Expansion I/O base

12 Slot Extension Base
Model Number:2MLR-E12P
Type:Expansion I/O Base Unit
Input Voltage:24V DC (18-36V range)
Power Consumption:5W (typical), 8W (max)
Backplane Current:1.5A (max)
Isolation:1500V DC

ExpansionI/O Base

I/O Base for 8 module installation
Base for 8 module installation
Power Supply:Backplane-powered from main base
Current Capacity:12A distributed
Isolation :1500V AC (channel-to-channel)
Backplane:100Mbps high-speed communication

Main CPU Base

Model Number:2MLB-M06A
Type:6-Slot Main Base Unit
Power Distribution:10A max
Isolation:1500V AC (slot-to-slot)
Connector Type:High-density 96-pin

Main CPU Base

CPU base
for 2 module installation
Model Number:2MLR-M02P
Type:2-Slot Main Base Unit
Backplane Current:8A max (shared)
Isolation:1500V AC (slot-to-slot)
Connector Type:High-density 48-pin
Power Distribution:24V DC

POWER SUPPLY

POWER SUPPLY
REDUNDANT POWER DC24V
7.5A

Power modules

8.5A, Voltage (110V)
POWER SUPPLY MODULE
REDUNDANT POWER
100-120 VAC POWER
8.5 AMP
MASTER LOGIC L200R SERIES

Power modules

5.5A, Voltage (220V)
I/O interface module
LOGIC CONTROLLER
PROGRAMMABLE
MASTERLOGIC-200
REDUNDANT POWER SUPPLY
5.5 AMP
200-240 VAC

Power modules

LOGIC CONTROLLER
PROGRAMMABLE
REDUNDANT POWER SUPPLY
5.5 AMP
110 V

CPU modules

CPU MODULE
MASTERLOGIC-200
128 K STEP
16MB BUILT IN FLASH MEMORY
2MB DATA MEMORY
7MB PROGRAM MEMORY

CPU modules

Number ofInstructions Operator:18
Basic function block:41
ProcessingSpeed LD:0.042µs/step
MOV  :0.126µs/step
Program Memory Capacity:10 MB
Max No of I/O Bases:31
Max No of Slots:372

CPU modules

High speed CPU module
(Fully Redundant system)
Master,Fiber Optic
(Max. I/O point: 23,808 points)
Current consumption (mA):1360

Extension Baseboard Terminator

Extension Baseboard Terminator
Must use for non redundant base expansion
(Resistance)
Termination Type:Passive resistive
Resistance:120Ω ±1%
Power Rating:0.5W
Contact Material:Gold-plated copper alloy

Dummy module

Dust protection module for unused slot
DUMMY MODULE
MASTERLOGIC-200 SERIES
DUSTPROOF
FOR EMPTY I/O SLOTS

Expansion I/O cable

Length:15.0 meters
Fiber Count:2 fibers (1 Tx, 1 Rx)
Wavelength:850nm/1300nm
Bandwidth:4700MHz·km @850nm
Attenuation:≤3.0dB/km @850nm
Optical Power:-20dBm to -3dBm

Expansion I/O cable

Length:10.0 meters
Connectors:36-pin HD (male/female) with keying
Cable Diameter:10.5mm ±0.5mm
Conductors:20 AWG OFC
Impedance:100Ω ±3%
Voltage Rating:60V DC / 30V AC
Current Capacity:3A per conductor
Capacitance:≤40pF/m

Expansion I/O cable

Length:5.0 meters
Bend Radius:≥60mm
Conductors:22 AWG stranded tinned copper
Shielding:Triple-layer
Impedance:100Ω ±5%
Voltage Rating:60V DC / 30V AC RMS
Current Rating:2A per conductor
Capacitance:≤45pF/m

ExpansionI/O cable

Model Number:2MLC-E301
Type:Long-Distance Expansion I/O Cable
Length:3.0 meters
Connectors:High-density 36-pin
Cable Diameter:9.2mm ±0.3mm
Jacket Material:Polyurethane
Bend Radius:50mm minimum

ExpansionI/O cable

Model Number:2MLC-E121
Type:Expansion I/O Interconnect Cable
Length:1.2 meters
Connector Type A:High-density male (main base side)
Connector Type B:High-density female (extension side)
Cable Diameter:8.5mm ±0.3mm
Jacket Material:Oil-resistant PVC (UL94 V-0)
Bend Radius:≥40mm

ExpansionI/O cable

Model Number:2MLC-E061
Type:Expansion I/O Interconnect Cable
Length:0.6 meters (600mm)
Connector A:High-density male (main base side)
Connector B:High-density female (extension side)
Cable Type:Shielded twisted pair (STP)
Jacket Material:Flexible PVC (oil-resistant)
Bend Radius:≥35mm

ExpansionI/O cable

Totalexpansiondistanceshould notexceed15m
Model Number:2MLC-E041
Type:Expansion I/O Interconnect Cable
Length:0.4 meters (400mm)
Connector A:High-density male (main base side)
Connector B:High-density female (extension side)
Cable Type:Shielded twisted pair (STP)
Jacket Material:Flexible PVC (oil-resistant)
Bend Radius:≥30mm

12-slot Extention Rack

Model Number:2MLB-E12A
Type:12-Slot High-Density Extension Base Unit
Material Industrial:Polymer Composite
Slot Configuration:12 expansion slots
Power Distribution:18A max
Isolation :2000V AC
Backplane Voltage:5V DC, 24V DC
Power Consumption:8W

8-slot Extention Rack

Model Number:2MLB-E08A
Type:8-Slot Extension Base Unit
Mounting:Heavy-duty DIN Rail (35mm)
Slot Configuration:8 expansion slots
Current Capacity:12A max distributed power
Isolation :1500V AC
Connector System:Gold-plated high-density contacts
Backplane Voltage:5V DC, 24V DC

6-slot Extention Rack

Model Number:2MLB-E06A
Type:6-Slot Extension Base Unit
Backplane Current:8A max
Isolation:1500V AC

4-slot Extention Rack

Model Number:2MLB-E04A
Type:4-Slot Extension Base Unit
Slot Capacity:4 expansion modules
Power Supply:Backplane-powered
Backplane Current:5A max
Isolation :1500V AC

12-slot Main Base Unit

Model Number:2MLB-M12A
Type:12-Slot Modular Base Unit
Input Voltage:24V DC (±10%)
Power Distribution:15A max backplane current
Isolation:2000V AC (channel-to-channel)
Power Consumption:6W (base unit only)
Connector System:Gold-plated high-reliability contacts
