Allen-Bradley

PowerFlex 40 AC Drive

Input Voltage:380-480VAC
Rated Current output:17.0 A
Rated Power:7.5 kW (10.0 HP)
Installation:Panel Mount
Enclosure Rating:IP20 / NEMA UL Type Open
Keypad:LED Keypad
Voltage:480 Volts AC
Enclosure:Panel Mount - IP20, NEMA/UL Type Open
Horsepower:10 Horsepower
Amperage:17.0 Amps

Power Flex Drive

22AD6P0N104
AC DRIVE
POWERFLEX 4
480 VAC
3 PHASE
6 AMPS
2.2 KW
3 HP
FRAME SIZE B
IP20 (OPEN)
LED DISPLAY
FIXED DIGITAL KEYPAD
NO CE COMPLIANT FILTER
RS485
Country of Origin: China

Servo Drive

SERVO DRIVE
KINETIX 5500
230 VAC 1-/3-PHASE INPUT
480 VAC 3-PHASE INPUT
24 VDC CONTROL INPUT
12.5 AMP PEAK CURRENT OUTPUT

Kinetix 5500 Servo Drive

Continuous Output Current (0-peak):3.5 A
Product Category:Kinetix 5500
Continuous Output Current (rms):2.5 A
Peak Output Current (0-peak):8.8 A
Peak Output Current (rms):6.25 A
Velocity Loop:300 Hz
Current Loop:1000 Hz
Efficiency:0.97
Short-circuit current rating:200,000 A (rms) symmetrical
Internal shunt power:30 W

Communication Adapter

Voltage:400V AC
Ph:3
Amps:1.3
kW(Hp):0.37 (0.5)
Frame:A
Communication Protocol :RIO / DH+
Data Rate:57.6 Kbps, 115.2 Kbps, or 230.4 Kbps
No. of connections:32 nodes
Drive Power consumption:250 mA at 5V DC supplied by the host drive
Operating Temperature:-10…50 °C (14…122 °F)
Storage:-40…85 °C (-40…185 °F)
Relative Humidity:5…95% non-condensing

Servo Drive

2098DSD020SE
SERVO DRIVE
ULTRA 3000 DIGITAL
2 KW
10-30 AMP
100-240 VAC
50/60 HZ
12/24 VDC SUPPLY
WITH SERCOS INTERFACE

Servo Drive

Input Frequency:48…62 Hz
Main AC input current, Nom (rms):7.9 A
Main AC input current, Nom (0-pk):22.6 A
Control power back-up input voltage:20…26V DC
Control power back-up input current, nominal:500 mA
Control power back-up input current, max. inrush:30 A
Peak output current (0-pk):25.5 A
Continuous power output:3.00 kW
Continuous Output Current (0-peak):8.5 Amperes
Power Rating:3.0 kWatts

Indexing Servo Drive

Product Bulletin:2097 Kinetix 300 Drives
Input Frequency:48…62 Hz
Main AC input current, Nom (rms):7.9 A
Max inrush:22.6 A
Drive Voltage:480 Volts
Continuous Output Current (0-peak):8.5 Amperes
Power Dissipation:99 Watts

Indexing Servo Drive

Drive Voltage:480 Volts (Three Phase)
Input Frequency:48…62 Hz
Output current:5.7 A
Output power:2.0 kW
Communication port:One (1) Ethernet port
Safe Torque Off (STO):Integrated
Mounting Panel Mount
Torque Value;5.0-7.0 lb*in (0.56-0.79 N*m)

Servo Drive

Control power back-up input voltage:20…26V DC
Control power back-up input current, nominal:500 mA
Control power back-up input current, max. inrush:30 A
Continuous output current (rms):4.0 A
Continuous output current (0-pk):5.7 A
Peak output current (rms):12.0 A
Peak output current (0-pk):17.9 A
Continuous power output:1.0 kW
Overvoltage:430 VDC
Input Frequency:48…62 Hz
Continuous output current (rms):4.0 A
Continuous power output:1.00 kW

