SPB Circuit Board
Input Voltage: Typically 24V DC
Operating Voltage Range: ±15V DC
Current Consumption:<500mA
Isolation Voltage: 1000V AC
Fiber optic or optocoupled signals
Digital I/O (for control signals)
Printed Circuit Board
Logic Side: 5V DC
Isolated Side: 15V DC
Current Rating: Typically <1A
Reinforced isolation:≥2500V AC
High-speed digital signals
Analog inputs:0-10V, 4-20mA
Power Supply Module
Input Voltage:230V AC
Range: Typically ±15%
Output Voltage:+24V DC
Auxiliary Outputs: ±15V DC
Efficiency: >85%
Isolation: 2500V AC
Terminal blocks for AC input and DC output
Multi-pin headers for control signals
Control Board
Processor:32-bit DSP
Typical clock speed: 100-150MHz
Memory Flash: 2-4MB
Memory RAM:512KB-1MB
Supply Voltage:24VDC ±10%
Secondary: 3.3VDC, 5VDC
Power Consumption: <15W typical
Isolation: 2500VAC between control and power sections
Power Supply Module
Input Voltage:230V AC
Range: -15% to +10% of nominal
Frequency: 50/60Hz ±5%
Output Voltages:+24V DC (±1%)
Current Ratings:24V DC
Efficiency: >88% at full load
Ripple: <1% of nominal output voltage
S+ Infi-net to Computer Interface Module
Processor: 32-bit RISC processor
Memory:8MB RAM
Power Supply: 24V DC ±10%
Power Consumption: <15W
Operating Voltage Range: 18-30V DC
Screw terminals for power
BNC or ST-type fiber for Infi-net
DB9 or DB25 for serial
RJ45 for Ethernet (if equipped)
Controller Module
CPU: 32-bit RISC processor
Clock Speed: 100-200 MHz
RAM: 32-64 MB
Flash Memory: 16-32 MB
Voltage: 24V DC
Power Consumption: 8-15W
Isolation: 1500V AC (input-to-output)
Conductivity Transmitter Controller
Power consumption: ≤5VA
TDS: 0.001 ppm to 1000 ppt
Resistivity: 0.5 Ω·cm to 100 MΩ·cm
Accuracy:±0.5% of reading ±0.001 μS/cm
Power Supply: 100-240V AC ±10%, 50/60Hz
Conductivity: 0.001 μS/cm to 2000 mS/cm (auto-ranging)
1-point offset adjustment
2-point cell constant calibration
Dry calibration (for verification)
CONNECTION TERMINAL UNIT
Number of Channels: 16 connection points
Isolation: 250V AC
Rated Voltage: 250V AC/DC
Current Rating: 2A per channel
Contact Resistance: <50mΩ
Insulation Resistance: >100MΩ @ 500V DC
Dielectric Strength: 2000V AC (50Hz)
Governor Detection Board
Frequency range: 1Hz-20kHz
Input sensitivity: 50mV RMS minimum
Isolation: 1500V AC between channels
Analog Inputs:4-20mA position
Control Outputs: 4-20mA governor control signal
Power Supply:24VDC nominal
Accuracy: ±0.1% of reading ±1 RPM
TEACH PENDANT MAINBOARD
Operating Voltage: 24V DC
Power Consumption: <15W
Isolation: Opto-isolated I/O for safety signals
CPU: ARM-based microcontroller
Flash Memory: Stores firmware and configuration
Touchscreen panels
State-of-the-art graphics
Robust and reliable
Truly open platform
Display type:Touch
Display size 15.4"
Brightness:450 cd/m²
Display resolution, ratio:1280 x 800 (16:10)
Processor:ARM9 (1 GHz)
Main memory:1 GB
Power Control drive board
DC Bus Monitoring:0–1000V DC typical
Logic Side: +24V DC (±10%)
Gate Drive Side: +15V/-8V
Current Consumption:<500mA
Gate Drive: Peak 2A
Reinforced Isolation: 2500V AC
Working Voltage: 1000V DC
Control Panel
Intel Core i5/i7 processor (generation varies)
RAM: 8-32GB DDR4
Storage: 256GB-1TB SSD
Power Supply:100-240V AC, 50/60Hz
Role-based access control
Audit trail logging
Cyber security compliant
CURRENT TRANSDUCER CONTROL BOARD
Input Current Range:±10A (direct input)
Output Signal:4-20mA analog output
Analog Output: 4-20mA (load ≤500Ω)
Accuracy: ±0.5% of full scale
Bandwidth: 10kHz (-3dB point)
Isolation Voltage: 2500V AC
Cartridge U-high HART / Std. FET 300
Input Voltage: 24V DC
Power Consumption: ≤1.5W
Isolation: 500V AC
Signal Conditioning:16-bit ADC resolution
Analog Input:4-20mA + HART
4-20mA loop drive: ≤500Ω
Communication Speed: 1200 bps (FSK)
Multidrop Mode: Supports up to 15 devices
SPEED TRANSDUCER MODULE
Magnetic pickup (MPU) or proximity probe
Frequency range: 1Hz to 10kHz
Input sensitivity: 50mV RMS minimum
Accuracy: ±0.1% of reading ±1 RPM
Analog Output:4-20mA
Load capacity: ≤500Ω
Power Supply:24V DC ±10% (standard)
Inverter Power Supply Board
Input Voltage:24V DC
Output Voltages:+24V DC
Current Capacity:+24V: 2A max
Efficiency:≥85% (full load)
Ripple Noise:<1% of output voltage
Reinforced Isolation :1500V AC input-to-output)
Symphony Plus Controller
Processor:Dual-core ARM Cortex
Memory:2GB RAM
I/O Capacity:Supports up to 512 I/O points
Power Supply:24V DC
Power Consumption:≤15W (typical)
Ethernet: 2× 10/100/1000 Mbps
Fieldbus: PROFIBUS DP, Modbus TCP/RTU
POWER DRIVE BOARD
Input Voltage:24V DC (±10%)
Gate Drive Output:+15V / -8V (IGBT control)
Isolation Voltage:2500V AC (gate-to-control)
Switching Speed:<100ns (turn-on/off)
Current Sensing:±0.5% accuracy
LV AC general purpose wall-mounted drive
Number of Phases:3-phase
Degree of Protection:IP21
Enclosure Type NEMA:Type1
Altitude:1000 m
Operating Humidity (RHamb):5 ... 95
Sound dB (A):63 dB(A)
Frequency (f):47.5 ... 63 Hz
Frame Size:R5
Input Voltage (Uin):380 ... 480 V
DRIVE BOARD
Input Voltage:24V DC ±10%
Gate Drive Output:+15V/-8V (typical for IGBTs)
Isolation Voltage:2500V AC
Current Sensing Accuracy:±1% of full scale
Switching Frequency:Up to 20kHz
Fiber optic for control signals
Terminal blocks for power connections
Multi-pin headers for auxiliary signals
Extension Card I/O
Supply Voltage: Typically 24V DC
Voltage range: 24V DC
Load capacity: Up to 2A per channel
Resolution: 12/16-bit
Signal types: 4–20mA, 0–10V
DIFFERENTIAL UNIT
Rated Current (In): Typically 1A or 5A
Frequency: 50/60 Hz
Harmonic Restraint: 2nd/5th harmonic blocking
Number of phases: 3
Trip contacts: Normally 4–6 changeover
Rated load: 5A @ 250V AC/DC
