PRODUCT DESCRIPTION
8502-BI-DP-01 PROFIBUS-DP bus interface module
MTL 8502-BI-DP-01 is a bus interface module in the MTL8000 distributed I/O family for connecting compatible I/O modules to a PROFIBUS-DP host. The documented 8502-BI-DP family supports up to twenty-four I/O modules and exchanges process and diagnostic data with the host controller.
The bus interface operates as a PROFIBUS slave through an isolated RS-485 connection, with communication rates up to 6 Mbaud. Cyclic telegrams can contain analog and digital values together with HART process and status information. Nonvolatile configuration storage, configurable data mapping and extended module and channel diagnostics support the documented MTL8000 node arrangement.
The bus interface operates as a PROFIBUS slave through an isolated RS-485 connection, with communication rates up to 6 Mbaud. Cyclic telegrams can contain analog and digital values together with HART process and status information. Nonvolatile configuration storage, configurable data mapping and extended module and channel diagnostics support the documented MTL8000 node arrangement.
BEFORE YOU BUY
Confirm the complete profibus-dp bus interface module
ACTUAL APPLICATIONS
Application context for 8502-BI-DP-01
8502-BI-DP-01 is a profibus-dp bus interface module in the MTL8000 distributed I/O. It supports oil and gas, chemical and petrochemical, water and wastewater where the documented electrical limits, connected signals and equipment configuration are satisfied.
-
01 · OIL & GAS
Oil Production and Natural Gas Processing
Oil Production and ProcessingNatural Gas Process Production -
02 · CHEMICAL & PETROCHEMICAL
Chemical Processing and Petrochemical Production Industries
Industrial Chemical ProductionPetrochemical Processing and Production -
03 · WATER & WASTEWATER
Municipal Water Supply and Wastewater Treatment
Municipal Water SupplyIndustrial Wastewater Treatment
Technical specifications for 8502-BI-DP-01
-
Product Model8502-BI-DP-01
-
Product ParametersPROFIBUS-DP bus interface module
-
In stock10 units
-
ManufacturerMTL Insturments Group
-
I/O module capacity24 modules maximum
-
Network protocolPROFIBUS-DP to EN 50170
-
Transmission rates9.6 / 19.2 / 93.75 / 187.5 / 500 kbaud; 1.5 / 6 Mbaud
-
Transmission interfaceRS-485
-
LAN/Railbus/power isolation500 V
-
Input data capacity244 bytes including 2-byte status word
-
Output data capacity244 bytes including 2-byte control word
-
Combined cyclic data capacity296 bytes maximum
-
Diagnostic telegram78 bytes
-
Railbus supply12 V DC
-
Railbus current420 mA typical; 520 mA maximum at −40 ℃
-
Cable impedance135–165 Ω
-
Cable capacitance30 pF/m maximum
-
Bus length at 9.6–93.75 kbaud1200 m maximum
-
Bus length at 6 Mbaud100 m maximum
View all additional
Alternative Names
8502-BI-DP-01
MTL8000 distributed I/O PROFIBUS-DP bus interface module
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
SYSTEM INTEGRATION
Integrate 8502-BI-DP-01 profibus-dp bus interface module
MTL 8502-BI-DP-01 is a bus interface module in the MTL8000 distributed I/O family for connecting compatible I/O modules to a PROFIBUS-DP host. The documented 8502-BI-DP family supports up to twenty-four I/O modules and exchanges process and diagnostic data with the host controller.
Compare the documented i/o module capacity (24 modules maximum) and network protocol (PROFIBUS-DP to EN 50170) with the installed configuration. Match the complete order code, terminal arrangement and required mating components before connection.
Follow the MTL Instruments instructions for mounting, wiring and configuration. Retain the existing parameter record, inspect connections and validate every affected signal before returning the equipment to operation.
Features:
- I/O module capacity: 24 modules maximum
- Network protocol: PROFIBUS-DP to EN 50170
- Transmission rates: 9.6 / 19.2 / 93.75 / 187.5 / 500 kbaud; 1.5 / 6 Mbaud
The 8502-BI-DP-01 profibus-dp bus interface module requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify 8502-BI-DP-01 profibus-dp bus interface module
Replace 8502-BI-DP-01 only after confirming the complete article number, product family and installed revision. The replacement must match the documented profibus-dp bus interface module role and the connected equipment.
Record the installed MTL8000 distributed I/O configuration, terminal assignments and cable connections before removal. Preserve the applicable program, parameter settings and diagnostic records for restoration.
After fitting 8502-BI-DP-01, restore the approved configuration and perform the manufacturer-defined functional checks. Confirm the connected signal or power paths and record the final test results before release.
Features:
- I/O module capacity: 24 modules maximum
- Network protocol: PROFIBUS-DP to EN 50170
- Transmission rates: 9.6 / 19.2 / 93.75 / 187.5 / 500 kbaud; 1.5 / 6 Mbaud
The 8502-BI-DP-01 profibus-dp bus interface module requires replacement verification against the complete installed configuration and current manufacturer documentation.