EtherNet/IP Safe Torque-Off Control Module


SERVO DRIVE CONTROL MODULE
MULTI-AXIS
KINETIX 6500
INPUT: 2.5-24 VDC
OUTPUT: 5-24 VDC
0.60 AMP
SAFE SPEED MONITOR
SAFE OFF
ETHERNET/IP NETWORK
COMMON INDUSTRIAL PROTOCOL MOTION

POWER MODULE

POWER MODULE
KINETIX 6200 / 6500 AXIS MODULE
1.8 KW
4 AMP
360-480 VAC
50/60 HZ

Axis Module

AXIS MODULE
KINETIX 6000
GUARDMOTION
460 VAC
13.5 KW
30 AMP INVERTER
WITH SAFE TORQUE-OFF FEATURE

Integrated Axis Module

INTEGRATED AXIS MODULE
KINETIX 6000 SERIES
380 / 460 VAC
15 KW / 23 AMP CONVERTER
6.6 KW / 15 AMP INVERTER
WITH SAFE TORQUE-OFF FEATURE

Integrated Axis Module

INTEGRATED AXIS MODULE
KINETIX 6200 / 6500
360 / 480 VAC
15 KW / 23 AMP CONVERTER
6.6 KW / 14.6 AMP INVERTER
WITH SAFE TORQUE-OFF FEATURE

Power Supply - 3A

POWER SUPPLY
FLEX I/O
INPUT: 120/230 VAC / 0.62/0.42 AMP (50/60 HZ)
OUTPUT: 24 VDC / 1.3 AMP
31.2 W
DIN RAIL MOUNTABLE

Isolated Analog Output Module

Update Rate:2.5/5.0 ms all channels
Conversion Type:Digital to Analog Converter
Resolution:15 bits plus sign
Product Description:Flex IO High Output Module
No. of outputs: Four (4) Isolated
Output type:4-20 mA, 0-20 mA and ±10VDC; 0-10VDC; +/- 5VDC and 0-5VDC
Voltage Resolution:0.320 mV/cnt
Current resolution:0.656 mA/cnt
Step response to 63% of full scale < 25 s
External DC supply, nom:24V DC
External DC supply range:19.2…31.2V DC (includes 5% AC ripple)
Mounting:DIN Rail

Analog Input Module

External DC supply, nom:24V DC
Operating Temperature:0 to 55 C (32 to 131 F)
Storage Temperature:–40…85 °C (–40…185 °F)
Vibration: 5g @ 10 to 500 Hz
Operating Shock:30 g
Thermal dissipation, max:6.8 BTU/hr @ 31.2V DC
Power dissipation, max:2.0 W @ 31.2V DC
Product Type:Flex I/O Isolated Input Analog Module
Inputs:4 Isolated
Resolution:16 bits

Analog Input Module - HART

1794IE8H
INPUT MODULE
FLEX I/O
ANALOG
CURRENT OR VOLTAGE
8 CHANNELS SINGLE ENDED INPUT
HART CAPABILITY
OPEN STYLE
DIN MOUNT
IP20

Flex I/O Combination Module

Flex I/O Combination Module
24V DC
10 Sink Inputs
6 Source Outputs

NETWORK ADAPTER

NETWORK ADAPTER
FLEX I/O
ETHERNET/IP
DUAL MEDIA
EXTENDED TEMPERATURE -20 TO +70 DEG
24 VDC
OPEN STYLE
DIN MOUNT
IP20

Block I/O Module

179132A0
DISCONTINUED BY MANUFACTURER 06/30/2015
BLOCK I/O INPUT MODULE
120V AC
32 POINT (32 INPUT)
PLC BLOCK I/O
.15AMP
120VAC
32 POINT MODULE (32 INPUT)
Tariff Code: 8538903000
Country of Origin: United States

DeviceNet Daughtercard

Processor Module

1785LT
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
PLC-5/15
6 K WORD
SRAM DH/RIO
2.5 AMP
5 VDC
Country of Origin: United States

CPU PROCESSOR MODULE

1785L80E
CPU PROCESSOR MODULE
PLC-5/80E
100K WORD SRAM
ETHERNET
(2) DH+/REMOTE I/O
RS-232-C / 422-A / 423-A
