Printed circuit board



                                                        CIRCUIT BOARD
TURBINE CONTROL
2 PORTS
MARK VI
SPEEDTRONIC SERIES






	IS200TRPGH2B

	PC BOARD
FEATURES TWO LARGER TERMINAL BLOCKS


CPU MODULE



                                                        Series:PACSystem RX7i
Manufacturer:GE Fanuc
Part Number:IC698CPE020
Maximum Program block size:128 KB
User Memory:10 Megabyte
Processor speed:700 MHz
Application:Rx7i System
Media Redundancy:Supported via LAN 2
Random Access Memory (RAM):10 MB
Operating Voltage:5 to 12 Volts DC
Flash Memory:10 MB
Current Rating:4.3 Amps
Ethernet data rate:10Mb/sec and 100Mb/sec
Discrete I/O memory:32 K
Analog I/O memory:32 Kwords
No. of Program blocks:512 Program block
CPU Memory:10 Megabyte User Logic RAM
Processor type:Pentium III, 700 MHz


Rack mount CPU



                                                        Series:PACSystem RX7i
Manufacturer:GE Fanuc
Part Number:IC698CPE010
Description:EX7i Central Processing Unit (CPU)
Location:Rx7i Rack
Random Access Memory (RAM):10 MB
Operating Voltage:5 to 12 Volts DC
Flash Memory:10 MB
Current Rating:3.4 Amps
Discrete I/O memory:32 K
Analog I/O memory:32 Kwords
No. of Program blocks:512 Program block
User Memory:10 Megabyte
Compatible Memory storage:SRAM, Flash
Maximum Program block size:128 KB
Max Program Block:512 Program Blocks
Processor speed:300 MHz


memory module



                                                        Brand:GE Fanuc
Series:Series 90-70
Part Number:IC697MEM717
Memory Capacity:64, 128, 256, and 512 Kbytes


memory module



                                                        Brand:GE Fanuc
Series:Series 90-70
Part Number:IC697MEM715
Battery Type:Lithium
Data Storage:Supported


discrete output module



                                                        Series:Series 90-70
Part Number:IC697MDL740
Required current:0.15 Amps
Number of outputs:16
Isolation voltage:1500 Volts
Rated voltage:24 to 48 Volts DC


Discrete input module



                                                        Series:Series 90-70
Manufacturer:GE Fanuc
Part Number:IC697MDL653
Rated voltage:24 Volts DC
No of Channels:Thirty-Two (32)
No. of groups:Four (4)
OFF-state current:0-2 mA
Required current:0.3 Amps
Nominal output voltage:24 VDC
Number of inputs per module:32
Isolation voltage:1500 Volts
Current draw:300 mA
Off–state Voltage:0-5 VDC
On–state Voltage:13.5 - 30 VDC


discrete output module



                                                        Series:Series 90-70
Part Number:IC697MDL350
Outputs:32
Output Current/Point:0.5 A
Output Current/Group:2 A
Current Required:0.5 A
Frequency:47-63 Hz


Input Module



                                                        Series:Series 90-70
Part Number:IC697MDL250
Number of Inputs:32
Input Current:10 mA
Required Current:0.35 A
Frequency:60 Hz


discrete input module



                                                        Series:Series 90-70
Part Number:IC697MDL240
Inputs:16 Isolated Inputs
Input Current:10 mA
Current Required:0.25 A
Frequency:60 Hz


CPU module



                                                        Series:Series 90-70
Manufacturer:Emerson Automation
Part Number:IC697CPX772
Product type:CPU module
RAM:512 kilobytes
Current input:3.1 Amps
Voltage input:5 Volts DC
NV-RAM:256 kilobytes
Clock speed:96 megahertz
Current draw:3.1 Amps
Voltage input:5 Volts DC
Analog I/O:8 K max
Serial ports:3
Maximum RAM:512 kilobytes


CPU module



                                                        Series:Series 90-70
Product Description:Single slot CPU
Part Number:IC697CPU782
Product type:CPU module
Discrete I/O memory:12 KB
Compatibility:GE Fanuc 90-70 PLCs
Analog I/O memory:8 KB
Clock speed:16 megahertz
Maximum RAM:512 kilobytes
Floating Point math:Supported
Current input:1.6 Amps
Serial port:1
Analog I/O:8 K max
Communication port:RS485 interface
Voltage input:5 Volts DC
Module location:slot 1 of rack 0


CPU Module



                                                        Series:Series 90-70
Part Number:IC697CPU772
Product type:CPU module
Voltage input:5 Volts DC
Current draw:1.2 Amps
Microprocessor:80C186
Serial port:1


Ethernet Controller



                                                        Manufacturer:GE Fanuc
Series:Series 90-70
Part Number:IC697CMM741
Memory Types:RAM, ROM
Number of LEDs:3


5-Slot Rack Rear Mount



                                                        Series:Series 90-70
Part Number:IC697CHS750
Current:20 Amperes
Voltage:5 Volts DC
Slots:5


Remote I/O scanner module



                                                        Series:Series 90-70
Manufacturer:Manufacturer
Slot width:Single slot
Product Description:Remote I/O scanner
Part Number:IC697BEM733
Application:GE fanuc IC66 Bus
Current draw:0.8 A
Location:IC697 PLC rack
Terminating Resistor values:75, 100, 120 or 150 Ohms
Description:Genius Remote I/O Scanner
Backplane Current:1.3 Amps
Operating Voltage:5.0 Volts DC


Bus Controller Module



                                                        Series:Genius Bus I/O
Part Number:IC697BEM731
Operating Voltage:5.0 Volt DC
Backplane Current:1.3 Amps
Bus Cable:Belden 9182 type cable
Module Width:Single Slot
Description:Genius I/O Bus Controller
Application:IC66 PLC System
Location:IC66 PLC Rack
Connectors:3PL and 1PL Ports
LED Indicators:3 LED Indicators
Average Weight:2.0 Pounds


Bus Transmitter module



                                                        Series:Series 90-70
Manufacturer:Emerson Automation
Part Number:IC697BEM713
Slot required:1
Voltage input:5 Volts DC
Compatibility:IC697 PLC
Current draw:1.4 Amps
Programmer interface:1
Voltage input:5 Volts DC
Expansion interface:1
Current input:1.4 Amps
