16-CH AI Terminal Block

Input Power Rating 30 VDC @ 100m A
AmbientTemperature-40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration
1 mm peak to peak from 2 to 13.2 Hz;
0.7 g from 13.2 to 150 Hz
AirborneContaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3
Relative Humidity 5 to 95% non-condensing

I.S. DO 45 mA CHARM

CHARM Bus power rating +6.3 VDC at 0 mA
Field circuit power rating+24 VDC at 78 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to13.2Hz;
0.7g from 13.2 to 150Hz
Airborne Contaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3

IS module power supply carrier

IS module power supply carrier 8724-CA-PS
Accommodates one 8920 PSU module
DIN rail or panel mounting
printed wiring board
rugged polycarbonate moulding
32- and 64-slot address capable
CARRIER MOUNTING MODULE:
System Power Supply module: 8920-PS-DC

DC power supply

PAC8000 I/O
Power Module-Field Input24VDC In
5A@12VDC Out;
Power for 2/1 (IS) modules
Use2/1 (IS) modules power
with support for load sharing redundancy
PAC8000 Intrinsically Safe module
DC power supply (8 modules)

KJ2201X1-BA1 Logic Solver - SLS 1508

Dry-ContactPlus Card

KC3021X1-BA2
13P0054X022
DeltaV 32CH
Dry-ContactPlus Card

KL2101X1-BA1 Charm I/O Card

24 V DC input
Maximum current: 2 A
6.3 V DC output
Maximum current: 3.25 A
Output Power 6.3 VDC at 3.25 A
Operating Range: -40 °C to +70 °C
Storage Range: -40 °C to +85 °C

Analog Input Module

ANALOG MODULE
2 WIRE/16CHANNEL
4-20MA
SERIES 2
LOCALBUS POWER RATING: 12VDC AT 150MA
BUSSED FIELD POWER RATING: 24VDC AT 600MA
FIELD CIRCUIT RATING: 240VDC AT 30MA
RACK MOUNTED

KL2101X1-BA1 Charm I/O Card

Input Power:24 VDC at 2 A
Output Power:6.3 VDC at 3.25 A
Ambient Temperature :-40 °C to +70 °C
Shock 10g ½ Sinewave for 11msec
Vibration
1mm Peak to Peak from 2 to13.2Hz;
0.7g from 13.2 to 150Hz
Airborne Contaminants
ISA-S71.04 –1985 Airborne
Contaminants Class G3

KJ3002X1-BF1 RTD Input Module

RTD MODULE
OHMS FINAL ASSEMBLY
W/ SHIELD
8WIDE
160MA
12VDC
RTD CARD

KJ3002X1-BA1 Analog Input Module

KJ2003X1-BB1 Controller MD Plus

MQ CONTROLLER

KJ2005X1MQ1
MQ CONTROLLER
1.4 AMP
5 VDC

Analog Output Module

Output Type: Analog (Voltage or Current)
Output Range: 0-20 mA,
Channels: 4 channels of output .
Resolution: Typically 16-bit .
Output Accuracy: ±0.1% of full scale
Power Supply: 24 V DC
Current Draw: 200-400 mA .
Operating Temperature: Typically from -20°C to +60°C

KJ3222X1-BK1 AI 8-Channel 4-20 mA HART

KJ3241X1-BA1 Redundant Serial Interface Card

Serial Interface Card

Local Bus Power 12 VDC at 300 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985 Airborne
Contaminants Class G3
