PRODUCT DESCRIPTION
IC697CGR935 96 MHz Hot-Standby CPU
GE Fanuc IC697CGR935 is a 96 MHz, 32-bit CPU for hot-standby redundancy applications in the Series 90-70 PLC platform. It executes the configured control program and supports redundant-system continuity through the documented companion hardware and configuration.
The CPU uses an 80486DX4 processor, 1 Mbyte of user-logic RAM and floating-point math. The catalog lists 12288 discrete I/O points, SNP serial communication and one RS-232 plus two RS-485 ports; the applicable firmware release and redundant-rack arrangement determine software compatibility.
The CPU uses an 80486DX4 processor, 1 Mbyte of user-logic RAM and floating-point math. The catalog lists 12288 discrete I/O points, SNP serial communication and one RS-232 plus two RS-485 ports; the applicable firmware release and redundant-rack arrangement determine software compatibility.
BEFORE YOU BUY
Confirm the complete 96 mhz hot-standby cpu
ACTUAL APPLICATIONS
Application context for IC697CGR935
IC697CGR935 supports hot-standby control in compatible Series 90-70 PLC systems. Industrial contexts include manufacturing, process production and power generation. The paired CPU configuration, I/O network and firmware must be verified as a complete redundant system.
-
01 · CHEMICAL PROCESSING
Chemical Production and Process Manufacturing
Industrial Chemical ProductionPetrochemical Production and Processing -
02 · OIL & GAS
Petroleum Production and Natural Gas Processing
Petroleum Refining and ProcessingNatural Gas Process Production -
03 · POWER GENERATION
Electricity Generation and Industrial Energy Production
Thermal Electric Power GenerationIndustrial Cogeneration and Heating
Technical specifications for IC697CGR935
-
Product ModelIC697CGR935
-
Product Parameters96 MHz Hot-Standby CPU
-
In stock5 units
-
ManufacturerGeneral Electric
-
Processor architecture80486DX4
-
Processor clock96 MHz
-
CPU word width32 bit
-
User logic RAM1 Mbyte
-
Non-volatile user flash memoryNone
-
Discrete I/O capacity12288 points
-
Analog I/O capacity8 Kbytes
-
Boolean execution time0.4 µs per Boolean function
-
Embedded communication protocolSNP serial
-
Serial interface arrangement1 RS-232 and 2 RS-485 ports
-
CPU redundancy modeHot standby
-
Redundancy scan extension4.7 ms
-
Required 5 V bus current3.1 A
-
Floating-point mathSupported
-
Release 7.60 programming softwareIC641SWP 7.01+ / IC641CTL 2.10+
View all additional
Alternative Names
IC697CGR935
Series 90-70 96 MHz Hot-Standby CPU
96 MHz Hot-Standby CPU IC697CGR935
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate IC697CGR935 96 mhz hot-standby cpu
Identify IC697CGR935 and both redundant system configurations. Confirm the Series 90-70 racks, companion redundancy hardware, firmware and I/O network.
Budget 3.1 A from the 5 V bus and allocate documented serial interfaces. Match the application and memory configuration to the supported programming software release.
Validate redundancy behavior, I/O communication and CPU diagnostics using the GE system procedure. Preserve the accepted application and hardware configuration.
Features:
- 96 MHz hot-standby Series 90-70 CPU
- 1 Mbyte RAM and configured I/O network
- 3.1 A 5 V bus allocation
The IC697CGR935 96 mhz hot-standby cpu requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify IC697CGR935 96 mhz hot-standby cpu
Match IC697CGR935 and its full hardware/firmware revision before exchange. A different Series 90-70 CPU does not establish equivalent hot-standby behavior.
Archive the application and paired CPU configuration. Record racks, I/O network, serial connections and companion redundancy hardware before following the service procedure.
Restore the approved configuration and test normal and standby operation. Check switchover behavior and diagnostics before releasing the system to service.
Features:
- CGR935 hardware and firmware revision match
- Archived paired CPU and redundancy configuration
- Switchover and I/O diagnostic verification
The IC697CGR935 96 mhz hot-standby cpu requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- GE exact-CPU catalog column and GFK-1440A
- Release 7.60 programming compatibility notes
- Hot-standby restrictions and hardware identity
Documentation for the IC697CGR935 96 mhz hot-standby cpu must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size4 × 21.8 × 29.1cm
-
Shipping weight0.75kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8537101190
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about IC697CGR935
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which redundancy type does IC697CGR935 support?
The GE catalog identifies CPU hot-standby redundancy. It must be configured with the documented redundant-system hardware and software. -
What processor and memory are specified for CGR935?
It uses a 96 MHz 80486DX4 processor and 1 Mbyte of user-logic RAM. -
Is user flash memory listed for this redundant CPU?
The catalog lists no non-volatile user flash memory for IC697CGR935. -
What serial interfaces are available on CGR935?
The catalog lists one RS-232 and two RS-485 ports with SNP serial communication. -
What current should be allocated on the CPU 5 V bus?
The exact CGR935 catalog column specifies 3.1 A, not the 1.6 A value of adjacent CPU variants. -
What programming software versions apply to release 7.60?
GFK-1440A specifies IC641SWP 7.01 or later and IC641CTL 2.10 or later. Later releases require their own compatibility check. -
Which paired CPU revisions and software belong in a redundancy-spare enquiry?
Provide IC697CGR935, both CPU hardware/firmware revisions, racks, redundancy hardware and programming software versions, together with the required quantity. -
What rack and serial checks apply to a CGR935 delivery?
Inspect CPU label, backplane contacts and serial ports, and compare the paired system revisions. Preserve the application and redundant configuration before the controlled exchange.
