Honeywell

LCNP4E Card

51405098100
DISCONTINUED BY MANUFACTURER
OUTPUT MODULE
HART
ANALOG
0.46 AMP
24 VDC
REPLACED BY 51454493-126
LCNP4E GUS/EXPERION LCN INTERFACE. DELL MODEL T5500 AND NEWER REQUIRE THIS BOARD FOR LCN CONNECTION.

CCPAOX01
DISCONTINUED BY MANUFACTURER
ANALOG OUTPUT MODULE

51304441125
DISCONTINUED BY MANUFACTURER
INPUT MODULE
32 POINT
MU-TDID12
24 VDC

Safe Fire detector input FTA with Line Mon. (24 Vdc, 16 ch.)

CONTROL PROCESSOR MODULE

CONTROL PROCESSOR MODULE
C200
EXPERION PKS
24 VDC
CONFORMAL COATING
(51404305-275)

Analog Input Module

Extensive self diagnostics
Optional redundancy
Fast loop scan
Internal or external field power selection
On board excitation power
Galvanic Isolation

S8 HLAI IOTA (16), BLK, COATED

CCPCF901
DISCONTINUED BY MANUFACTURER
CONTROL FIREWALL C9 MODULE
9 PORT
0.112 AMP
24 VDC

Analog Output Module

OUTPUT ANALOG MODULE
24 VDC
480 MA
TA = 60 C MAX
(51410070-175)

5 Slot Module Backpanel

Five-Slot and Ten-Slot Module
configured to perform various functions,
Universal Stations in the TPS system.
Each module occupies a specific address (node)
on the Local Control Network (LCN).

Power Distribution Board

FCPDB0824
DISCONTINUED BY MANUFACTURER
PC BOARD
POWER DISTRIBUTION BOARD
8 CHANNEL
24VDC 2A CC

51304476125
PC BOARD ANALOG OUTPUT 8POINT MU-TAOX02

TMG7403
BURNER CONTROL BOX
4-6 AMP
220-240 VAC
50 HZ
20 VA

Analog Input Module

Input Type:Thermocouple and / or RTD
Input channels:64 fully-isolated channel-to-channe
Input scan rate:1 Second fixed by IOM
Channel bandwidth:0 to 4.7 Hz (-3 dB)
Nominal input range:-20 to +100 millivolts
Temperature stability:+/-20 ppm per deg C max
Long term drift:500 ppm

Analog Output Module

8CTAOX61
PC BOARD
ANALOG OUTPUT IOTA
COATED
SERIES 8
16 CHANNELS

Analog Output Module

Output Type:4-20 mA
Output Channels:16
Output Temperature Drift:0.005% of Full Scale/°C
Output Readback Accuracy:±4% of Full Scale
Output Current Linearity:± 0.05% of Full Scale nominal
Directly Settable Output Current Range:0 mA, 2.9 mA to 21.1 mA
Maximum Output Compliant Voltage:16 V
Maximum Open Circuit Voltage:22 V

Analog Input Module

Extensive self-diagnostics
Optional redundancy
Supplies non-incendive field power
Suitable for Configure / Status for HART devices
HART-capable, multivariable instruments for
fastcollection of control variables
Fast loop scan
Non-Incendive Power

TCPCIC01
DISCONTINUED BY MANUFACTURER
CONTROL INTERFACE MODULE
CNET PCI
5.25 VDC @ 700 MA
CLASS 2
(96365671)

I/O Card

Voltage Rating:24 VDC
Module current rating:430 mA
Operating Temperature:0 to 60 °C
Storage temperature:-40 to 85 °C
Supervisory network type Series:8 PGM is a standard FTE node
