CEX-Bus Terminatior

3BSC950193R1
CONNECTOR
CEX-BUS
TERMINATOR TB850
25PIN
DB25P
MALE

PP885 High Performance Touch Panel 15.4"

3BSE069276R1
DISCONTINUED BY MANUFACTURER
OPERATOR INTERFACE
15.4IN TOUCH PANEL
TFT 1280X800 (16:10)

15-inch TFT HMI panel

Powder-coated aluminum
Touch screen: Polyester on glass 1 million finger
touch operations.Overlay: Autotex F157/F207
25-pin D-sub contact
chassis-mounted female
withstandard locking screws 4-40 UNC
 9-pin D-sub contact
male with standard locking screws 4-40 UNC

Processor unit

CPU: Dual-core, 1.2 GHz
Flash Storage: 4 GB
Ethernet Ports: 2x 10/100/1000 Mbps
Input Voltage: 24V DC
Power Consumption: 15W typical

OPERATOR INTERFACE

OPERATOR INTERFACE
PROCESS PANEL SERIES
24 VDC
0.35 AMP(PP235)

Compact Terminal block

Compact installations of I/O modules
Field signals and process power connections
Connections to ModuleBus and I/O modules
Mechanical keying prevents insertion of the wrong module
Latching device to DIN rail
DIN rail mounting

Module Termination Unit

3BSE022460R1
DISCONTINUED BY MANUFACTURER
TERMINATION UNIT
TU846
Country of Origin: Sweden

TU838 Extended Module Termination Unit

3BSE008572R1
PLC MODULE
TU838
TERMINAL EXTENDED MODULE
50V

Compact Module Termination Unit

Up to 32 channels of field signals
Connections to ModuleBus and I/O modules.
Mechanical keying
DIN rail for grounding
DIN rail mounting

MODULEBUS EXTENSION CABLE ADAPTOR

3BSE008536R1
MODULEBUS EXTENSION CABLE ADAPTOR
D-SUB
25 MALE

SD834 Power Supply Device

Input a.c. 100-240 V or d.c
110-150 V. Output
d.c. 24 V 20A
If redundant power application
is required connect to SS8XX voting unit
DIN rail mounted
G2 compliant

Pulse Counter or Frequency Measurement Module

8 channels
The modules can be used in
both single and redundant applications
Interface for NAMUR, 12 V and
24 V transducer signal levels
Each channel can be configured for
pulse count or frequency measurement
The inputs can also be read as DI signals
Pulse count by accumulation in a 16 bit counter
Frequency (speed) measurement 0.5 Hz - 20 kHz
Advanced on-board diagnostics

Analog Output Module

Input impedance:2.5 kΩ
Maximum field cable length:200 meters (218 yards)
Rated insulation voltage:50 V
Dielectric test voltage:500 V a.c.
Power dissipation:2.5 W
Current consumption +5 V Modulebus:120 mA

Digital Output Module - 24Vdc

Digital Output Module - 24Vdc

Digital Output Module

3BUR001455R1
DIGITAL OUTPUT MODULE
CURRENT SINKING
DO814

Digital Input Module

NAMUR inputs
G3 compliant
Output status indicators
state upon error detection
Intrinsic Safety support
Short-circuit protection to ground and 30 V
8 channels with process voltage supervision
OSP sets outputs to predetermined
Over-voltage and over-temperature protection

REDUNDANT FIELDBUS INTERFACE MODULE

3BSE025255R1
REDUNDANT
FIELDBUS INTERFACE MODULE
AF 100
(CI820V1)

Analog Output Module

3BSC690087R1
DISCONTINUED BY MANUFACTURER
INPUT MODULE
ANALOG
8 CHANNEL
4-20 MA
W/ INTRINSIC SAFETY INTERFACE
HART
(AO895)
Tariff Code: 85389091
Country of Origin: Singapore

Analog Output Module

3BSE052605R1
OUTPUT MODULE
ANALOG
1 X 8 CHANNEL
4-20 MA
W/ HART
(AO815)

Analog Output Module

Input/Output Type: Analog Output
Output Voltage:Typically 0-10 V DC or 4-20 mA
Channels:Typically 8 channels
Output Range:4-20 mA or 0-10 V
Output Accuracy:±0.1% of full scale
Power Supply:24 V DC
Power Consumption:Typically < 12 W

AI820 Analog Input Module

INPUT MODULE ANALOG
4 X 1 CHANNEL / INDIVIDUALLY GALVANIC ISOLATED
250 OHM
20 MA
10 VDC
(3BSE008544R1)

Analog Input Unit - HART

8 channels for 0...20 mA
4...20 mA, 0...5 V or 1...5 V d.c
single ended unipolar inputs
1 group of 8 channels isolated from ground
12 Bit resolution
Current limited transmitter supply per channel
HART pass-through communication

Power Voting Unit

Input Voltage Range: 18–32 VDC
Output Voltage: 24 VDC
Input Current: Rated for up to 20 A
Efficiency: ≥ 95%
Operating Temperature Range: -25°C to +70°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% RH (non-condensing)

RTA Communication Kit

Power Supply: 24 VDC (±10%).
Operating Temperature: -25°C to +60°C
2x Ethernet ports (RJ45, 10/100/1000 Mbps)
Optional serial ports (RS-232/485)
Compatible with ABB AC 800M controllers

RTA Communication Box for MB300

Power Supply: 24 VDC (±10%).
Operating Temperature: -25°C to +60°C
2x Ethernet ports (RJ45, 10/100/1000 Mbps)
Optional serial ports (RS-232/485)
Compatible with ABB AC 800M controllers
