SR760
DISCONTINUED BY MANUFACTURER
FEEDER MANAGEMENT RELAY
W/AUTORECLOSE
PHASE CURRENT INPUTS - 5 AMP
ZERO SEQUENCE CURRENT INPUTS - 5 AMP
88-300 V DC
70-265 V AC
48/62 HZ
EIGHT 4-20 MA ANALOG OUTPUTS
BREAKER CLOSED LED - RED LED
NP104X905BA603
DISCONTINUED BY MANUFACTURER
KEYPAD PANEL
GE TURBINE CONTROL SYSTEM
45 X 35 X 32 CM
VME Communication Interface Card
Mark VI Speedtronic
VCMI card
VME Bus Master Controller
IONet connector
"TX," "RX," and "CD" are the labels on them
Printed circuit board
CIRCUIT BOARD
TURBINE CONTROL
2 PORTS
MARK VI
SPEEDTRONIC SERIES
IS200TRPGH2B
PC BOARD
FEATURES TWO LARGER TERMINAL BLOCKS
CPU MODULE
Series:PACSystem RX7i
Manufacturer:GE Fanuc
Part Number:IC698CPE020
Maximum Program block size:128 KB
User Memory:10 Megabyte
Processor speed:700 MHz
Application:Rx7i System
Media Redundancy:Supported via LAN 2
Random Access Memory (RAM):10 MB
Operating Voltage:5 to 12 Volts DC
Flash Memory:10 MB
Current Rating:4.3 Amps
Ethernet data rate:10Mb/sec and 100Mb/sec
Discrete I/O memory:32 K
Analog I/O memory:32 Kwords
No. of Program blocks:512 Program block
CPU Memory:10 Megabyte User Logic RAM
Processor type:Pentium III, 700 MHz
Rack mount CPU
Series:PACSystem RX7i
Manufacturer:GE Fanuc
Part Number:IC698CPE010
Description:EX7i Central Processing Unit (CPU)
Location:Rx7i Rack
Random Access Memory (RAM):10 MB
Operating Voltage:5 to 12 Volts DC
Flash Memory:10 MB
Current Rating:3.4 Amps
Discrete I/O memory:32 K
Analog I/O memory:32 Kwords
No. of Program blocks:512 Program block
User Memory:10 Megabyte
Compatible Memory storage:SRAM, Flash
Maximum Program block size:128 KB
Max Program Block:512 Program Blocks
Processor speed:300 MHz
memory module
Brand:GE Fanuc
Series:Series 90-70
Part Number:IC697MEM717
Memory Capacity:64, 128, 256, and 512 Kbytes
memory module
Brand:GE Fanuc
Series:Series 90-70
Part Number:IC697MEM715
Battery Type:Lithium
Data Storage:Supported
discrete output module
Series:Series 90-70
Part Number:IC697MDL740
Required current:0.15 Amps
Number of outputs:16
Isolation voltage:1500 Volts
Rated voltage:24 to 48 Volts DC
Discrete input module
Series:Series 90-70
Manufacturer:GE Fanuc
Part Number:IC697MDL653
Rated voltage:24 Volts DC
No of Channels:Thirty-Two (32)
No. of groups:Four (4)
OFF-state current:0-2 mA
Required current:0.3 Amps
Nominal output voltage:24 VDC
Number of inputs per module:32
Isolation voltage:1500 Volts
Current draw:300 mA
Off–state Voltage:0-5 VDC
On–state Voltage:13.5 - 30 VDC
