Bently Nevada

I/O Module

135489-04
I/O Module With
Internal Barriers
And Internal Terminations

Vibration Transmitter

0 4 0-4 mils pp (0-100 μm pp)
5 0 5.0 metres (16.4 feet)
0 2 Bulkhead screws
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

Thrust Transmitter

06 0.6-0-0.6 mm
50 5.0 meters (16.4 feet)
01 35 mm DIN-rail clips
00 Not required

3300 NSv Proximity Probes

330905:3300 NSv Probe
M10X1 thread,without armor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

Accelerometer Interface Module

ACCELEROMETER INTERFACE MODULE
28 V
138 MA
1.3 W
24 VDC
25 HZ HIGH PASS CORNER
350 HZ LOW PASS CORNER
50 PC/G TRANSDUCER CHARGE INPUT SENSITIVITY
10 VDC SIGNAL BIAS
0 TO +70 DEGREE C

3301040010100200
PROBE

Seismoprobe VelocityTransducers

Seismoprobe VelocityTransducers
01 0 ±2.5, 4.5 Hz (270 cpm)
01 Top Mount (no cable)
10 Circular; M10X1 stud
00 No Approvals

I/O Module

INTERNAL BARRIER
I/O MODULE
3500 SERIES
4 PROX/ACCEL CHANNELS
W/ INTERNAL TERMINATIONS

3300XL 11mm Extension Cable

080 8.0 meters (26.2 feet)
12 FluidLoc cable with connectorprotector
00 Not required
3.94 V/mm (100 mV/mil) Output
Long Linear Range
Thin Design

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm
