Number of output channels:64
Rated applied voltage:24 V DC
Load voltage:24 V DC, 100 mA
Field power supply voltagerange:20.4 to 26.4 V
Output ON voltage maximumvalue:2 V DC
Leak current maximum valuewhen output OFF:0.1 mA
Output format:Current sink
Number of input:channels16, non-isolated
Input signal:4 to 20 mA
Allowable input current/voltage:27 mA
Accuracy:±0.1% of full scale
Data refresh cycle:10 ms
Input step response time:100 ms
Transmitter power supply:22.8 to 26.4 V
Setting of 2-wire or 4-wiretransmitter
For each channel by setting pin
Allowable input voltage ±5 V.
Withstanding voltage :1500 V AC for 1minute
Power ON 2 MΩ or more
Power OFF 2 MΩ or more
Accuracy ±0.03% of full scale (for 0 to 400 Ω)
Allowable total resistance of signalsource plus wiring:40 Ω or less
(wiring resistance per wire)
Temperature drift:Max. ±30 ppm/°C.
Maximum current consumption:450 mA (5 V DC)
Type: Optical ESB Bus Repeater Module
Bus System: ESB
Connector Type: SC or LC connectors
Operating Voltage: Typically 24 V DC
Operating Temperature Range: -10°C to 60°C (14°F to 140°F)
Power Consumption: Typically low, around 3-5W
Number of input channels
16-channel input, isolated
Input signal 4 to 20 mA
Allowable input current 24 mA
Accuracy ±0.1% of full scale
Data refresh cycle 10 ms
Transmitter power supply 24.0 to 25.5 V
Temperature drift Max. ±0.01%/°C
Number of I/O channels
8-channel input, isolated channels
I/O signal 4 to 20 mA
Allowable input current 25 mA
Accuracy ±16 µA
Data update period 10 ms
Temperature drift ±16 µA/10 °C
Maximum currentconsumption
360 mA (5 V DC), 450 mA (24 V DC)
High-Speed 1 MS/s 16-bit Isolation Module
(4 ch) High Noise Immunity
Suitable for testing and long-term monitoring
for power generators and multi-output power supplies.
Provides dynamic analysis of multi-channel
data recording applications.
Applicable to DL350 and DL850 series
Function: ESB Bus optical transport function
Connection method: Star type connection
Chain type connection
Available for both star and chain type connection.
Number of connecting stage: Maximum two
Transmission distance: Maximum 5 km (total two stages)
In case of Vnet/IP system with the R1.03 or later,
the total distance of two stagesis maximum 10 km.
Current consumption: 0.5 A
Number of output channels 8 channels, module isolation
Rated output range 4 to 20 mA
Maximum range of guaranteed precision 1.25 to 23 mA
Output range 1.25 to 23 mA
Allowable load resistance @ rated range 230 to 600 Ω
Accuracy ±48 µA
Data update frequency 40 ms
Temperature drift ±16 µA/10 ºC
Withstand voltage 1.5 kV AC between output signal and system for 1 minute
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
External power supply 24 V DC +20 %/–10 %
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
External power supply 24 V DC +20 %/–10 %
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Number of outputs 4-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 10 A minimum
External power supply 24 V DC +20 %/–10 %
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 2 A/output line
Minimum load current 100 mA
Load resistance range 12 to 240 Ω)
Maximum lamp load (*1) 1 A/output line
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Number of inputs 16-channel, module isolation
Input current 6 mA ± 20 %
Contact rating 24 V DC +20 % / -10 %
External power supply 24 V DC +20 % / -10 %
Input response time 40 ms maximum
Withstand voltage (*1) (*2) 2 kV AC between input signal and system for 1 minute, 16-input line collectivelyconnected
Number of input channels 16 channels, module isolation
Rated input range 4 to 20 mA
Permissible input range 0 to 25 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute
Number of input channels 16 channels, module isolation
Rated input range 4 to 20 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Number of outputs 4-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 10 A minimum
Output format Current source
Maximum load current 2 A/output line (8 A in total output lines) (*4)
Minimum load current 100 mA
Load resistance range 12 to 240 Ω (*6)
Input Voltage:24V DC
Input Current:10-20 mA
Signal Input Range:0-24V DC
Input Channels:8 or 16
Operating Temperature:-10°C to +60°C
Storage Temperature:-40°C to +85°C
Input Voltage:24V DC
Input Current:10-20 mA
Signal Input Range:0-24V DC
Input Channels:8 or 16
Operating Temperature:-10°C to +60°C
Storage Temperature:-40°C to +85°C
Input Voltage:24V DC
Current Consumption:Typically 100-200 mA
Fieldbus Power:24V DC
Operating Temperature:Typically -10°C to +60°C
Storage Temperature:-40°C to +85°C
Communication profile CiA 301
Number of installed NFLC121 modules 4 max. for FCN-500
Number of slave devices 126 slave devices per
CANopen Communication Module
Node Bootup
SYNC producer
Heartbeat Consumer/Producer
Number of output channels 16
Rated applied voltage 24 to 125 V DC
100 to 240 V AC, 50/60 Hz
Output response time 12 ms or less
Maximum current consumption 780 mA (5 V DC)
External connection Pressure clamp terminal
