I/O Chassis for Redundant Module

The IOCHAS-0001R chassis
up to 9 pairs
redundant IO modules
Approvals: CE, UL, CSA, TUV, FM
5V-1: 35 mA (IO-0001 slot 20)
5V-2: 35 mA (IO-0001 slot 21)

Bus Terminator

Model Number:FS-TERM-0002
Type: Bus Terminator
Termination Type:Active impedance matching
Nominal Impedance:100Ω ±1%
Power Requirement:Backplane-powered
Current Draw :15mA @ 24V DC
Isolation Voltage: 500V DC from backplane
Signal Reflection:<-30dB @ 1GHz

Bus Terminator

Model Number:FS-TERM-0002
Type: Bus Terminator
Termination Type:Active impedance matching
Nominal Impedance:100Ω ±1%
Power Requirement:Backplane-powered
Current Draw :15mA @ 24V DC
Isolation Voltage: 500V DC from backplane
Signal Reflection:<-30dB @ 1GHz

IO Extender Module

Input Voltage:24V DC (18-36V)
Power Consumption:2.5W (typical)
Isolation :1500V AC
Channel Capacity:16 points
Signal Types:DI/DO/AI/AO
Operating Temp:-40°C to +70°C
Storage Temp:-50°C to +85°C
Humidity:5-95% RH (condensing)
Vibration:5g @ 10-500Hz

IO Extender Module

Input Voltage:24V DC (18-36V)
Power Consumption:2.5W (typical)
Isolation :1500V AC
Channel Capacity:16 points
Signal Types:DI/DO/AI/AO
Operating Temp:-40°C to +70°C
Storage Temp:-50°C to +85°C
Humidity:5-95% RH (condensing)

Controller backplane

Model Number:FS-CPB-0001
Type:High-Speed Controller Backplane
Compatibility:ControlEdge 900/900X Series
Power Distribution:24V DC
Backplane Current:40A max
Isolation :1500V AC
Impedance:100Ω ±10%

Chassis for redundant or non-redundant Controller

Chassis for redundant or non-redundant Controller
Product No. : FS-CPCHAS-0001
Product Type : Chassis for Control Processor
Approvals : CE, UL, CSA, TUV, FM
Power :
5V-1 : 0.05 A
5V-2 : 0.05 A

SC Switch Module

FC-SSWM01
51306930-176
SC SWITCH MODULE
PROGRAM/FORCE/RESET

Node Address Jumper

Product No. : 51153818-202
Product Type : Node Address Jumper
The node address jumper is used to give the processors in
the RUSIO-3224 or RUSLS-3224 module(s)
the node address of the IOTA
Gray plastic jumper set
Has a (two digit) number that is clearly visible

Jumper Kit

Type of Jumper
Electrical jumper connections
for various industrial applications
Operating Temperature Range
Typically from -20°C to +70°C
Storage Temperature Range -40°C to +85°C
Humidity 5% to 95% non-condensing

Digital Input Module

Safe digital input FTA
24 V DC, 16 channels
Digital Input Module

I/O Chassis for non-redundant I/O modules

IOCHAS-0001S is a chassis
for up to 18 non-redundant IO module
Approvals: CE, UL, CSA, TUV, FM
5V-R: 35 mA (IO-0001 slot 21)

Safe digital output module (24 Vdc, 0.55 A, 8 channels) (conformal coated)

Safe high-density analog input module (24 Vdc, 16 channels) (conformal coated)

Controller I/O Termination Assembly

Typically 24V DC or 12V DC
Output Type Source
Load Voltage 15 30 VDC Maximum
On-State Voltage 24 V (typ), load current @ 0.5A
Off-State Leak Current 5.0 µA (max)
Turn-On/Turn-Off Time 10 ms (max)
