Siemens SINAMICS

INVERTER CONTROL MODULE

SIMOVERT
Master drives
Inverter control Module
IGD1 for devices 380-460 V 3 AC
50/60Hz und 510-620 V DC
92A and 146A

POWER SUPPLY MODULE

SINAMICS
SPARE POWER SUPPLY
FOR 500-690V 3AC
50/60 HZ
AC DRIVE/POWER/MOTOR MODULE

Mains thyristor control Module

PC BOARD
MAINS THYRISTOR CONTROL MODULE TDB
SPARE PART

LINE FILTERE

LINE FILTER
SINAMICS
FOR 10 KW SMART LINE MODULE
INPUT: 3 PHASE 380-480 VAC 50/60 HZ

Inverter control Module

INVERTER GATING MODULE
380-460 VAC
50/60 HZ
510-620 VDC
510 A

Memory card

MICRO MEMORY CARD
SD CARD
SINAMICS DCM

SINAMICS BRAKING MODULE

SINAMICS BRAKING MODULE
INPUT: 600 V DC
OUTPUT: 250 KW/
15 S FOR CHASSIS UNITS H AND J

CONVERTER CONTROL MODULE

SINAMICS DCM DC converter
for 4-quadrant drives Circuit (B6) A (B6) C
Input: 400V 3AC, 13A
controllable: Field rectifier D420/15
MREQ-GEG6V62
Output: 420 V DC, 15 A

CONTROL UNIT

SINAMICS S120
CONTROL UNIT
CU310-2 DP
WITH PROFIBUS INTERFACE
WITHOUT COMPACTFLASH CARD

6RY1703-0GA01

PC BOARD
BACK PANEL
REAR
6RY1703-0GA01
Contact Rating: 5‒10 A @ 24–230 V AC/DC
Isolation Class:24 V AC/DC isolation
Control Side: 24 V DC
Power Circuit: Up to 690 V AC three-phase

POWER INTERFACE BOARD

POWER INTERFACE BOARD
RELAY OUTPUTS
WITH ON-BOARD TRANSFORMERS
Contact Configuration:Typically SPDT or DPDT relays
Maximum Switching Voltage:250 V AC/DC
Current Rating:5–15 A per relay
Purpose:24 V AC/DC to lower voltage
Control Input(s): 24 V DC

FIELD POWER SUPPLY PC BOARD

PC BOARD ASSEMBLY
FIELD POWER SUPPLY PC BOARD
Nominal Input: 110-240 V AC
Frequency: 47-63 Hz
Voltage Output: Likely 24 V DC
Operating Temperature: Range of 0°C to +60°C
Humidity Tolerance: ≤95%, non-condensing

EXCITATION BOARD

EXCITATION BOARD
CIRCUIT BOARD
FIELD SUPPLY
850 AMP

TDB MODULE PC BOARD

A5E02822121
TDB MODULE PC BOARD
690VAC
FOR CONVERTER MODULE

Inverter Snubber Module

Inverter snubber Module SML4
Rated Voltage: 510 V to 930 V
Peak Current Handling: 10–20 A
Operating Temperature: -10°C to +50°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Interface Board

MICROMASTER 430
PX replacement Control
Interface Board
for 380-480 V 3AC
50/60 Hz, 490 A AC Drive

Control Interface Board

Smart Line Module :6TG38-8AA0
Rated power of the SmartLine Module:710
Power loss 50/60 Hz
Rated voltage:
3-ph. 500 V AC -10 % (-15 % < 1 min)
3-ph. 690 V AC +10 %

POWER SUPPLY BOARD

SINAMICS MICROMASTER PX
POWER SUPPLY BOARD
spare power supply
380-480 V 3AC
50/60 Hz AC Drive Power

DC REGULATING BOARD

SINAMICS DCM
DC speed regulation excitation board
Output Voltage Range: 0–250 V DC
Field Current Rating: Typically ≤20 A
Enable/Disable Signals: 24 V DC
Temperature Range: 0°C to +55°C (60°C with derating)
Humidity: 5–95% non-condensing

Inverter Drive

SINAMICS V20
380-480 V 3AC -15%/+10% 47-6
Rated power 0.75 kW with 150% overload for 60 sec
unfiltered I/O interface: 4 DI, 2 DQ, 2 AI, 1 AO
Fieldbus: USS/Modbus
RTU with built-in BOP Degree of protectionIP20/UL
open Size: Size A 90x150x146

