Honeywell

WSI2 Unix coprocessor card

100 MHz
without graphics
used in the UxS and AxM.
with 32, 64, or 128 MB of RAM memory

Tpdgc I/O Circuit Board

TPDG I/O BOARD
INTERFACE FOR PERIPHERALS
6 PERIPHERAL CONNECTIONS

Turbo Peripheral DG – UxS

Power Requirements 24 VDC
Operating Temperature Range -20°C to 60°C
Humidity Range 5% to 95%
Mounting Options
Standard DIN rail or custom rack mounting

Operator Keyboard

Fully programmable customized menus
LCD color touchscreen, and buttons
Softkeys support different colors and text
Touch pad and touch ring
Ergonomic design with padded wrist rest
Variable-speed joystick with integral zoom control
L ocking power connector
Dedicated keys for commonly used functions
Dynamic menu selection
Web interface for configuration and firmware upgrades
Laser cut backlit keys

CIRCUIT BOARD

TDC 3000 systems
Input Voltage: 24 V DC (typical)
Power Consumption: ≤10W
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C

Interface Converter Board

24V DC internal power supply
within the system
-20 ° C to 70 ° C
5% to 95%, no condensation
Multiple digital/analog input/output interfaces
DIN rail installation or rack mounted installation

HTD Regulator

HTD Regulator
Miscellaneous Modules
Wide Range of Equipment

Control Card

Voltage: 24 VDC (±10%)
Channel-to-Channel: 250 VAC minimum
Channel-to-Bus: 500 VAC reinforced isolation
Channels: 8 or 16
Resolution: 16-bit
Accuracy: ±0.1% of full scale
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 0–95% RH, non-condensing

RACK 10 SLOT

TKFXX102
RACK 10SLOT COATED
5.1VDC - 15/6AMP
24VDC - 2.8/2.8AMP
3.3VDC - 4/4AMP

MPU TRANSITION MODULE

TMPU1002
DISCONTINUED BY MANUFACTURER
MPU TRANSITION MODULE
COPPER TRANS MOD FOR EXTREME ENG CPU 18-410051-001 DUAL DIODE MODULE
DIN
6A DUAL DIODE MODULE

UCN Series Module

Output Frequency:50 kHz
Processing Capacity:High-speed data processing
Communication Protocol:Supports multiple industry-standard protocols
Operating Temperature:-40°C to +70°C
Memory Size:Extended memory capacity for enhanced system functionality

Power Supply

51198947100
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
115/240 VAC INPUT
50/60 HZ
25 VDC OUTPUT
10 AMP LOAD
550 WATT POWER

Low Level Analog Mux Module

Manufacturer : Honeywell
Product No. : 51309218-125
Product type : Low Level Analog Input Multiplexer RTD FTA
Not CE compliant, not conformally coated
Redundancy not supported
Input channels : 16
Teminals : compression
LLMux RTD FTA with compression terminals
Single IOP interface

Digital Input Power Module

Pulse Input FTA - MC-TPIX52
CE compliant, conformally coated
Use with IOP MU-PPIX02 or MC-PPIX02
Redundancy not supported
Input Points - 8
Terminals - Screw
Size B - 12 inches (307 mm)

Analog Input Module

Low Level Multiplexer Thermocouple FTA - MC-TAMT13
CE compliant, conformally coated
Redundancy not supported
Input channels - 16
Teminals - compression
Size B - 12 inches (307 mm)

Purbo Peripheral Display Generator

Temp: 0°C to 50°C
Power: Standard Honeywell supply
Humidity: 5% - 90% RH
Refresh: Real-time
Type: DCS Display

MEMORY BOARD

Model: 51401072-300
Type: Memory Board
Function:  Used in process control systems
System Compatibility: Honeywell TDC 3000 Process Control System
Operating Temperature Range: 0°C to 60°C (32°F to 140°F)

Processor Module

Model: 51403393-200
Operating Voltage: 24V DC
Power Consumption: Low power design
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to+85°C
CPU Type: High performance embedded processor, specifically optimized for control systems

CONTROL BOARD

51401551201
CONTROL BOARD
PWA K2LCN 2MW
MULTI INPUT/OUTPUT
PANEL MOUNT
SINGLE SLOT

Printed Circuit Board

51402615200
PC BOARD
K2LCN CIRCUIT BOARD
W/ 2MW OF MEMORY

GATEWAY INTERFACE MODULE

51400997100
PC BOARD
PLC GATEWAY INTERFACE
PWA PLCI
STATUS LED
SINGLE CONNECTOR
PANEL MOUNT

PC BOARD

51400901100
CONTROL BOARD
ENHANCED MODULE PROCESSOR
COMBINED PROCESSOR/LAN INTERFACE/MEMORY BOARD
PANEL MOUNT
MULTI INPUT/OUTPUT

PC BOARD

51400855100
PC BOARD
HIGH PERFORMANCE/DENSITY

PROCESSOR BOARD

51401551300
PROCESSOR BOARD
HIGH PERFORMANCE/DENSITY
(K2LCN-3)

CONTROL BOARD

51401551301
CONTROL BOARD
K2LCN-3
MULTI INPUT/OUTPUT
PANEL MOUNT
SINGLE SLOT
