Control board card

HIEE300888R0002
UAC389 AE02
Pulse Amplifier Interface module

IGBT Module

Rated Voltage (V_CEO): 600 V
Collector Current (I_C): 60 A (continuous)
Peak Collector Current (I_Cpeak): 120 A (pulsed)
Gate-Emitter Threshold Voltage (V_GE(th)): 4.0 V (typical)
Input/Output Signal Voltage: 15 V / 15 V
Max Power Dissipation (P_diss): 200 W (maximum)

Processor Module

MEASUREMENT UNIT BOARD

HIEE300890R0001
LD MUB-01
UAC383 AE01
MEAS. UNIT BOARD

Power Adapter Terminal Assembly

Power Input:24V DC
Current Capacity:5A max
Operating Temperature:
-10°C to 60°C (14°F to 140°F)
Storage Temperature:
-40°C to 85°C (-40°F to 185°F)
Humidity Tolerance:5% to 95% non-condensing

Five-slot File Power Supply

TDC 3000
Five-slot File Power Supply
Chassis Power Supply
CE-compliant
Standard 3-pin connector

Digital I/O Module

Number of I/O channels  64-channel input
Signal isolation Common every 16-channel
Input contact rating 5 V DC, 20 mA or more
Input response time  8 ms (for status input)
Maximum currentconsumption 800 mA (5 V DC)
External connection  Dedicated cable (KS9)
Compatible card  ST6 compatible

Analog Output Baseplate

Current Output: 4–20 mA
Voltage Output: Optional 0–10 V DC
Typically ±0.1% of full scale
Current Output: 750 Ω (4–20 mA)
Voltage Output:  ≥ 1 kΩ (0–10 V)
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
