Operating Panel

Display:2-line LCD with backlight
Control Keys:Navigation keys + Start/Stop/Jog buttons
Operating Voltage:24V DC
Power Consumption:≤ 5 W

Binary Input Module

Input Channels:16x
Input Voltage:24/48/110/125V DC
Input Threshold (ON);>60% of rated voltage
Input Current :3–8 mA
Response Time:<5 ms
Isolation:2.5 kV AC
Power Consumption:≤ 4 W

Relay Control module

Number of Channels: 8 independent channels
Number: 6 dedicated
Contact Rating: 24 V DC / 30 mA
Voltage: +24 V DC nominal
Power Consumption: < 5 W

GCOM Communication Interface

Power Consumption: 1.5 - 2.5 W
Isolation:500 V AC (ports to backplane)
ESD Protection:±15 kV (IEC 61000-4-2)

Industrial Control Module

Input Channels:16 (Grouped as 8+8)
Input Voltage:24 V DC (Nominal)
Voltage Range:19–30 V DC (Logic "1": ≥15 V)
Logic "0" Threshold:≤5 V DC
Input Current:6 mA per channel (typical)
Isolation:500 V AC (channel-to-channel)
Backplane Power :5 V DC (via P4 baseplate)

Transmitter Controller

Function:8-channel analog input (4-20mA)
Input Channels:8 (isolated)
Signal Range:4-20mA
Input Impedance:250 Ω
Accuracy:±0.1% FS (at 25°C)
HART Support:FSK modulation (1200/2200Hz) via same wires
Power Supply:24 V DC loop power
Isolation :500 V AC

Transmitter Controller

Functions:4x 4-20mA Input
Signal Range :4-20mA
Accuracy:±0.05% FS (23°C)
Loop Power:24 V DC
Isolation:500 V AC (channel-to-bus)
Max Devices:16 per segment
Power:9–32 V DC

Control Board

Hardware Generation:G4 (4th Gen)
Status:Discontinued (since ~2003)
Replacement:AC 800M Controller Series
Memory:4 MB DRAM + 2 MB Flash
Backup Battery:3.6 V Li (BR2325) for RAM retention
Cycle Time:≤100 ms
I/O Capacity:Up to 1024 I/O points
Supply Voltage:24 V DC ±10%
Power Consumption:15 W (max)

Control Board

Memory:2 MB SRAM
Profibus DP Ports:2x RS-485
Baud Rate:9.6 kbps – 12 Mbps
Max Devices:124 slaves per segment
Supply Voltage:5 V DC ±5% (via backplane)
Power Consumption:8 W max
Isolation:500 V AC (field-to-logic)
