Technical specifications for TC-FXX102
-
Product ModelTC-FXX102
-
Product Parameters10 SLOT CHASSIS 13 AMP
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size39.7x14.5x17.2cm
-
ManufacturerHoneywell
-
Weight1.35 kg
-
Chassis Capacity10 Single-Width Module Slots
-
Current Rating13 A Backplane Capacity
-
Backplane Logic Voltage5.1 VDC
-
5.1 VDC Backplane CurrentUp to 15 A Total
-
Auxiliary Backplane Voltage24 VDC
-
24 VDC Backplane CurrentUp to 2.8 A Total
-
I/O Backplane Voltage3.3 VDC
-
3.3 VDC Backplane CurrentUp to 4 A Total
-
Maximum Combined Output Power75 W
Description
The Honeywell TC-FXX102 is a 10 Slot Chassis (13 Amp) developed for Honeywell Experion PKS and C-Series I/O systems. It serves as the mechanical mounting platform and electrical backplane for C-Series controllers, communication modules, and I/O modules. The chassis distributes power and backplane communication signals while providing secure installation for up to ten single-width modules. It is commonly used in distributed control systems for process automation across a wide range of industrial applications.
The Honeywell TC-FXX102 provides a 13 A backplane capacity, supporting larger system configurations than earlier 10 A chassis versions. The backplane distributes 5.1 VDC, 24 VDC, and 3.3 VDC power to installed modules while maintaining a maximum combined output power of 75 W. This capacity allows the chassis to accommodate multiple high-performance controllers and I/O modules operating simultaneously within the same cabinet.
The Honeywell TC-FXX102 provides a 13 A backplane capacity, supporting larger system configurations than earlier 10 A chassis versions. The backplane distributes 5.1 VDC, 24 VDC, and 3.3 VDC power to installed modules while maintaining a maximum combined output power of 75 W. This capacity allows the chassis to accommodate multiple high-performance controllers and I/O modules operating simultaneously within the same cabinet.
Information
Overview
Manuals
Application Notes
Product Applications
Features:
- 10-Slot Module Capacity
- 13 Amp Backplane Current Rating
- Redundant Power Supply Compatibility
- Compatible with C200 and C300 controller platforms
The Honeywell TC-FXX102 is compatible with Honeywell C200 Controllers, C300 Controllers, C-Series I/O modules, communication interfaces, and network modules. It also supports the TC-RPSCA2/TK-RPSCA2 Redundant Power System Adapter, enabling installation of redundant power supplies for applications requiring increased system availability. The redundant power architecture provides automatic load sharing, fault detection, status indication, and uninterrupted operation if one power supply becomes unavailable.
The TC-FXX102 Honeywell 10 SLOT CHASSIS 13 AMP may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Honeywell TC-FXX102 10 SLOT CHASSIS 13 AMP Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Engineered for continuous industrial operation, the TC-FXX102 supports all CIOM-A I/O modules including analog input/output, discrete input/output, thermocouple input, RTD input, and specialty modules. The TC-FXX102 is part of the Honeywell Experion LS I/O family that interfaces to the C200E control processor over the I/O ControlNet, and is also compatible with RIOM-A rail-mounted I/O modules through ControlNet Gateway modules on the same network. The TC-FXX102 provides reliable backplane communication and centralized power distribution, making it a trusted foundation for process control, monitoring, and data acquisition applications in demanding industrial environments.
- Power Generation: Monitors plant auxiliary equipment and sensor feedback within distributed networks
- Oil & Gas Processing: Tracks line pressures, fluid temperatures, and fuel flow rates
- Marine Vessel Controls: Integrates into shipboard monitoring for non-critical subsystem sequencing
- Turbine/Engine Monitoring: Tracks pressure, temperature, and flow in gas/steam/hydro setups
- Distributed Control Networks: Integrates into Woodward NetCon LINKnet architecture for scalable plant sequencing
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Alternative Names
TC-FXX1O2
TC-FXXI02
TCFXX102
Technical notes
The Honeywell TC-FXX102 features a durable industrial metal chassis for panel mounting inside control cabinets. Integrated backplane connectors simplify module installation and replacement while ensuring reliable electrical connections. The chassis operates over a temperature range of -40°C to +70°C and is suitable for demanding industrial environments where long-term reliability is required. Its IP20 enclosure and robust construction make it appropriate for continuous operation in process control installations.
FAQs
-
What is the difference between TC-FXX102 and TK-FXX102?
+The TK version features a conformal coating for enhanced protection in harsh or corrosive environments. -
Does it have a power supply?
+Yes, it includes an integrated, selectable 85-132/170-265 VAC or 19.2-32 VDC power supply. -
Does it support power redundancy?
+Yes, the chassis backplane fully supports integration with redundant power supply configurations to maximize system uptime and mitigate failure risks. -
What is the TC-FXX102?
+The Honeywell TC-FXX102 is a 10-slot chassis rack designed for the Honeywell Experion PKS automation system. It physically houses up to 10 single-wide Series-A input/output (I/O) modules and integrated power supplies.
