ALL MANUFACTURERS

IGITAL OUTPUT MODULE

DRIVE BOARD
RESISTIVE NETWORK
STATUS LED INDICATORS
YT204001-FK
Number of Channels: Typically 4 or 8
Switching Capacity: Up to 2A per channel
Supply Voltage: 24V DC
Isolation Voltage: 1500V AC
Response Time: <1ms

Digital I/O card

Input Voltage:24V DC nominal (15-30V range)
Input Current :3-5mA per point
Output Type:Relay (Form C) or Solid State
Output Rating:2A @ 30V DC
Isolation Voltage:1500V AC
Response Time:<1ms (input)

INTERCONNECTOR

Contact Configuration:96-position (48x2 rows)
Contact Material:Gold-plated copper alloy
Current Rating:1A per contact (max)
Voltage Rating:60V DC max
Contact Resistance:<20mΩ (initial)
Insulation Resistance:>100MΩ @500V DC
Mating Cycles: >500 insertions

Industrial Control Board

Supply Voltage:24V DC ±10%
Power Consumption:15W (max)
Isolation Voltage:1500V AC (I/O to logic)
ESD Protection:±8kV (contact discharge)
Processor: 32-bit RISC-based
Memory: 16MB Flash,
I/O Capabilities:8x digital inputs (24V DC)

Industrial Control Board

Supply Voltage:24V DC ±10%
Power Consumption:20W (typical)
Processor:32-bit DSP (200MHz)
Memory:16MB Flash, 8MB RAM
Isolation Voltage:1500V AC (I/O to logic)

Advanced Control Module

Processor:Dual-core PowerPC @ 1.2GHz
Memory:2GB DDR3 RAM + 4GB Flash
Control Loops:Up to 256 PID loops
Scan Time:0.1ms (minimum)
Task Capacity:32 parallel tasks
Legacy Protocols: PROFIBUS-DP
Max Expandable I/O: 1024 points
High-speed analog:±10V/4-20mA

Communication Interface Module

Supply Voltage:24V DC ±10%
Power Consumption:8W (typical), 12W (max)
Isolation:2500V AC (port-to-port)
ESD Protection:±8kV (contact discharge)
Ethernet Ports:2x 10/100BASE-TX (RJ45)
Serial Interfaces:2x RS-485 (isolated)
Protocol Support:PROFIBUS DP-V1
Data Rate:Up to 12Mbps

Control Module

Supply Voltage:24V DC ±10%
Power Consumption:15W (typical), 25W (max)
Isolation Voltage:1500V AC
ESD Protection:±8kV
Control Loops: Up to 512 PID loops
Execution Time: 0.1ms for basic instructions
Task Capacity: 64 parallel tasks
Memory Cycle Time: <10ns

Current Voltage Input Module

Pulse Amplification Board

Input Voltage Range:10mV - 30V AC/DC
Input Impedance:100kΩ (typical)
Output Signal:24V transistor / 0-20mA
Output Current:≤500mA (transistor), ≤20mA (analog)
Isolation Voltage:1500V AC
High-gain amplifier: 10-100x adjustable
Wide input range: 10mV to 30V pulses
Frequency response: DC to 500kHz
Isolated output: 24V PNP/NPN or 0-20mA

Procontrol System Coupling Module

Voltage: 24 VDC (±15%) or 110–240 VAC
Power Consumption: 5–10 W
Operating Temperature: -20°C to +60°C.
Humidity: 5–95% non-condensing.

Control Board

Analog I/O update rate: 1 kHz
Digital I/O update rate: 10 ms
Standard range: -20°C to +60°C
Extended range: -40°C to +70°C
Power consumption: Max. 10W
Humidity: 5% to 95% RH
16-bit resolution for analog inputs/outputs

CONVERTER PULSE BOARD

Input Voltage Range:5-30V DC (HTL)
Input Frequency:0-500kHz
Output Signal:Differential (RS422) or single-ended
Output Current:20mA max
Power Supply:24V DC ±10%
Power Consumption:5W typical
Resolution: Up to 4096 pulses/revolution
Signal Delay: <100ns

FIELD PROTECTION UNIT

Operating Time:<8ms for critical faults
Measurement Accuracy:±0.5% of reading
Sampling Rate:64 samples/cycle
Time Sync Accuracy:±1μs
Power Supply:48-125V DC or 90-264V AC
Power Consumption:15W typical
Isolation Voltage:2.5kV AC

LCDC Module

Supply Voltage: 24 VDC (±10%)
RS-232/RS-485 serial interface
Relay Outputs:0-24 VDC
Operating Temperature: 0°C to 55°C
Humidity: ≤95% non-condensing

I/O module

16 digital inputs (24V DC)
Configurable as sinking/sourcing
3ms debounce filtering
Channel-by-channel LED status
Voltage Range:5-30V DC
Current:3mA typical
Isolation:1500V AC

I/O Module

Analog Input :4-20mA/0-10V
Analog Output:4-20mA/0-10V
Digital Input:24V DC
Digital Output:24V DC, 0.5A
Resolution:16-bit
Accuracy:±0.1% of span
Input Impedance:250Ω
Input Voltage:24V DC (15-30V range)
Output Current:0.5A max per channel
Response Time:<1ms
Backplane Interface: Redundant S800 I/O bus
Update Rate: 10ms (all channels)

Mini Contactor Relay

Rated Current (Ie):6A (AC-1)
Rated Voltage (Ue):230V AC / 24V DC
Breaking Capacity:3A @ 400V AC (AC-3)
Contact Material:Silver alloy (AgSnO₂)
Coil Voltage:24V DC / 48V DC / 110V AC / 230V AC (selectable)
Power Consumption:2.2W (DC) / 3.5VA (AC)
Operate Time:≤15ms (DC), ≤20ms (AC)
Release Time:≤10ms (DC), ≤15ms (AC)

83SR06E Binary and Analog Control Module

Overload (49):20-100% of In
Short Circuit (50):2-15×In
Phase Loss (46):Fixed/Adjustable
Ground Fault (51G):20-40% of In
Rated Current (In):6A (CT 5-100A)
Control Voltage:24-240V AC/DC
Contact Rating:5A @ 250V AC (resistive)
Communication:RS-485

Analog Output Module

Accuracy:±0.1% of span
Galvanic isolation:1500V AC channel
Range:4-20mA / 0-20mA
Resolution:16-bit
Load Capacity:≤750Ω
Update Rate:10ms per channel
Power Supply:24V DC ±10%
Power Consumption:5W (max)
Isolation Voltage:1500V AC

81EU01 Universal Input Module

81EU01 Input Module universal
16 fold for Binary and Analog Transmitters
ValueUnavailable
16 Channels

Analog Output Module

Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel
Power Supply:24V DC ±10%
Isolation:1500V AC

Control Module

Channels:16
Voltage/Current:24V DC, 0.5A
Isolation:1500V AC
Response Time:<1ms
Power Supply:24V DC ±10%
Power Consumption:8W (typical)

83SR11E Module

Power Supply:24V DC ±10%
Power Consumption:6W (typical)
Isolation:1500V AC
Range:4-20mA / 0-20mA
Resolution:16-bit
Accuracy:±0.05% of span
Load Capacity:≤750Ω
Update Rate:5ms per channel
