- 3300 XL 11mm Proximity Transducer
- 330702-00-25-10-02-00
In Stock
Ships by Friday, June 26
Fast Shipping Available
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330702-00-25-10-02-00
-
Product Model330702-00-25-10-02-00
-
Product Parameters3300 XL 11 mm Probe, 1/2-20 UNFthread, with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.8x1.5x112cm
-
ManufacturerBently Nevada
-
Weight0.05 kg
-
Unthreaded Length Option0.0 in
-
Overall Case Length Option2.5 in
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector, standard cable
-
Agency Approval OptionNot required
Description
The Bently Nevada 330702-00-25-10-02-00 is a 3300 XL 11 mm Proximity Probe designed for non-contact measurement of shaft vibration, axial position, differential expansion, and displacement in critical rotating machinery. The probe is part of the 3300 XL 11 mm Proximity Transducer System, which combines a proximity probe, extension cable, and Proximitor® sensor to provide accurate and reliable machinery condition monitoring and protection. The 11 mm probe system is particularly suited for applications requiring an extended linear measurement range compared to standard 8 mm probe systems.
This model features a 1/2-20 UNF threaded stainless-steel probe body and stainless-steel armored cable construction. The armored cable provides additional protection against abrasion, mechanical stress, vibration, and harsh industrial environments, making it suitable for installation in turbines, compressors, pumps, motors, and generators operating in demanding conditions.
This model features a 1/2-20 UNF threaded stainless-steel probe body and stainless-steel armored cable construction. The armored cable provides additional protection against abrasion, mechanical stress, vibration, and harsh industrial environments, making it suitable for installation in turbines, compressors, pumps, motors, and generators operating in demanding conditions.
Alternative Names
33O7O2-OO-25-10-O2-OO
330702 00 25 10 02 00
330702-00-25-I0-02-00
33O7O2 OO 25 1O O2 OO
330702 00 25 I0 02 00
330702 00 25 10 0Z 00
330702-00-25-10-02-05
330702-00-25-10-02-CN
330702-00-25-10-02-BR
330702-00-25-10-02-RU
Information
Overview
Manuals
Application Notes
Product Applications
Mechanical Installation
Features:
- 3.94 V/mm (100 mV/mil) Output
- Long Linear Range
- Thin Design
This configuration incorporates a 1/2-20 UNF threaded stainless-steel probe body with a 2.5-inch case length and a 1.0-meter armored cable assembly. The stainless-steel armor enhances cable durability by protecting against abrasion, vibration, mechanical impact, and harsh industrial conditions. The probe is equipped with a miniature ClickLoc® connector and connector protector to provide secure electrical connections and simplify installation and maintenance procedures.
The 330702-00-25-10-02-00 Bently Nevada 3300 XL 11 mm Probe, 1/2-20 UNFthread, with armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330702-00-25-10-02-00 3300 XL 11 mm Probe, 1/2-20 UNFthread, with armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The probe cable is a 75 Ω triaxial FEP-insulated cable with a typical capacitance of 85 pF/m. The DC resistance from the centre conductor to the outer conductor is 1.8 ± 0.2 Ω for the 1.0 metre length. The minimum cable bend radius is 25.4 mm (1.0 in).
When combined with a 3300 XL 11mm Proximitor Sensor (330780 series) and a 330730 series extension cable, the system provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. The system linear range is 4 mm (160 mils), with an incremental scale factor of 3.94 V/mm (100 mV/mil) and a recommended gap setting of 2.5 mm (100 mils). The system linearity is ±1% of full scale. The frequency response extends from DC to 10 kHz (+0, -3 dB) with up to 305 metres (1,000 feet) of field wiring.
- Centrifugal Air Compressors:Tight-clearance multi-stage integral gear compressors
- Refrigeration Compressors:Compact-shaft industrial chilling/HVAC systems
- Process Gas Compressors:Small turbo-expanders & tight-seal gas systems
- Small Pumps & Motors:High-speed pumps, small turbines & narrow shafts
- Oil & Fluid Barrier Protection:FluidLoc cable prevents wicking into junction boxes
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Torque Specifications: Never exceed a maximum case torque of 45.2 N⋅m (400 in-lb). The recommended installation torque is 15.2 N⋅m (133 in-lb).
Minimum Bend Radius: The coaxial probe cable should have a minimum bend radius of 25.4 mm (1.0 inch).
Cross-Talk Prevention: To prevent electromagnetic interference between adjacent probes, maintain a minimum separation of transducer tips of at least 64 mm (2.5 in) for axial position measurements and 58 mm (2.3 in) for radial vibration measurements.
Technical notes
When combined with a 3300 XL 11mm Proximitor Sensor (330780 series) and a 330730 series extension cable, the system provides an output voltage directly proportional to the distance between the probe tip and the observed conductive surface. The system linear range is 4 mm (160 mils), with an incremental scale factor of 3.94 V/mm (100 mV/mil) and a recommended gap setting of 2.5 mm (100 mils). The system linearity is ±1% of full scale. The frequency response extends from DC to 10 kHz (+0, -3 dB) with up to 305 metres (1,000 feet) of field wiring.
