Analog Module

TSXAEY414
DISCONTINUED BY MANUFACTURER
INPUT MODULE
FOR MODICON TSX
ANALOG
4 INPUTS
16 BITS
4-20 MA
+/-10V

Digital Input Module

Discrete input voltage:24 V DC positive
Sensor power supply:19…30 V
Discrete input current:3.5 mA
isalotion resistance:< 10 MOhm 500 V DC
ambient air temperature for operation:0…60 °C
Ambient air temperature for storage:-25…70 °C

ControlLogix 16 MB Controller

Series:ControlLogix
Part Number/Catalog No.:1756-L74
Non-volatile memory:1GB
No. of task:32
I-O Memory:0.98 MB
User Memory:16 MB
Maximum Digital I-O:128,000
Current Draw (1.2 Volts DC):5 milliamps
Current Draw (5.1 Volts):800 milliamps
Power Dissipation:2.5 Watts

Kinetix 6000 Axis Module

AXIS MODULE
KINETIX 6000 AXIS MODULE
400 / 480 VAC
3.9 KW / 9 AMP INVERTER
WITH SAFE TORQUE-OFF FEATURE

SM321 Digital Input Module

DIGITAL INPUT MODULE
SIMATIC S7-300
ISOLATED
16-DIGITAL INPUTS
24VDC
1 X 20 POLE
SUCCESSOR FOR 6ES7321-1BH01-0AA0

1771 Power Supply

1771P7
POWER SUPPLY MODULE
16 AMP
120/220 VAC
5 VDC
50/60 HZ
PLC-5
Country of Origin: United States

SLC 500 Power Supply

Series:SLC 500
Module Type:Power Supply
Input Voltage:120 to 220 Volts AC
Input Power:42 Watts
Inrush Current:20 Amps
Internal Current Capacity:2 A at 5V dc 0.46 A at 24V dc
Output Voltage Range:18 to 30 Volts DC
Backplane Current (5 Volts):2 Amps
Backplane Current (24 Volts):0.46 Amps
Frequency:47 to 63 Hertz
Location:1746 Chassis
Weight:2 pounds

Central processing unit

SIMATIC S7-300
CPU 317-2 PN/DP
Central processing unit
with 1 MB workmemory
1st interface MPI/DP 12 Mbit/s
2nd interface Ethernet PROFINET
with2-port switch
Micro Memory Card required

Simatic S7-200 CPU 224

SIMATIC S7-200
CPU 224
COMPACT UNIT
AC POWER SUPPLY14 DI DC/10 DO
RELAY
8/12 KB CODE/8 KB DATA
PROFIBUSDP EXTENDABLE
8537101190

Mechanical velocity sensor

Sensitivity:17.5 mV/mm/s
Frequency Range:14 to 1000Hz
Natural Frequency:14Hz ± 7% @ 20°C (68°F)
Transverse Sensitivity:< 0.1 @ 80Hz
Vibration Amplitude: 500µm peak-peak
Amplitude Linearity:< 2%
Maximum Transverse Acceleration:2g (19.62 m/s2)
Damping Factor :0.6% @ 20°C (68°F)
Resistance:1723Ω ± 2%
Inductance:≤ 90 mH
Active Capacity:< 1.2 nF

CPU 314C-2PN/DP Compact CPU

CPU MODULE
SIMATIC S7-300
W/ 192 KB WORK MEMORY
24 DI/16 DO
4 HIGH-SPEED COUNTERS (60 KHZ)
1ST INTERFACE MPI/DP 12 MBIT/S
2ND INTERFACE ETHERNET PROFINET WITH 2-PORT SWITCH
24 VDC POWER SUPPLY

Flex I/O Terminal Base

Part Number/Catalog No.:1794-TB32
Product Type:Flex I/O Terminal Base Unit
Terminal Screw Torque:0.56-0.79 Nm
Supply Voltage Range max.:31.2V DC/AC, 50/60Hz, 10A
Isolation Voltage:50V Continuous max.
Voltage Rating :24V DC/AC

Double Motor Module

SINAMICS S120 Double Motor Module
input: 600 V DC
output: 400 V 3 AC, 18 A/18 A
type of construction: booksize internal
air cooling optimized pulse patterns
and support of the extended
Safety Integrated functions
incl. DRIVE-CLiQ cable

Comfort CE6.0 9" TFT 16:9

SIMATIC HMI TP900 Comfort
Comfort Panel
touch operation
9" widescreen TFTdisplay
16 million colors
PROFINET interface, MPI/PROFIBUS DP interface
12MB configuration memory
Windows CE 6.0, configurable
from WinCC ComfortV11

CUSA Module

SIMOVERT Master
drives Module
CUSA AFE-infeed
backfeed unit Control module
Firmware version: V2.XX

SIMATIC HMI MEMORY CARD 2 G COMFORT PANEL

SIMATIC SD memory card
2 GB Secure Digital Card
for For devices withcorresponding

COMMUNICATION MODULE

COMMUNICATION MODULE
SIMOVERT MASTER DRIVES
MOTION CONTROL
CBP2 PROFIBUS

Analog Output Module

SIMATIC S7-300
Analog output SM 332
isolated, 4 AO, U/I
diagnostics; resolution 11/12 bits
20-pole, removing and inserting possible
with active backplane bus

Digital I/O Module

SIMATIC S7-300
Digital module SM 323
isolated, 16 DI and 16 DO
24 V DC, 0.5 A
Total current 4A
1x 40-pole

OP17 Operator Panel - DP Interface

Operator Panel OP 17/DP LC display,
LED backlit 4x 20/8x 40 lines x characters
SIMATIC S7, M7
PROFIBUS DP 1.5
Mbaud with UL/CSA approval

CP340 RS422/485 Interface Module

SIMATIC S7-300
CP 340 Communications processor
with RS 422/485 interfaceincl
configuration package on CD

CPU MODULE

CPU
24 DI/16 DO
4 AI
2 AO
4 HIGH-SPEED COUNTERS
INTEGRATED DP INTERFACE
INTEGRATED POWER SUPPLY 24 VDC
WORK MEMORY 96 KB
FRONT CONNECTOR (2X 40-POLE)
MICRO MEMORY CARD REQUIRED
REPLACED BY 6ES7314-6CH04-0AB0

IP67 Output Block - 24 VDC Positive Logic - 8 Pt 2A - Profibus

IC676PBO082
IP67 OUTPUT BLOCK - 24 VDC POSITIVE LOGIC - 8 PT 2A - PROFIBUS
