Bently Nevada

Vibration Transmitter

05 0-5 mils pp (0-125 μm pp)
03 DIN clips and screws
CNCSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

I/O Module

Description: I/O Module
Compatibility: 3500 Series
Analog Inputs: 4–20 mA, 0–10 V
Power Supply: 24 VDC
Operating Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity Tolerance: Up to 95% non-condensing

Condition Monitoring System

Input Power Min: 18 Vdc Max: 36 Vdc
Current Max: 1.7 A
InrushCurrentMax: 2.7 A, less than 5 ms
Max: 12 dynamic signals and 2 Keyphasorsignals
DynamicRange110 dB @ fs = 102.4 ksps
Signal/NoiseRatio110 dB @ fs = 102.4 ksps
A/DConversionSigma-Delta 24 bits nominal
Bandwidth 0 to 40 kHz

3300 XL Proximitor Sensor

52 5.0 meters (16.4 feet) system length
no mounting hardware
05 CSA, ATEX, IECEx Approvals

3300 XL NSv Proximitor Sensor

70 7.0 meters (23.0 feet) systemlength
panel mount
05 Multiple approvals
3300 XL NSv Proximitor Sensor

3300 XL 8 mm Reverse Mount Probes

Total length option : 10 = 1.0 metre (3.3 feet)
Connector option : 02 = Miniature ClickLocTM coaxial connector
Agency approval option : 00 = Not required
Probe tip material : Polyphenylene sulfide (PPS).
Probe case material : AISI 303 or 304 stainless steel (SST).

Proximitor Sensor

Replaces 3300 RAM
Transducer Systems
and 3000-Series or 7000-Series
190 Transducer System
Average Scale Factor of
7.87 V/mm (200 mV/mil)
