Softstarter

Type:Thyristor-Based Soft Starter
Rated Current:142 A
Motor Power (400V):75 kW
Input: 208–690V AC (±10%), 50/60 Hz
Control Circuit: 100–250V AC/DC
Current Limit: Adjustable (200–500% I_e)
Pump Stop: Anti-water-hammer control

Control Card

Power Supply:24V DC
Voltage: 15–30V DC
Current: 3–8 mA
Rating: 2A @ 250V AC
Resolution: 10-bit
Load Impedance: ≥500Ω (voltage)
Baud Rate: 9600–115200 bps
Isolation:1500V AC

SPEED UP UNIT

Input Voltage:24 V DC
Power Consumption:≤ 8 W
Torque Response: ≤ 2 ms
Accel/Decel Rates: Up to 3x faster vs
Overload Capability: 200%
Type:Dynamic Performance Module

Analog Input Board

Power Supply:24V DC (±10%)
Power Consumption:≤ 4 W
Voltage: 0–10V
Current: 0–20mA
Resistance: Pt100/Pt1000 RTDC
Resolution:16-bit
Sampling Rate：10 ms/channel
Voltage: ≥1 MΩ
Current: 250Ω ±0.1%
Channel-to-Channel: 300V AC
Channel-to-Backplane: 1500V AC

ANALOG INPUT BOARD

Power Supply:24V DC (±10%)
Power Consumption:≤ 3 W
Input Channels:8x Isolated Voltage Inputs
Resolution:16-bit
Accuracy:±0.1% of FS (Full Scale) at 25°C
Input Impedance ≥1 MΩ
Sampling Rate:10 ms/channel
Channel-to-Channel: 300V AC
Overvoltage Protection:±30V continuous

Analog Input Module

Overload Protection:±30V (voltage)
Power Supply:24V DC
Power Consumption:≤ 1.5 W
Input Channels:4x Isolated Channels
Voltage: 0–10V, ±10V, 0–5V
Current: 0–20mA, 4–20mA
Resolution:12-bit
Sampling Rate:2 ms per channel
Voltage: ≥100 kΩ
Isolation:1500V AC

DIGITAL INPUT CIRCUIT BOARD

Type:8-Channel Isolated
Sink/Source: Auto-detecting
Voltage Range: 15–30V DC
Input Current 3–8 mA
Response Time:≤ 2 ms
Isolation:1500V AC
Power Supply:24V DC
Power Consumption:≤ 1.8 W

Digital Output Module

Output Signal: 24V DC
Load Current per Channel:0.5A to 2A
Max Switching Voltage: 30V DC
Isolation Voltage: 500V AC/DC
Response Time: <1ms

CURRENT FEEDBACK BOARD

Supply Voltage:24V DC
Current Input :3-phase AC
Isolation Voltage:2500V AC
Frequency Range:0–500 Hz

Industrial Circuit Board

Power Supply:24V DC
Analog Inputs: 4-20mA
Digital I/O: Opto-isolated inputs
Communication: Possible RS-485/Modbus
Type: Industrial control

IGITAL OUTPUT MODULE

DRIVE BOARD
RESISTIVE NETWORK
STATUS LED INDICATORS
YT204001-FK
Number of Channels: Typically 4 or 8
Switching Capacity: Up to 2A per channel
Supply Voltage: 24V DC
Isolation Voltage: 1500V AC
Response Time: <1ms

Digital I/O card

Input Voltage:24V DC nominal (15-30V range)
Input Current :3-5mA per point
Output Type:Relay (Form C) or Solid State
Output Rating:2A @ 30V DC
Isolation Voltage:1500V AC
Response Time:<1ms (input)

INTERCONNECTOR

Contact Configuration:96-position (48x2 rows)
Contact Material:Gold-plated copper alloy
Current Rating:1A per contact (max)
Voltage Rating:60V DC max
Contact Resistance:<20mΩ (initial)
Insulation Resistance:>100MΩ @500V DC
Mating Cycles: >500 insertions

Industrial Control Board

Supply Voltage:24V DC ±10%
Power Consumption:15W (max)
Isolation Voltage:1500V AC (I/O to logic)
ESD Protection:±8kV (contact discharge)
Processor: 32-bit RISC-based
Memory: 16MB Flash,
I/O Capabilities:8x digital inputs (24V DC)

Industrial Control Board

Supply Voltage:24V DC ±10%
Power Consumption:20W (typical)
Processor:32-bit DSP (200MHz)
Memory:16MB Flash, 8MB RAM
Isolation Voltage:1500V AC (I/O to logic)

Advanced Control Module

Processor:Dual-core PowerPC @ 1.2GHz
Memory:2GB DDR3 RAM + 4GB Flash
Control Loops:Up to 256 PID loops
Scan Time:0.1ms (minimum)
Task Capacity:32 parallel tasks
Legacy Protocols: PROFIBUS-DP
Max Expandable I/O: 1024 points
High-speed analog:±10V/4-20mA

Communication Interface Module

Supply Voltage:24V DC ±10%
Power Consumption:8W (typical), 12W (max)
Isolation:2500V AC (port-to-port)
ESD Protection:±8kV (contact discharge)
Ethernet Ports:2x 10/100BASE-TX (RJ45)
Serial Interfaces:2x RS-485 (isolated)
Protocol Support:PROFIBUS DP-V1
Data Rate:Up to 12Mbps

Control Module

Supply Voltage:24V DC ±10%
Power Consumption:15W (typical), 25W (max)
Isolation Voltage:1500V AC
ESD Protection:±8kV
Control Loops: Up to 512 PID loops
Execution Time: 0.1ms for basic instructions
Task Capacity: 64 parallel tasks
Memory Cycle Time: <10ns

Current Voltage Input Module

Pulse Amplification Board

Input Voltage Range:10mV - 30V AC/DC
Input Impedance:100kΩ (typical)
Output Signal:24V transistor / 0-20mA
Output Current:≤500mA (transistor), ≤20mA (analog)
Isolation Voltage:1500V AC
High-gain amplifier: 10-100x adjustable
Wide input range: 10mV to 30V pulses
Frequency response: DC to 500kHz
Isolated output: 24V PNP/NPN or 0-20mA

Procontrol System Coupling Module

Voltage: 24 VDC (±15%) or 110–240 VAC
Power Consumption: 5–10 W
Operating Temperature: -20°C to +60°C.
Humidity: 5–95% non-condensing.

Control Board

Analog I/O update rate: 1 kHz
Digital I/O update rate: 10 ms
Standard range: -20°C to +60°C
Extended range: -40°C to +70°C
Power consumption: Max. 10W
Humidity: 5% to 95% RH
16-bit resolution for analog inputs/outputs

CONVERTER PULSE BOARD

Input Voltage Range:5-30V DC (HTL)
Input Frequency:0-500kHz
Output Signal:Differential (RS422) or single-ended
Output Current:20mA max
Power Supply:24V DC ±10%
Power Consumption:5W typical
Resolution: Up to 4096 pulses/revolution
Signal Delay: <100ns

FIELD PROTECTION UNIT

Operating Time:<8ms for critical faults
Measurement Accuracy:±0.5% of reading
Sampling Rate:64 samples/cycle
Time Sync Accuracy:±1μs
Power Supply:48-125V DC or 90-264V AC
Power Consumption:15W typical
Isolation Voltage:2.5kV AC
