3300 XL Proximitor Sensor
90 9.0 meters (29.5 feet)
system length,panel mount
Gap Voltage Output:-2 V to -18 V DC
Vibration Output:±5 V AC peak
Dynamic Range:0–10 kHz
Linearity:±1% over full scale
Vibration Variables:±1% of full scale range
3-wire VoltageMode:10 kΩ
Bias Filter:0.09 Hz 1-pole low-pass
OK Filter: 2.4 kHz 1-pole low-pass
BiasVoltage:-24 V
Analog inputs: 4–20 mA, ±10V
Analog outputs (4–20 mA
Voltage range: ±10V, 0–10V.
Current range: 4–20 mA, 0–20 mA
Digital Inputs:24V DC (±10%)
Relay contacts: 2A @ 30V DC / 250V AC
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5–95% non-condensing
Temperature monitoring is available in 16 channels.
Temperature inputs can be RTD or TC
Accepts isolated tip thermocouples,
3-wire or 4-wire RTDs
or a combination of
TC and RTD inputs
