PRODUCT DESCRIPTION
TC-305-01 communications cable with eight flying leads
TC-305-01 provides flying-lead connections to the communications ports of a Trusted T8151 Communications Interface. The module end uses a 78+2-way type M connector in a single-width hood with an earth braid, while eight leads provide the external connections.
The assembly uses screened Cat 5 cable with a PVC sheath and heatshrink protection at the flying-lead end. Connectors are fitted to user requirements. The manufacturer provides 50-ohm coaxial leads for the specified Ethernet connections and prohibits simultaneous use of both Ethernet media types.
The assembly uses screened Cat 5 cable with a PVC sheath and heatshrink protection at the flying-lead end. Connectors are fitted to user requirements. The manufacturer provides 50-ohm coaxial leads for the specified Ethernet connections and prohibits simultaneous use of both Ethernet media types.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where TC-305-01 Fits Across Industrial Production Fields
Used in oil, chemical and power operations where the installed equipment and approved controller configuration are compatible.
-
01 · OIL & GAS
Oil Production, Gas Processing and Petroleum Transportation Facilities
Offshore production platforms and onshore facilities processing crude oil.Natural gas processing plants and pipelines transporting petroleum products. -
02 · CHEMICAL PROCESSING
Chemical Manufacturing, Batch Processing and Industrial Formulation Facilities
Continuous production facilities manufacturing bulk chemicals and industrial materials.Batch production areas handling chemical blending and product formulation. -
03 · POWER GENERATION
Gas Turbine Generation and Combined Cycle Power Stations
Natural gas turbine generators supplying electricity to utility networks.Combined cycle power stations integrating gas and steam generation.
Technical specifications for TC-305-01
-
Product ModelTC-305-01
-
Product ParametersTrusted Communications Flying Lead Cable
-
ManufacturerICS Triplex
-
Host interfaceTrusted T8151 Communications Interface
-
Module-end connector78+2-way type M
-
Connector enclosureSingle-width hood
-
External cable endsEight flying leads
-
Cable constructionScreened Cat 5
-
Sheath materialPVC; -01 variant
-
Earth connectionBraid fitted to the module-end hood
-
Flying-lead protectionHeatshrink at the sheath ends
-
Coaxial Ethernet leads50 ohm; E1 and E3
-
Ethernet media restrictionUse either documented media type, not both simultaneously
-
Catalog electrical limit60 V / 2 A maximum per channel
View all additional
Alternative Names
Trusted TC-305-01 communications cable
TC30501 T8151 flying lead cable
ICS Triplex TC-305-01 breakout assembly
