Honeywell

Power Supply Unit

Power Supply Unit
24/5 Vdc, 16A
dual 5 V supply (out of 24 VDC) for
Control Processor and redundant IO
non-redundant IO

Universal Safety Interface

UNIVERSAL SAFETY INTERFACE
MMEM CC, EUCN
Approvals: CE, TUV, UL, CSA, FM
5 V supply voltage: 5 V DC ± 5%
5 V supply current: max 1.2A
Operating temperature:-5°C - +70°C (+23°F - +158°F)
Storage temperature: -40°C - +85°C (-40°F - +185°F)
Relative humidity: 10 - 95% (non condensing)

Analog Input Module

Input Type Current (2-wire or self-powered transmitters)
Input Channels 16 Channels (16 Single Ended)
Common Mode Rejection Ratio, dc to 60 Hz 70 dB
A/D Converter Resolution 16 bits
Input Range 4-20 mA (through 200 Ω)
Normal Mode Rejection Ratio, at 60 Hz 20 dB
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.0 Hz
Maximum Normal Mode Input ± 30 Volts

Hlai/sti galvanic isolator module

Description : HLAI/STI FTA, GI/IS MC-GAIH13
CE compliant, conformally coated
Redundancy
Channels : 16
Galvanically Isolated
Terminals : Compression
Size B : 12 inches (307 mm)

PROBE LOW TEMP 20FT PH

Measuring Range: 0–14 pH.
Process Fluid: 0°C to 50°C (32°F to 122°F)
Response Time: ≤30 seconds
Cable: 20 feet shielded, UV-resistant
Pressure Rating: ≤5 bar (72.5 psi)
Calibration: 2–3 point calibration

Analog Input Module

ANALOG INPUT MODULE
24VDC
16 CHANNEL
Absolute accuracy
Correct conversion over the full range
Crosstalk between inputs
Channel input filters
Internal supply voltages

Universal Input Output IOTA

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Universal Input Output IOTA Red

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Digital Output Module

Output Channels:32
Output Type:SINK (Open Drain)
Load Voltage:15 30 VDC Maximum
Load Current:0.1 A per channel (Max)
On-State Voltage:0v VDC
Off-State Voltage:24 V (typ)
Off-State Leak Curren:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

Revision C IO Link Cable

Type: IO Link Cable
Part Number: 51202341-102 Revision C
Country of Origin: USA
Cable Length: 1 meter
Shielding: Shielded

HORIZONTAL BACK PLANE PWA

Operating Voltage: 24 V DC
Input Current: 1 A
Output Power: 20 W
Bus Interface: RS-485
Operating Temperature: -20°C to +70°C
Humidity Range: 5% to 95% non-condensing
Certifications: CE, UL, ISO 9001

IOL FOE PM VIOLET - 0.5M

Cable Type: Fiber Optic Ethernet.
Connector Type: IOL (Input/Output Link) connectors.
Length: 0.5 meters
Operating Voltage: 24 VDC.
Operating Current: 0.5 A.
Maximum Power Consumption: 12 W

Digital Input Module

PC BOARD
LOGIC CARD
NON-REDUNDANT
IOTA
9 INCH

Digital Output IOTA Redundant

Output Channels:32
Output Type SINK: (Open Drain)
Load Current :0.1 A per channel (Max)
On-State Voltage 0v VDC (load current @:0.1A max
Off-State Voltage:24 V (typ),
Off-State Leak Current:100 µA (max)
Turn-On/Turn-Off Time:10 ms (max)

Digital Input IOTA Redundant

Power supply:24V DC
Rated Current:55mA at 24V
Power Consumption:1.32W at 20mA
Power/DCS to Field:1500 VAC
DCS side connections:
37 pin DSUB connector on CC-UGIA01
Voltage Input:24V DC
Interface to DCS:4 to 20mA with HART

Analog Output IOTA Redundant

Power supply 24V DC
Rated Current 55mA at 24V
Power Consumption 1.32W
Power/DCS to Field 1500 VAC
DCS side connections 37 pin
DSUB connector on CC-UGIA01
Voltage Input 24V DC
Current Input 4 to 20mA with HART,
CC-UGAI01 in sink mode.
Open wire current <150uA

Digital module

Channels: 16 digital channels
Input Type: 24 VDC
Isolation:500 VDC
Update Rate: ≤10 ms
Power Consumption: ≤5 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing.

SC S300 SAFETY CONTROLLER SIL3

Input Voltage: 24 VDC (±10%)
Output Voltage: 24 VDC
Current Capacity: Typically up to 5A
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing

SC S300 SAFETY CONTROLLER SIL3

Digital Inputs:24 VDC
Cycle Time: <10 ms
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Contact Rating: 5A @ 250VAC
Operating Force: 1.8N minimum
Release Force: 0.1N minimum
Pre-travel: 1.5mm maximum

Digital Input Module

Input Channels:32
Galvanic Isolation: 1500 VAC RMS or ±1500 VDC
Isolation Technique:Optical (in IOM)
DI Power Voltage Range:18 to 30 VDC
ON Sense Voltage/Current:13 VDC (min) or 3 mA (min)
OFF Sense Voltage/Current:5 VDC (max) or 1.2 mA (max)
nput Impedance:4.2 K
Absolute Delay Across Input Filter and Isolation:5 ms ± 20%

Redundant Net Interface Module

REDUNDANT NET INTERFACE MODULE
CAGE CARD
24 VDC
(PN-14251 / 14251)

ANALOG OUTPUT MODULE

I/O LINK INTERFACE
FIBER OPTIC CONVERTER
9 PORTS
ANALOG OUTPUT MODULE

Enhanced Logic Manager Module

Input Voltage:Typically 24 VDC
Power Consumption:Around 25 W
Operating Temperature Range:Typically -20°C to 60°C
Storage Temperature Range:-40°C to 85°C.
Relative Humidity:5% to 95% non-condensing.

Power Supply

POWER SUPPLY
230 VAC

Quad Processor Pack

Two -synchronous- processors
Flash memory for system and applicationprogram
RAM with battery backup (battery located inBKM-0001)
Data comparators for the processors and theirmemory
Minimum and maximum execution timemonitor
Memory error handler
1oo2D functionality
24V and 5V monitoring
Emergency Shut Down Input (24V)
Two outputs (for non-redundant resp.redundant IO)
