· Product image is representative; revision or series may vary. Contact us to request a specific version.
- Customs & Documentation
- We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
Documents checked before dispatch · Shipment details confirmed · Global tracking provided
- Payment
- Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
- Product Condition
- Factory New These are new and current items that are procured directly from the manufacturer.
New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
-
20+
years in automation -
ISO 9001
certified quality system -
12 months
amikon warranty -
2-hour reply
from your account manager -
Success Story
solutions in action
-
Please try to be as accurate as possible with your search.
-
We can quote you on 1000s of specialist parts, even if they are not listed on our website.
-
We can't find any results for “”.
SEE PRODUCTS IN SEARCH PAGE ()
PRODUCT DESCRIPTION
Two isolated serial ports for controller communications
ICS Triplex T7150A is a Regent + Plus communications module with two isolated serial ports. Each port supports the documented RS-232, RS-422 or RS-485 connection arrangements for communication with host computers, operator interfaces, printers or other compatible controllers.
The module supports Regent R2, Guarded Peer-Link and Modbus communications over its isolated serial interfaces. Power-sharing circuitry receives supplies from the three processor modules, while front-panel indicators show communications status and transmit or receive activity.
The module supports Regent R2, Guarded Peer-Link and Modbus communications over its isolated serial interfaces. Power-sharing circuitry receives supplies from the three processor modules, while front-panel indicators show communications status and transmit or receive activity.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where T7150A Fits in Industrial Production Facilities
Use spans process industries and utility facilities, subject to the installed hardware, connections and approved configuration.
-
01 · POWER GENERATION
Power Station Operations and Electricity Production Control Rooms
Power station control rooms with operator displays and workstations.Electricity production sites with turbine auxiliaries and boiler equipment. -
02 · CHEMICAL PROCESSING
Chemical Production Operations and Industrial Process Control Rooms
Chemical production operations with batch equipment and operator workstations.Industrial process control rooms with status displays and printers. -
03 · OIL & GAS
Hydrocarbon Production Facilities and Petroleum Processing Operating Areas
Hydrocarbon production facilities with process equipment and operator displays.Petroleum processing operating areas with control desks and workstations.
Technical specifications for T7150A
-
Product ModelT7150A
-
Product ParametersRegent + Plus communications module
-
ManufacturerICS Triplex
-
Serial ports2 independently configurable ports
-
Serial standardsRS-232, RS-422 and RS-485
-
Baud range300 to 19200 baud
-
Supported protocolsRegent R2, Modbus RTU, ASCII Output and Guarded Peer-Link
-
Modbus roleRTU slave; communication initiated by an external master
-
Guarded Peer-Link rolesNetwork master or network slave
-
Port connectorsFemale DB-25 on module; mating male DB-25 cable connector
-
Module powerPowered by triplicated processor modules; no separate external supply required
-
Isolation1000 V minimum: serial device-to-logic and port-to-port
-
Heat dissipation7 W
-
Recommended network cableFor multidrop and Guarded Peer-Link: 120 ohm twisted pairs with overall shield
-
Operating temperature0 to +60 degrees C
-
Storage temperature-40 to +85 degrees C
-
Relative humidity0-95%, noncondensing
View all additional
Alternative Names
T7150A Regent + Plus communications module
ICS Triplex T7150A dual serial communications interface
T7150A Regent + Plus Regent R2 and peer-link module
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
REGENT + PLUS EQUIPMENT
Match T7150A to the documented Regent + Plus configuration
T7150A provides serial communication between Regent + Plus controllers and compatible hosts, operator interfaces or peer controllers. Match electrical interface, protocol role, cable arrangement and actual jumper settings.
Match both front DB-25 connectors and the original RS-232, RS-422 or RS-485 drawing. The module is powered by the triplicated processor modules; no separate module power supply is required.
For safety-critical Guarded Peer-Link operation, verify the specified redundant networks and redundant communications modules at every controller.
Features:
- Two independent isolated serial ports
- RS-232, RS-422 and RS-485 connections
- Regent R2, Modbus RTU and ASCII output
The ICS Triplex T7150A regent + plus communications module requires the appropriate mounting, connections and configuration to be verified before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Record the complete T7150A identity and compare its hardware revision with the installed item. Retain the complete T7150A identity and verify the two port definitions, DB-25 connections, network termination and bias settings. Guarded Peer-Link safety-critical duty requires redundant networks and redundant modules at each controller.
Match both front DB-25 connectors and the original RS-232, RS-422 or RS-485 drawing. For safety-critical Guarded Peer-Link operation, verify the specified redundant networks and redundant communications modules at every controller.
Use the controlled manufacturer procedure and the approved maintenance plan. Module health and individual port indicators serve different purposes. Check the matching port settings and wiring before diagnosing a module failure.
Features:
- Complete order identity retained
- Companion equipment and configuration checked
- No unconditional substitution claim
The ICS Triplex T7150A regent + plus communications module requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: Amikon-authored summaries and manufacturer-hosted manuals are listed here. Check the complete product identity and document scope before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the ICS Triplex T7150A regent + plus communications module must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed sizePacked dimensions unconfirmed
-
Shipping weightGross weight unconfirmed
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS referenceClassification unconfirmed
-
OriginMexico
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about T7150A
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
How many serial ports does T7150A provide?
Two isolated, independently configurable ports supporting the documented RS-232, RS-422 and RS-485 arrangements. -
Does the module need a separate external power supply?
No. The manufacturer states that power comes from the triplicated processor modules. This does not determine the power requirements of separately connected equipment. -
Is the documented Modbus service a master or slave?
The manual describes Modbus RTU slave communication initiated by an external master. Do not assume an RTU master role from the protocol name alone. -
Which connectors are on the module?
Each serial port has a female DB-25 connector on the front. The mating cable uses a male DB-25 connector, with signals wired according to the selected interface drawing. -
Do all nodes use the same termination jumpers?
No. Termination, bias and transmit-control settings depend on the network arrangement and end or middle node position. Use the manufacturer table rather than a generic jumper recipe. -
Does any single serial link qualify for safety-critical data exchange?
No. The stated safety-critical Guarded Peer-Link arrangement requires redundant communication networks and redundant communications modules at each controller. It is not a blanket approval for other protocols. -
Can a module be removed without changing communication?
Opening the top removal lever disables the module. Follow the documented removal procedure and the approved network maintenance plan; do not assume that one module can be removed without an operational effect.
