Control Base Assembly
CONTROLLER BASE RACK
4 SLOT
Distributed Control System
supports 8 to 16 I/O
24 VDC
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to 85°C
Humidity 5% to 95% non-condensing
KJ3002X1-BG2 Thermocouple Module
KJ3002X1BG2
DISCONTINUED BY MANUFACTURER
THERMOCOUPLE
MV FINAL ASSEMBLY
INPUT MODULE
8POINT
ANALOG
KJ3202X1-BA1 High Side Output Module
KJ3202X1BA1
DISCONTINUED BY MANUFACTURER
INPUT MODULE
HIGH SIDE CARD
SERIES 2
24VDC
DO 24 VDC ISOLATED
KJ3001X1BG1
DISCONTINUED BY MANUFACTURER
OUTPUT MODULE
8 POINT
DISCRETE
ISOLATED
24 V DC
KJ4010X1-BG1 Localbus Right Extender
KJ4010X1BG1
DISCONTINUED BY MANUFACTURER
RIGHT EXTENDER
CL1
DIV 2
LOCALBUS
KJ4010X1-BF1 Localbus Right Extender
KJ4010X1BF1
DISCONTINUED BY MANUFACTURER
LEFT EXTENDER
LOCALBUS
CL1
DIV 2
KJ4001X1-NB1 Horizontal LocalBus Dual Left Cable Extender
KJ4001X1NB1
DISCONTINUED BY MANUFACTURER
DUAL LEFT EXTENDER
8 AMP
12
6 VDC
LOCALBUS
KJ4001X1-NA1 Horizontal LocalBus Dual Right Cable Extender
KJ4001X1NA1
DISCONTINUED BY MANUFACTURER
DUAL RIGHT EXTENDER
8 AMP
12.6 VDC
LOCALBUS
KJ3221X1-BA1 Analog Output Module
KJ3221X1BA1
DISCONTINUED BY MANUFACTURER
INPUT MODULE
8POINT ANALOG
4-20MA
HART
KJ3221X1-BA1 Analog Output HART Module
KJ3221X1BA1
DISCONTINUED BY MANUFACTURER
INPUT MODULE
8POINT ANALOG
4-20MA
HART
KJ3102X1-BA1 IS Analog Input 4-20mA With Hart Module
PROCESS CONTROL
8 CHANNELS
4-20MA
WITH HART MODULE
12P1863X032
SYSTEM POWER SUPPLY (DC/DC)
KJ1501X1BB1
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
SYSTEM DC/DC
12VDC
10WATT MAX
AI 16 CH 4-20mA HART CARD
Local Bus Power 12 VDC at 150 mA
Bussed Field Power 12 VDC at 600 mA
Field Circuit 24 VDC at 32 mA/Ch
Ambient Temperature -40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2Hz;
0.7 g from 13.2 to 150 Hz
Airborne Contaminants
ISA-S71.04 –1985 AirborneContaminants Class G3
Relative Humidity 5 to 95% Non-Condensing
7380A36G01
DISCONTINUED BY MANUFACTURER
PCB SEQUENCE OF EVENTS RECORDER CARD
PCB CIRCUIT BOARD MODULE
7-21 MA
6QSE1
16 Channel Digital Output
Output Voltage: 24 VDC
Output Current: Typically 1-5 A per channel
Channels: 16 output channels
Isolation: Optical or relay isolation )
Output Type: Dry contact relay or solid-state
Operating Temperature: -20°C to +60°C
