Honeywell

System Interconnection Cable

Cable type: 20 × AWG 22
slot 1 to 18
Outer diameter (nominal): 9.93 mm / 0.39 in
Connector for systeminterconnection cables

Analog Output Module

Output Type 4-20 mA
Output Channels 16
Output Ripple < 100 mV
peak-to-peak at power line frequency
Output Temperature Drift 0.005% of Full Scale/°C
Output Readback Accuracy ±4% of Full Scale
Output Current Linearity ± 0.05% of Full Scale nominal.
Resolution ± 0.05% of Full Scale
Calibrated Accuracy ± 0.35% of Full Scale (25oC) including linearity
Directly Settable Output Current Range 0 mA, 2.9 mA to 21.1 mA
Maximum Output Compliant Voltage 16 V

Digital Output Module

DC-PDOD51
Digital Output Module
Optional redundancy
Electronic Overcurrent protection

SERIES C CONTROL MODULE

Operating Voltage: 24 V DC
Input Current: 1.5 A
Output Power: 10 W
Output Frequency: 1 kHz
Operating Temperature: -20°C to +70°C
Humidity Range: 5% to 95% non-condensing

ANALOG INPUT MODULE

MC-TAIH52
ANALOG INPUT MODULE
HIGH LEVEL

MOTHERBOARD

PC BOARD
MOTHERBOARD
MAIN PROCESS CONTROL BOARD
K4LCN-based ENIM
converted to UEA hardware.
Note that the LCN NIM, AM, EPLCG, NGand EHB
with C300s can also be migrated
equivalent ELCN UEA nodes
