Rated Voltage: 24 V DC ±10 %
Power Consumption: 4.5 W (holding)
Coil Insulation: Class F (155 °C)
Port Size: G 1/4 (BSPP)
Orifice Diameter: 1.3 mm
Max. Working Pressure: 0.7 MPa
Architecture: 32-bit RISC CPU
Supply Voltage: 24 V DC ± 20 %
Power Consumption: 8 W typical
Galvanic Isolation: 500 V between supply
Retentive Memory: 128 kB FRAM
Processing Time: 0.1 µs / binary instruction
Real-Time Clock: ± 1 min / month @ 25 °C
Logic Supply: 5 V DC ±5 % @ 3 A max
Field I/O Supply: 24 V DC ±10 % @ 1.2 A max
Isolation: 500 V RMS betwee
Surge Withstand: IEEE 472-1974 (SWC) 2 kV
Microcontroller: 16-bit Motorola
Flash Memory: 512 kB
Battery-backed RAM: 32 kB
Analog Inputs: 8 × 0-10 V / 4-20 mA
Capacity:30 gpm
Pilot Ratio:3:1
Maximum Setting:4000 psi
Pilot Configuration:Bleed through
Valve Hex Size:1 1/8 in.
Valve Installation Torque:45 - 50 lbf ft
