Bently Nevada

System Monitor Module

330001
DISCONTINUED BY MANUFACTURER
SYSTEM MONITOR BASIC
SYSTEM POWER-UP INHIBIT FUNCTION
SYSTEM RESET
SUPPLY VOLTAGES OK LEDS

I/O MODULE

12573601
DISCONTINUED BY MANUFACTURER
COMMUNICATION GATEWAY MODULE

Isolated Tip TC I/O Module

3500/65 RTD/ Isolated Tip TC I/OModule
External Terminations
Channel-to-Channel:1500V AC
Analog Output:4-20mA
Supply Voltage: 24V DC ±10%
Resolution:0.1°C
Input Impedance:>1MΩ

Modbus RS485 I/O Module

Ethernet TCP/IP Capabilities
Serial (RS232/RS422/RS485)
Communications Capabilities
RJ45 Ethernet Connection
Configurable Modbus Register Utility

AC POWER INPUT MODULE

106M108101
AC POWER INPUT MODULE
85-264 VAC
2.8 AMP
47-63 HZ

3300 XL Standard Extension Cable

045 4.5 meters (14.8 feet)
01 Armored cable
00 Not required

3300 XL 8 mm Reverse Mount Probes

330106-05-30-CC-DD-EE M10 x 1 threads
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector

12824001
DISCONTINUED BY MANUFACTURER
I/O MODULE
PROXIMITOR /SEISMIC MONITOR

Power Supply Module

Product No. : 3500/15-05-05-00
Product type : 3500/15 AC and DC Power Supplies
Model : 3500/15 = Power supply
Power supply type : 05 = Universal AC voltage (85 to 264 Vac rms)
Power supply type : 05 = Universal AC voltage (85 to 264 Vac rms)
Agency approval option : 00 = None

Transient Data Interface

Channels Supported: Up to 16 channels
Sampling Rate:Up to 100 kHz
Adjustable resolution:12-bit to 16-bit ADC
Power Supply: 24 VDC
Standards: API 670

Tachometer Module

InputImpedance:20 k Ω (standard)
MPU: 1 VAC to 50 VAC
Proximity Probe: -2 VDC to -18 VDC
Range: 0.1 RPM to 99,999 RPM
Accuracy: ±0.1% of reading
Power Supply: 15–30 VDC

Vibration Monitor

Radial Vibration
Thrust Position
Differential Expansion
Shaft Absolute
Eccentricity
Acceleration
Velocity

3300 XL 5/8 mm Proximitor Sensor

14418150
PROXIMITOR SENSOR
3300XL
5/8MM

3301040013100205
PROBE

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

PROXIMITY SENSOR

PROXIMITY SENSOR
MODEL: 3300 XL 8 MM
1 M LENGTH
OUTPUT RESISTANCE: 50 O
OPERATING TEMP: -51 C TO +177 C
(060-987-158)

16-Channel Relay Output Module

14999201
RELAY OUTPUT MODULE
16-CHANNEL
SPARE
