Yokogawa Centum XL

Duplexed Field Control Unit

For Vnet/IP and FIO, for 19-inch Rack Mountable
100–120 V AC power supply
220–240 V AC power supply
Basic type
LFS1500 Control Function for Field Control Station (for Vnet/IP and FIO)

ESB Bus Interface Slave Module

8, isolated
4 to 20 mA
24 mA
270 Ω (20 mA) to 350 Ω (4 mA)

Current Input Module

16, isolated
4 to 20 mA
270 Ω (20 mA) to 350 Ω (4 mA)
±16 µA
230 mA (5 V DC), 540 mA (24 V DC)

Power Supply Module

Power Supply Module
Two modules in case of
dual-redundant configuration.
Power supply to the I/O modules
and supply power to the transmitters
The power supply terminals use M4 screws

Optical ESB Bus RepeaterSlave Module

Optical ESB Bus RepeaterSlave Module
Star type connection Chain type connection Available
for both star and chain type connection
Maximum two
Maximum 5 km (total two stages)
In case of Vnet/IP system with the R1.03 or later
the total distance of two stagesis maximum 10 km
Current consumption: 0.5 A

Optical ESB Bus Repeater Slave Module

ESB Bus optical transport function
Star type connection
Chain type connection
Maximum two
Maximum 5 km (total two stages)
Current consumption: 0.5 A

Optical ESB Bus Repeater Module

SNT501-13 S1
Optical ESB Bus RepeaterModule
Maximum 5 km (total two stages)
In case of Vnet/IP system
with the R1.03 or later, the total distance
of two stagesis maximum 10 km

Power Supply Module

SPW48113S1
POWER MODULE
2.5 AMP
100-120 V
50/60 HZ

Ethernet Communication Module

ETHERNET COMMUNICATION MODULE
STANDARD TYPE
NO EXPLOSION PROTECTION
BASIC TYPE
STYLE S1
NO DIRECT REPLACEMENT

Digital Output Module

±36 V
1 MΩ or more
500 Ω or less
±100 mV, ±0.3 % of full scale
Max. ±6.4 mV/ °C, ±0.02 %/ °C
15 bits/0-32 V

Power Supply Module

Input Voltage: 100–120 V AC
Input Frequency: 50/60 Hz
Maximum Power Consumption: 200 VA
Output Voltage: Typically 24 V DC
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Storage Temperature: -25°C to +70°C (-13°F to 158°F).
Humidity: 5–95% RH (non-condensing)

DP97 *B Display Processor Card

Multipoint Analog I/O Card

VM2 *D Multipoint Analog I/O Card

VM1 *D Multipoint Analog I/O Card

ST7 *A Multipoint Status Output Card

ST7 *A Multipoint Status Output Card

ST6 *A Multipoint Status Input Card

ST5 *A Multipoint Status I/O Card

Multi Status Input Card

Multi Status Input Card

2 Channel Mirco XL Module
