- 3300 XL 8mm Proximity Transducer
- 330104-15-25-10-02-05
In Stock
Ships by Monday, August 17
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330104-15-25-10-02-05
-
Product Model330104-15-25-10-02-05
-
Product Parameters3300 XL 8 mm Probe, M10 x 1 thread,with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size1.7x1.5x114cm
-
ManufacturerBently Nevada
-
Weight0.15 kg
-
Unthreaded Length Option150 mm
-
Overall Case Length Option250 mm
-
Total Length Option1.0 meter (3.3 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector standard cable
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
The 330104-15-25-10-02-05 is a 3300XL 8mm Proximity Probe with M10 x 1 thread and armor as a critical component of the 3300XL 8mm Proximity Transducer System. The 330104-15-25-10-02-05 provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The primary applications of the 330104-15-25-10-02-05 include vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements
The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system’sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements
Information
Overview
Manuals
Application Notes
Product Applications
Probe Insertion & Gapping
Features:
- M10 x 1 Metric Thread with Armor Protection
- Patented TipLoc Molding Method
- Patented CableLoc Design with 330 N Pull Strength
- 1.0 Meter Total Length for 1-Meter Proximitor Sensor
- ClickLoc Connector with Connector Protector and Standard Cable
The probe incorporates a 1.0 meter (39 inch) integrated 75 Ω triaxial cable with FEP insulation, terminated with a miniature male coaxial ClickLoc connector. The ClickLoc connector locks into place and prevents loosening under vibration. The patented TipLoc molding method creates a stronger bond between the probe tip and the probe body. The patented CableLoc design provides 330 N (75 lbf) of pull strength, securing the cable to the probe tip.
The probe delivers a linear range of 2.0 mm (80 mils), with a sensitivity of 7.87 V/mm (200 mV/mil) and linearity better than ±0.06 mm (±2.3 mils). The frequency response extends from 0 to 10 kHz, maintaining performance with extended field wiring up to 305 meters (1000 feet).
The 330104-15-25-10-02-05 BENTLY NEVADA 3300 XL 8 mm Probe, M10 x 1 thread,with armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
BENTLY NEVADA 330104-15-25-10-02-05 3300 XL 8 mm Probe, M10 x 1 thread,with armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 330104-15-25-10-02-05 features a patented CableLoc design that provides 330 N (75 lbf) pull strength to more securely attach the probe cable and probe body. The 330104-15-25-10-02-05 is equipped with corrosion-resistant, gold-plated ClickLoc connectors that require only finger-tight torque during installation. The specially-engineered locking mechanism on the 330104-15-25-10-02-05 prevents the connectors from loosening, and these connectors require no special tools for installation or removal. The 330104-15-25-10-02-05 includes Option 02, which provides a miniature coaxial ClickLoc connector with connector protector and standard cable, offering increased environmental protection for the probe-to-extension cable connection.
With a total length of 1.0 meter (3.3 feet), the 330104-15-25-10-02-05 is designed for use with the 1-meter Proximitor sensor. The 330104-15-25-10-02-05 features an unthreaded length of 15mm (AA:15) and an overall case length of 25mm (BB:25), providing precise metric dimensions for secure mounting. The 330104-15-25-10-02-05 supports complete interchangeability of probes, extension cables, and Proximitor sensors within the 3300XL 8mm system, eliminating the need to match or bench calibrate individual components.
- Oil/Gas Refineries: Monitors and shuts down hazardous processes safely
- Chemical/Petrochemical: Integrates with field devices in toxic/explosive environments
- Power Generation: Ensures high-speed communication between control room and critical field instruments
- Manufacturing/Process: Reliable serial interface linking safety systems to broader plant networks
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Positioning: Ensure the machine shaft or target is centered within its normal operating range.
Insertion depth: The probe must be screwed into the machinery's mounting bracket or adapter until it physically touches the target surface (this is 0 gap).
Backing off: From the zero-gap position, back the probe out by a specific number of turns, or measure the gap using a feeler gauge based on the manufacturer’s linear range (typically between 0.25 mm to 2.5 mm or 10 to 100 mils).
Locking: Tighten the locknuts on the probe to secure its position once the desired gap voltage is reached.
Alternative Names
330104-15-25-10-02-O5
330104-15-25-10-0Z-05
330104-15-25-10-O2-05
330104-15-25-1O-02-05
330104-15-25-I0-02-05
330104-15-Z5-10-02-05
330104-I5-25-10-02-05
3301O4-15-25-10-02-05
330I04-15-25-10-02-05
33O104-15-25-10-02-05
330104 15 25 10 02 05
330104 15 25 10 02 O5
330104 15 25 10 0Z 05
330104 15 25 10 O2 05
330104 15 25 1O 02 05
330104 15 25 I0 02 05
330104 15 Z5 10 02 05
330104 I5 25 10 02 05
3301O4 15 25 10 02 05
330I04 15 25 10 02 05
33O104 15 25 10 02 05
330104-15-25-10-02-00
330104-15-25-10-02-CN
330104-15-25-10-02-BR
Technical notes
Furthermore, the 330104-15-25-10-02-05 is backward compatible and both electrically and physically interchangeable with non-XL 3300 series 5mm and 8mm transducer system components, providing flexibility for system upgrades and maintenance in existing installations. The 330104-15-25-10-02-05 operates within a standard temperature range of -52°C to +177°C (-62°F to +350°F) for the probe tip and cable.
FAQs
-
What is the 330104-15-25-10-02-05?
+The Bently Nevada 330104-15-25-10-02-05 is a highly accurate proximity probe sensor from the 3300 XL 8 mm transducer system -
What is the maximum operating temperature?
+The 330104 probe and standard extension cables can operate and be stored in temperatures ranging from -35°C to +200°C (-31°F to +392°F). Short-term excursions up to +250°C (482°F) are acceptable for less than 24 hours. -
Can this probe be connected directly to a legacy 7200 series monitor?
+No. The 3300 XL system requires its own specific Proximitor sensor (which processes the signal) and XL-specific extension cables. You cannot directly connect a 3300 XL probe to older legacy hardware. -
Can I mix and match components with older legacy systems?
+No. The 3300 XL 8 mm system operates on an advanced, proprietary design and cannot be connected directly to legacy parts like the older 7200 series Proximitor sensors. However, you can completely interchange probes, extension cables, and Proximitor sensors within the 3300 XL family without requiring individual bench calibration.
