- 3300 XL 8mm Proximity Transducer
- 330102-00-40-05-01-00
In Stock
Ships by Tuesday, July 21
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330102-00-40-05-01-00
-
Product Model330102-00-40-05-01-00
-
Product Parameters3300 XL 8 mm Proximity Probes
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.5x1.3x68cm
-
ManufacturerBently Nevada
-
Weight0.1 kg
-
Unthreaded Length Option0.0 in
-
Overall Case Length Option4.0 in
-
Total Length Option0.5 meter (1.6 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connectorprotector, standard cable
-
Agency Approval OptionNot required
-
ProximitorSensorMaterialA308 aluminum
Description
The Bently Nevada 330102-00-40-05-01-00 is an 8 mm proximity probe from the 3300 XL Proximity Transducer System. It is designed for non-contact measurement of shaft vibration, axial position, and Keyphasor reference signals on critical rotating machinery equipped with fluid-film bearings.
The probe features a 3/8-24 UNF mounting thread with 0.0 in unthreaded length and 4.0 in overall case length. The armored cable construction uses flexible AISI 302 or 304 stainless steel braid with an FEP outer jacket, providing mechanical protection against abrasion, crushing, and chemical exposure in harsh industrial environments. The total probe cable length is 0.5 metre (1.6 feet).
The probe tip is constructed from Polyphenylene Sulfide (PPS), a high-performance engineering polymer resistant to chemicals and thermal degradation. The probe case is AISI 303 or 304 stainless steel. A Viton® O-ring provides pressure sealing between the probe tip and case; probes are not pressure tested prior to shipment.
The probe features a 3/8-24 UNF mounting thread with 0.0 in unthreaded length and 4.0 in overall case length. The armored cable construction uses flexible AISI 302 or 304 stainless steel braid with an FEP outer jacket, providing mechanical protection against abrasion, crushing, and chemical exposure in harsh industrial environments. The total probe cable length is 0.5 metre (1.6 feet).
The probe tip is constructed from Polyphenylene Sulfide (PPS), a high-performance engineering polymer resistant to chemicals and thermal degradation. The probe case is AISI 303 or 304 stainless steel. A Viton® O-ring provides pressure sealing between the probe tip and case; probes are not pressure tested prior to shipment.
Information
Overview
Manuals
Application Notes
Product Applications
Installation Specifications
Features:
- Armored and Unarmored Options
- Multiple Connector Options
- Complete Interchangeability of Units and Cabling
The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
The 330102-00-40-05-01-00 Bently Nevada 3300 XL 8 mm Proximity Probes may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330102-00-40-05-01-00 3300 XL 8 mm Proximity Probes Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Each 3300 XL 8 mm Transducer System component isbackward compatible and interchangeable4 with other nonXL 3300 series 5 mm and 8 mm transducer systemcomponents5. This compatibility includes the 3300 5 mmprobe, for applications in which an 8 mm probe is too largefor the available mounting space
The 3300 XL probe and extension cable alsoreflect improvements over previous designs. Apatented TipLoc molding method provides amore robust bond between the probe tip andthe probe body. The probe’s cable incorporatesa patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attachthe probe cable and probe tip.
- Turbines:Protects steam/gas turbines from rotor imbalance & misalignment
- Compressors:Monitors shaft displacement in centrifugal/reciprocating compressors
- Pumps:Bearing wear analysis for water/cooling/chemical pumps
- Electric Motors & Generators:Tracks motor wear & hydro generator rotor alignment.
- Centrifuges:Measures high-speed & slow-rolling vibration in centrifuges
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Probe Gapping: The recommended gap for standard operation is 1.27 mm (50 mils).
Linear Range: The sensor operates linearly from 0.25 to 2.3 mm (10 to 90 mils).
Total System Length: This specific model (05) has a 0.5-meter (1.6 feet) total length. It must be used with a 4.5-meter extension cable to reach a standard 5-meter system length, or a 8.5-meter cable for a 9-meter system.
Alternative Names
330102-00-40-05-01-0O
330102-00-40-05-0I-00
330102-00-40-05-O1-00
330102-00-40-O5-01-00
330102-00-4O-05-01-00
330102-0O-40-05-01-00
33010Z-00-40-05-01-00
330I02-00-40-05-01-00
330102 00 40 05 01 00
330102 00 40 05 01 0O
330102 00 40 05 0I 00
330102 00 40 O5 01 00
33010Z 00 40 05 01 00
330I02 00 40 05 01 00
330102-00-40-05-01-05
330102-00-40-05-01-CN
330102-00-40-05-01-BR
Technical notes
The agency approval option (E: 00) of the Bently Nevada 330102-00-40-05-01-00 indicates no special agency approvals are required. The Bently Nevada 330102-00-40-05-01-00 is factory calibrated to AISI 4140 steel as the default target material, with calibration to other target materials available upon request. The Bently Nevada 330102-00-40-05-01-00 incorporates patented TipLoc molding technology that provides a more robust bond between the probe tip and the probe body, and patented CableLoc design that provides 330N (75 lbf) pull strength to more securely attach the probe cable and probe body.
FAQs
-
What is the 330102-00-40-05-01-00?
+The Bently Nevada 330102-00-40-05-01-00 is a 3300 XL 8 mm proximity probe designed for non-contact vibration and position measurement. -
What is the required cable length?
+This specific part number (330102-00-40-05-01-00) includes a 0.5-meter cable, which must be paired with a 5-meter Proximitor. -
What is the difference between 330101 and 330102 probes?
+The 330102 model is designed for 5-meter Proximitor systems, whereas the 330101 is used for 9-meter systems. -
What Proximitor sensor is compatible with this probe?
+Because the probe has a 0.5-meter total length, it must be used with a 5-meter Proximitor sensor system. In a standard 5-meter system, the 0.5m probe is paired with a 4.5-meter extension cable to reach the total required 5-meter electrical length. Matching these lengths is critical for proper system calibration.
