3300 System

3300 NSv Proximity Probes

330905  3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:20 mm
Minimum length: 100 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Extension Cable

For use in Tight
Installation Requirements
Replaces 3300 RAM Transducer Systems
and 3000-Series or 7000-Series 190 Transducer System
Average Scale Factor of 7.87 V/mm (200 mV/mil)

3300 NSv Extension Cable

For use in Tight
Installation Requirements
Replaces 3300 RAM Transducer Systems
and 3000-Series or 7000-Series 190 Transducer System
Average Scale Factor of 7.87 V/mm (200 mV/mil)

3300 XL 50 mm Proximitor Sensor

3300 XL 50 mm Proximitor Sensor
9 19.0 meters (29.5 feet)
systemlength
DIN mount
0 0 No Approvals

3300 XL 11 mm Probe

3300 XL 11 mm Probe
1/2-20 UNFthread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
00 Not required

3300 XL 11 mm Reverse MountProbe

330706-005-046- CC-DD-EE M10 x 1 threads
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector
00 Not required

3300 XL 11 mm Probe

330702 3300 XL 11 mm Probe
1/2-20 UNFthread, with armor
Minimum unthreaded length:2.0 in
Minimum case length: 3.0 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 Multiple Approvals

3300 XL 8 mm Probe

M10 x 1 threads(2)
90 9.0 meters (29.5 feet)
02 Miniature ClickLoc coaxialconnector
00 Not required

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:20 mm
Minimum length: 100 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread
with armor
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector with connectorprotector,
standard cable
00 Not required
Order in increments of 10 mm
Length configurations:
Maximum unthreaded length: 230 mm
Minimum unthreaded length: 0 mm
Example: 0 6 = 60 mm

3300 NSv Extension Cable

060 6.0 meters (19.7 feet)
03 Without stainless steel armor
with connector protector
05 Multiple Approvals
3300 NSv Extension Cable

3300 NSv Proximity Probes

330905    3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Maximum length: 250 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

NSv Proximitor Sensor

51 5.0 meters (16.4 feet) systemlength
00 Not required
PORXIMITY CONTROL SENSOR
7.87V/MM
24VDC

3300 XL NSv Proximitor Sensor

70 7.0 meters (23.0 feet) systemlength
panel mount
00 Not required
3300 XL NSv Proximitor Sensor

VIBRATION SENSOR

Vibration Sensor
Output Type 4-20 mA
Velocity Measurement Range 0.1 mm/s to 200 mm/s
Sensitivity 1000 Hz
Mounting Thread 5/8-18 UNS-2A
Operating Temperature Range -40°C to 120°C

3300 XL 11 mm Proximity Transducer

Probe Tip Diameter 11 mm
System Length 22 ft
Thread Size 3/8-24 UNF-2A
-51°C to +100°C (-60°F to +212°F)
0 to 4.0 mm (160 mils) linear range
7.87 mV/μm (200 mV/mil) nominal
Up to 90%, non-condensing

3300 XL 11 mm Proximity Probes

3300 XL 8 mm Proximity Probes
4 - 4 mm
54- 540mm
2 - 1.0 metre (3.3 feet)
11 - Miniature coaxial ClickLoc connector, FluidLoc cable
00 - Not required

3300 XL 8 mm Proximity Transducer

330104 3300 XL 8 mm Probe,
M10 x 1 thread,with armor
Minimum unthreaded length: 140 mm
Minimum case length: 190 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
00 Not required

3300 XL 8 mm Proximity Transducer

330104    3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 70 mm
Minimum case length: 120 mm
10 1.0 meter (3.3 feet)
11 Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
00 Not required

Interconnect Cable

Impedance: 50–100 Ω
Capacitance: <100 pF/m
Max Voltage Rating: 300V AC/DC
Signal Type: Supports -24V DC
Length: Standard 1m to 30m

3300 NSv Extension Cable

065 6.5 meters (21.3 feet)
04With stainless steel armor
withFEP jacket
with connectorprotector
05 Multiple Approvals

3300 NSv Extension Cable

045 4.5 meters (14.8 feet)
04With stainless steel armor
withFEP jacket
with connectorprotector
05 Multiple Approvals

3300 XL 8mm Proximity Transducer

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 60 mm
Minimum case length: 60 mm
90 9.0 meters (29.5 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL NSv Proximitor Sensor

3300 NSv Probe
3/8-24 UNF thread
withoutarmor
5.0 metres (16.4 feet)
CN Multiple Approvals
Maximum case length: 9.9 in
Minimum case length: 0.8 in
Example: 2 4 = 2.4 in

3300 NSv Extension Cable

060 6.0 meters (19.7 feet)
05With stainless steel armor
without FEP jacket
withconnector protector
05 Multiple Approvals
