ALL MANUFACTURERS

Remote MultipurposeInput/Output

REMOTE MULTIPURPOSE I/O MODULE
INPUT 24 VDC
2X9 PIN MALE D-SUB
32 I/O CHANNELS
DIGITAL/ANALOG INPUT
DIGITAL/ANALOG OUTPUT
1000 MS
25 OHM/WIRE
DIN RAIL MOUNT
(306712)

AC Motor Drive Inverter

DRIVE INVERTER
3.5 AMP
3 PHASE
380-500 V AC
50/60 HZ
1.5 KW
(18215033)

Feeder Distribution Protection Relay

Ambient Storage
Temperature Range -40°F to +176°F
Frequency 25 to 60 Hz nominal
Insulation Voltage 300 V
Manual 1601-0120-AE
Operating Temperature Range -40°F to +140°F

PROFIBUS Master Station

VME-PROF-M
PROFIBUS Master Station
A24, D16 Slave
64KB Dualport-RAM
128 KB RAM
512 KB Bootblock Flash EPROM

Universal Variable Speed AC Drive

10 HP/7.5 KW 380V to
Inverter 380
480V ±10%
3PH 9.5A
Position control/Digital lock
Programmable logic functions
Two programmable thresholds
Mains dip ride through
Frequency slaving
Catch a spinning motor
Eight preset speeds/accelerations/decelerations

AC inverter

Control Techniques Unidrive
Classic 4kW
Inverter 380...480V AC
3PH 9.5A
Position control/Digital lock
Programmable logic functions
Two programmable thresholds
Mains dip ride through
Frequency slaving
Catch a spinning motor
Eight preset speeds/accelerations/decelerations
Injection and dynamic breaking

PSR-SCP-24DC/ESP4/2X1/1X2 Universal Safety Relay

Level Control Transmitter

Measurement Principle: Guided Wave Radar
Measurement Range: Up to 30 meters (98.4 feet)
Accuracy: ±3 mm (±0.12 inches)
Resolution: 1 mm (0.04 inches)
Process Temperature Range: -196°C to 450°C (-320°F to 842°F)
Process Pressure Range: Up to 100 bar
Power Supply: 12-28 VDC
Current Consumption: Typically 20 mA

Shunt Module

SKKR30002BVRSUB
SEMITRANS; 200V; 300A
Low inductance value
Excellent long term stability
Isolated copper baseplate usingDCB
(Direct Copper Bonding)Technology
Large clearance (13 mm) andcreepage distance (20 mm)
Using BVR Shunts forextended lifetime

EPC50 OP Board

Output module

Number of outputs 16, electrically connected
Short circuit protection yes
Total current per module 8 A on 100 % duty cycle
Voltage drop ≤ 0,3 V at 0,5 A
Internal currentconsumption(from V+ bus)0 mA
External currentconsumptionLoad current
Operating mode Source operation
Voltage range 10…32 VDC, smoothed,max. 10 % residual ripple
