Honeywell

I/O Link Cable

Conductors:24V DC
Voltage Rating: ≤30V DC
Current Rating: Up to 2A
Type: M8 or M12 4-/5-pin connectors
Temperature Range: -25°C to +70°C

Digital Output Module

Output Channels 32
Output Type Source
Load Voltage 15 30 VDC Maximum
On-State Voltage 24 V (typ), load current @ 0.5A
Off-State Leak Current 5.0 µA (max)
Turn-On/Turn-Off Time 10 ms (max)

32 Point Digital Input Module

Inputs per module:32 (sinking)
Input Voltage Range:10 VDC to 32 VDC
Peak Voltage:32 VDC
AC Frequency: N/A
ON Voltage Level:9.5 VDC minimum
OFF Voltage Level:3.5 VDC maximum
Input Impedance:6.9 K ohms nominal
Minimum ON Current:1.0 mA
Maximum OFF Current:0.7 mA

UNIVERSAL SAFETY INTERFACE MMEM,CC,EUCN

SYSTEM INTERCONNECTION CABLE TERM.ON PIN

POWER DISTR.CABLE MB-0001 TO PDB-0824 BS

Power Distribution Cable

POWER DISTIBUTION CABLE
TRANSFERS POWER
FROM MB-0001 TO PDB-0824
24 VDC
145 CM LENGTH

Power Distribution Cable Set

Approvals: UL, CSA; FM pending
Type: CC 600 World 4 × 2.5 mm2
Bus bar side: 2 pole Squeeze To
Release type: D-TAB-200-STR
IO chassis side: FM5W5 S (female)
housing: low profile, 90°

POWER DISTR.CABLE IOCHAS-0003S 5VDC WD

Type number: FS-PDC-IOS05A
Approvals: UL, CSA
Type: SAB 2040415
CC600 4 × 1.5 mm2
Length: 2.45 m
Type: 8 pole, pin header
Weidmuller: BLZP 5.08HC/08/180F SN BK

POWER DISTR.CABLE IOCHAS-0003R 5VDC WD

Type number: FS-PDC-IOR05
Approvals: UL, CSA
Type: SAB 2040707
CC600 7 × 0.75 mm2
Length: 2.45 m
Type: 8 pole, pin header
Weidmuller: BLC 5.08/8 BR
Pins: Weidmuller: DFFC 0.5 - 1.0 SN E

Power Distribution Cable

The red wire represents the +24Vdc
The black wire represents the 0Vdc
Approvals: UL, CSA; FM pending
Housing type: 2 pole socket block
Weidmuller BLZ 5.08/2F
Crimp pin type: Weidmuller
DFFC 1.5-2.5 SN E

POWER DISTR.CABLE PDB-CPX05 5VDC WD

POWER DISTRIBUTION CABLE SET CPCHAS

Power distribution cable
set Control Processor
24 V DC

ART PWR DISTR.CABLE IOCHAS-0002 5VDC WD

Approvals: UL, CSA pending
Length: 2 m
Type: 3 pole socket connector
Make: Weidmuller: BLZ 5.08/03/180F SN BK

Multi-Conductor Cable

POWER BUSBAR
MAX.200A 24/48/110VDC, 60CM
Multi-Conductor Cable
Optical Rail Module
Communication Module