SINGLE MOTOR MODULE

SINAMICS S120
SINGLE MOTOR MODULES
INPUT: 600 V DC
OUTPUT: 3-PH 400 V,
210 A FRAME SIZE: CHASSIS
INTERNAL AIR COOLING SUPPORT
OF THE EXTENDED SAFETY
INTEGRATED FUNCTIONS
INCL. DRIVE-CLIQ CABLE

REPLACEMENT POWER BLOCK

REPLACEMENT POWER BLOCK
SINAMICS
3 PHASE
380-480 VAC
50/60 HZ
745 AMP
DRIVE/POWER MODULE RECTIFIER
U PHASE PAINTED MODULES
NICKEL-PLATED BUSBARS

POWER BLOCK

POWER BLOCK
DRIVE CONTROL INVERTER BOARD
IGD2/R4
480V/490A

SINGLE MOTOR MODULE

SINAMICS S120
SINGLE MOTOR MODULE
INPUT: DC 600V
OUTPUT: 3AC 400V, 85A FRAME
SIZE: BOOKSIZE INTERNAL AIR COOLING
OPTIMIZED PULSE SAMPLE
AND SUPPORT OF THE EXTENDED
SAFETY INTEGRATED FUNCTIONS INCL
DRIVE-CLIQ CABLE

Power Module

SINAMICS G120 Power Module
PM 250 with integrated Class A
filter capable of energy recovery
380-480 V 3 AC +10/-10% 47-63 Hz
Power high overload: 7.5kW at 200% 3s
150% 57s, 100% 240 s
Ambient temperature 0 to +50 °C
Power low overload: 11kW at 150% 3s
110% 57s, 100% 240 s
Ambient temperature 0 to +40 °C
FSC Degree of protection
IP20 without Control Unit and BOP

POWER SUPPLY MODULE

MODULAR POWER SUPPLY
8 AMP
24 VDC +/-20%
150 WATT
SPARE PART
Voltage: 24 VDC
Single-phase AC: 100–240 VAC

Single Motor Module

SINAMICS S120
Single motor module
input: 600 V DC output: 400 V 3 AC, 18 A
design: booksize D type internal air cooling
optimized pulse patterns and support of
the extended Safety Integrated functions
incl. DRIVE-CLiQ cable

Active Line Module

TB30 Terminal Board

SINAMICS / SIMOTION
TERMINAL BOARD
TB30 FOR
CONTROL UNIT CU320-X
SIMOTION D4X5-X

Power Module

Power Module

AOP30 Operator Panel

5.7-inch color TFT LCD
320 x 240 pixels
Input Voltage:24 V DC ±15%
Power Consumption:≤15 W (typical)
Operating Temperature:0°C to +50°C
Storage Temperature:-40°C to +70°C
Humidity:≤95% RH (non-condensing)

SINAMICS PM240-2 IP20-FSF-A-400V-75kW

Power Module

CONVERTER DCM DC 4Q 3P AC 400V 174A

Double Motor Module

SINAMICS S120
Double Motor Module
input: 600 V DC
output: 400 V 3 AC, 9 A/9 A
type of construction: booksize internal
air cooling optimized pulse patterns
and support of the extended Safety
Integrated functions
incl. DRIVE-CLiQ cable

Inverter Drive

CONTROL UNIT

SINAMICS CONTROL UNIT
CU320-2 PN
WITHOUT COMPACT FLASH CARD

Double Motor Module

Smart Line Module

Single Motor Module

Power Module

SINAMICS G120C PN 2,2KW UNFIL

Inverter Drive

Single Motor Module

SINAMICS S120
Single Motor Module
input: 600 V DC
output: 400 V 3AC, 60 A
type of construction: booksize internal
air cooling optimized pulse patterns and support
of the extended Safety Integrated functions
including DRIVE-CLiQ cable

Control Interface Module (CIM)

Supply Voltage: 24 V DC nominal
Power Consumption: Approximately 5–10 W
Isolation Voltage: 500 V AC
Digital Inputs: Voltage range 24 V DC
Digital Outputs:24 V DC
Analog Inputs: Voltage (±10 V）

Control Unit

Power Module

Power Module

Operator Panel
