- 6SL3224-0BE31-1UA0
In Stock
Ships by Wednesday, August 26
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6SL3224-0BE31-1UA0
-
Product Model6SL3224-0BE31-1UA0
-
Spare ModelNot available
-
Product ParametersSINAMICS G120 PM240 Power Module, 380-480 V, 11 kW HO / 15 kW LO, FSC
-
Tariff Code85044086
-
Country of originGreat Britain
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size255 x 390 x 220 mm
-
ManufacturerSiemens
-
Weight7 kg
-
Product lineSINAMICS G120
-
Module typePM240 Power Module
-
FilterUnfiltered
-
Braking chopperIntegrated
-
Input voltage3 AC 380-480 V, +10/-10%
-
Input frequency47-63 Hz
-
High-overload output11 kW
-
High-overload duty200% for 3 s; 150% for 57 s; 100% for 240 s
-
High-overload ambient-10 to +50 C
-
Low-overload output15 kW
-
Low-overload duty150% for 3 s; 110% for 57 s; 100% for 240 s
-
Low-overload ambient-10 to +40 C
-
Module dimensions334 x 189 x 185 mm
-
Frame sizeFSC
-
Degree of protectionIP20
-
Included equipmentControl Unit and BOP not included
-
Lifecycle statusPM410 - Spare-part status
-
Status effective date1 October 2019
-
-
Description
Siemens 6SL3224-0BE31-1UA0 is a SINAMICS G120 PM240 Power Module in frame size FSC.
The module is unfiltered, includes an integrated braking chopper, and is specified for 3 AC 380-480 V with +10/-10% tolerance at 47-63 Hz.
The high-overload output is 11 kW with 200% for 3 s, 150% for 57 s, and 100% for 240 s at -10 to +50 C.
The low-overload output is 15 kW with 150% for 3 s, 110% for 57 s, and 100% for 240 s at -10 to +40 C.
The module measures 334 x 189 x 185 mm and has IP20 protection. The Control Unit and BOP are not included.
Siemens lists the article as PM410 - Spare-part status, effective 1 October 2019.
Information
Product Information
Key Features
Applications
Engineering & Compatibility
Lifecycle & Replacement
Siemens 6SL3224-0BE31-1UA0 is a SINAMICS G120 PM240 Power Module in frame size FSC.
The article is unfiltered and includes an integrated braking chopper.
The input is 3 AC 380-480 V with +10/-10% tolerance at 47-63 Hz.
The high-overload output is 11 kW and the low-overload output is 15 kW.
The module measures 334 x 189 x 185 mm and has IP20 protection; the Control Unit and BOP are not included.
Siemens lists the article as PM410 - Spare-part status, effective 1 October 2019.
The module belongs to the SINAMICS G120 product line.
It is a PM240 Power Module in frame size FSC.
No filter is built into this article.
An integrated braking chopper is provided.
The input range is 3 AC 380-480 V, +10/-10%, at 47-63 Hz.
The high-overload and low-overload outputs are 11 kW and 15 kW respectively.
The degree of protection is IP20, and the Control Unit and BOP are not included.
The PM240 is used as a power module in a compatible SINAMICS G120 drive configuration.
It is specified for installations using a 3 AC 380-480 V, 47-63 Hz supply within the stated tolerance.
The 11 kW high-overload rating applies where the official high-overload duty and ambient limit are suitable.
The 15 kW low-overload rating applies where the official low-overload duty and ambient limit are suitable.
Application suitability must be checked against the selected Control Unit, BOP requirement, motor, overload duty, external filtering, braking design, enclosure, cabling, grounding, protection, and current Siemens documentation.
Match the exact Siemens article number 6SL3224-0BE31-1UA0 before installation.
Confirm a 3 AC 380-480 V supply with +10/-10% tolerance at 47-63 Hz.
For high overload, verify the 11 kW rating and the 200% for 3 s, 150% for 57 s, and 100% for 240 s duty.
For low overload, verify the 15 kW rating and the 150% for 3 s, 110% for 57 s, and 100% for 240 s duty.
Observe the stated ambient limits of -10 to +50 C for high overload and -10 to +40 C for low overload.
The article is unfiltered; verify the external filtering requirement and the integrated braking-chopper design.
Allow for frame size FSC, module dimensions of 334 x 189 x 185 mm, IP20 installation, and the required Control Unit and BOP arrangement.
Check motor, overload profile, filtering, braking, Control Unit, BOP, enclosure, cooling, cabling, grounding, protection, and original machine documentation before commissioning or replacement.
Siemens lists 6SL3224-0BE31-1UA0 as PM410 - Spare-part status.
The official status effective date is 1 October 2019.
The official product record does not identify a specific direct successor for this article.
AMIKONG can assist with locating the exact spare part or a suitable alternative according to the required quantity and destination.
A proposed replacement must be checked for supply range, output rating, overload duty, ambient limits, filter arrangement, braking chopper, frame size, dimensions, and IP20 installation.
Also verify the selected Control Unit, BOP, motor, enclosure, cooling, cabling, grounding, protection, machine project, and current Siemens information before installation.
Alternative Names
Technical notes
Verify the exact article number, 3 AC input voltage and frequency, high- or low-overload duty, ambient temperature, external filtering requirement, braking design, frame size, IP20 installation, selected Control Unit, BOP requirement, motor, cabling, grounding, protection, and original machine documentation before installation or replacement.
FAQs
-
What is Siemens 6SL3224-0BE31-1UA0?
+It is a Siemens SINAMICS G120 PM240 Power Module in frame size FSC. -
What input supply is specified?
+Siemens specifies 3 AC 380-480 V with +10/-10% tolerance at 47-63 Hz. -
What are the high- and low-overload output ratings?
+The high-overload output is 11 kW and the low-overload output is 15 kW. -
What overload duty profiles are listed?
+High overload is 200% for 3 s, 150% for 57 s, and 100% for 240 s. Low overload is 150% for 3 s, 110% for 57 s, and 100% for 240 s. -
Does the module include a filter and braking chopper?
+The module is unfiltered and includes an integrated braking chopper. -
Are the Control Unit and BOP included?
+No. The official product description states that the Control Unit and BOP are not included. -
What is the Siemens lifecycle status?
+Siemens lists the article as PM410 - Spare-part status, effective 1 October 2019. -
Is a direct successor listed and what must be checked for replacement?
+The official product record does not list a specific successor. AMIKONG can assist in locating the exact spare part or a suitable alternative, but supply, duty, ambient limits, filter, braking, frame size, Control Unit, BOP, motor, wiring, and project compatibility must be verified.
