5466-348
-
Product ParametersNETCON 5000B SIO
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size2.5x24.6x26.1cm
-
ManufacturerWoodward
-
Weight0.95 kg
-
Discrete inputs16 × 24 V DC
-
Analog inputs4 × 4-20 mA
-
Analog outputs2 × 4-20 mA
-
Operating temperature–20 … +70 °C
-
Storage–40 … +85 °C
-
Humidity5 … 95 % RH non-condensing
Description
5466348
DISCONTINUED BY MANUFACTURER
MODULE
NETCON 5000B SIO
DISCONTINUED BY MANUFACTURER
MODULE
NETCON 5000B SIO
Information
Overview
Manuals
Technical notes
Product Applications
Core Function & Features
Features:
- With one driver per port, the update rate for critical parameters is 5 ms.
- Interface for Digital Actuator Drivers
- Each Rs-485 port can operate at a different rate group
- Each driver's communication fault is detected, and drivers with comm faults are disabled.
- Remote monitoring of driver parameters
- Remote driver parameter configuration
- Allows the drivers to issue a fast and very accurate position command (16 bits, no noise).
Each Real Time SIO Module contains the circuitry for three RS-485 ports. Eachport is designed to communicate with EM or GS/LQ Digital Actuator Drivers. Foreach port, one driver is allowed for every 5 ms. Each driver is identified by itsaddress switches, which must match the driver number in the GAP applicationprogram. The RS-485 communications to the Universal Digital Drivers can beused for monitoring or control purposes.
The 5466-348 WOODWARD Netcon SIO Module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
WOODWARD 5466-348 Netcon SIO Module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
This module is designed to be used with Digital Drivers. Each Real Time SIOmodule contains three RS-485 ports. The units should have their terminationresistors installed, to prevent reflections.The RS-485 interface may be used in one of three ways:
It can be used to send the position demand and configuration information tothe driver, as well as monitor the driver status outputs.
It can be used to configure the driver and monitor the status outputs, but notto send a position demand. The driver position demand would be from a 4–20 mA input or the CAN bus interface.
It can be used to monitor the driver status outputs, but not configure thedriver or send a position demand to the driver. The driver position demandcould be from a 4–20 mA input or from the CAN bus interface, and theconfiguration input could be from RS-232 or from the CAN bus interface.
- Turbine Regulation: Speed and load control for gas and steam
- Actuator Control: Manages position demands and configurations for digital actuator drivers (EM or GS/LQ).
- Compressor Control: Used in industrial compressor regulation.
- Marine Propulsion: Controls and protects ship propulsion systems.
- Power Generation: Used in generator sets and power plant auxiliary equipment.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Three RS-485 Ports: Each port is dedicated to communicating with EM or GS/LQ Digital Actuator Drivers.
Fast Update Rate: The module provides a 5 ms update rate for critical driver parameters, ensuring real-time response for actuator control.
16-bit Resolution: Issues high-accuracy position commands with minimal noise.
Fault Detection: Automatically identifies communication errors and disables faulty drivers to maintain system integrity.
FAQs
-
What is 5466-348?
+It is Netcon SIO Module developed by Woodward. -
How many drivers can be connected to each RS 485 port?
+Each RS-485 port allows for the connection of one driver. Therefore, the module can accommodate a total of three drivers, one for each port. -
Do you have it in stock?
+Yes, right now we have Woodward 5466-348 in stock ready for shipment, we can support video inspection -
What is the function of the 5466-348?
+It is a Woodward Netcon SIO module that acts as an interface for managing up to three digital actuator drivers. -
What is the communication update rate of 5466-348?
+When one driver is used per port, the SIO module updates critical parameters every 5 milliseconds.
