Number of inputs 16-channel, module isolation
Input signa:
No-voltage contact
ON: 1 kΩ maximum
OFF: 100 kΩ minimum
Input current 6 mA ± 20 %
Contact rating 24 V DC +20 % / -10 %
Input response time 40 ms maximum
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
100-120 V AC power supply
24 V DC power supply
Standard Type (-20 to 40 °C)
(with ISA Standard G3 )
Dual-redundant power supply
Wide range temperature (-20 to 70 °C)
type (with Fan unit and ISA Standard G3)
Output signal 4 to 20 mA
Allowable load resistance 0 to 750 Ω
Circuit-open detection Less than 0.65 mA
Accuracy ±48 µA
Data update period 10 ms
Drift due to ambient temperature change ±16 µA/10 ˚C
4 to 20 mA
16 isolated
standard switch-overresponse
in redundant configuration
1500 V AC, for 1 minute
0 to 750 Ω
Less than 0.65 mA
±48 µA
±16 µA/10 ˚C
230 mA (5 V DC)
540 mA (24 V DC)
Number of input channels: 16, isolated channels
Allowable input voltage :±5 V
Input resistance:1 MΩ or larger
Maximum currentconsumption:350 mA (5 V DC)
Measurement current:RTD: 1 mA
Resistance ofsignal source plus wiring:150 Ω or less
