      Siemens 6ES7180-0AA00-0XA0
      · Product image is representative; revision or series may vary. Contact us to request a specific version.
      Ships by Saturday, November 14

      6ES7180-0AA00-0XA0

      PROFIBUS DP Master Interface

      Require for Quote:

      Shipping Information

      • For inventory products, we support same day shipping upon payment.
      • For urgent needs, we offer same-day shipping on most items for orders placed before 2:00 PM UTC+8 Simply mention your preferred next-day shipping when place the order, and your order will be prioritized to minimize downtime.
      • For indent items, typical turnaround is 1-3 weeks, depending on parts availability and scarcity.
      Customs & Documentation
      We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
      Documents checked before dispatch · Shipment details confirmed · Global tracking provided
      Payment
      Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
      Product Condition
      Factory New These are new and current items that are procured directly from the manufacturer.
      New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
      New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
      Quantity
      Mobile *
      Country/Region *
      E-mail *
      Company
      Content *
      Upload
      (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
      Get a Quote
      For more information on how your data is processed and stored by Amikong please read our privacy policy.

      • 20+

        years in automation

      • ISO 9001

        certified quality system

      • 12 months

        amikon warranty

      • 2-hour reply

        from your account manager

      • Success Story

        solutions in action
      PART NUMBER SEARCH

      Find another automation part

      • Please try to be as accurate as possible with your search.
      • We can quote you on 1000s of specialist parts, even if they are not listed on our website.
      • We can't find any results for “”.
        SEE MORE
          SEE PRODUCTS IN SEARCH PAGE ()
          PRODUCT DESCRIPTION

          Host-connected PROFIBUS DP master interface with dual-port memory

          Siemens 6ES7180-0AA00-0XA0 is the IM 180 interface module listed for PROFIBUS DP master applications. It connects a field device to the bus through an ASPC 2 communication ASIC and an 80C165 processor, with data rates up to 12 Mbit/s.

          A dual-port RAM interface links the module to the host system. The board combines processor, communication, program-storage and working-memory functions in a 100 by 100 mm assembly. Siemens separately identifies the IM 181 carrier board for use in an ISA-bus PC.
          BEFORE YOU BUY

          Confirm the complete installed configuration

          Send a label photo for review >>
          ACTUAL APPLICATIONS

          Industrial Production and Service Sectors

          These industry examples describe Siemens' broader market coverage, not verified installations of this exact product. Product suitability depends on the documented configuration and engineering requirements.
          • 01 · FOOD & BEVERAGE

            Dairy, Bakery and Confectionery

            Dairy production and processing within the commercial food industry.Bakery and confectionery manufacturing across diverse consumer food categories.
          • 02 · TEXTILE MANUFACTURING

            Manufactured Fibers and Textile Finishing

            Manufactured fiber production for the wider textile manufacturing sector.Textile finishing for materials within the commercial fabric industry.
          • 03 · PLASTICS PROCESSING

            Extruded and Thermoformed Plastics

            Plastic extrusion for material production within the plastics industry.Thermoforming as a manufacturing route for shaped plastic products.

          Technical specifications for 6ES7180-0AA00-0XA0

          • Product Model
            6ES7180-0AA00-0XA0
          • Product Parameters
            PROFIBUS DP Master Interface
          • Manufacturer
            Siemens
          • Catalog application role
            PROFIBUS DP master applications
          • Communication protocol
            PROFIBUS DP
          • Maximum data transmission rate
            12 Mbit/s
          • Communication ASIC
            ASPC 2
          • Microprocessor
            80C165 at 40 MHz
          • Catalog firmware size
            80 KB; not an installed firmware-version statement
          • RAM configuration
            2 × 128 KB
          • Host-system interface
            Dual-port RAM
          • Program-storage architecture
            OTP-EEPROM
          • Permissible environmental temperature
            0 to +70 °C
          • Power supply
            5 V DC
          • Typical current consumption
            250 mA
          • Board dimensions
            100 × 100 mm; not packed dimensions
          View all additional
          View as PDF Ask for Quote
          SYSTEM & REPLACEMENT CHECK

          Information needed before ordering

          Three direct checks to secure your system integration and minimize ordering risks.

          Information

          System integration Replacement check Manuals & support
          HOST-INTEGRATED PROFIBUS MASTER

          Plan the host-memory interface and carrier arrangement together

          The IM 180 is intended to add PROFIBUS DP master functionality to a field-device implementation. Its host connection uses dual-port RAM, while the onboard 80C165 processor and ASPC 2 ASIC provide the documented processing and bus architecture. Integration therefore depends on the host's memory-access arrangement, not merely a matching bus connector.
          For a PC-based implementation, Siemens specifies a separate IM 181 carrier that adapts IM 180 to the ISA bus. The catalog describes demonstration software and a Windows NT driver as accessories. Those historical references identify the intended integration path; they do not establish driver support for a current operating system.
          The catalog gives a 5 V DC supply, 250 mA typical current consumption and a permissible environmental range of zero to seventy degrees Celsius. These are board-level reference values. The host assembly still needs its own verified power, mechanical and interface design; catalog specifications are not a substitute for the complete wiring documentation.

          Features:

          • Dual-port RAM host integration
          • Separate ISA carrier where required
          • Board-level electrical and mechanical checks
          The Siemens 6ES7180-0AA00-0XA0 requires the documented hardware configuration, installation conditions and interface arrangement to be verified before system integration and commissioning.
          INTERCHANGEABILITY

          Verify the complete replacement identity before commissioning

          Check the complete 6ES7180-0AA00-0XA0 number against the installed board and purchasing requirement. IM 181 is a carrier, while IM 182-1, IM 183-1 and IM 184 are listed for slave applications. A common PROFIBUS family name or transmission rate does not make these neighboring products equivalent replacements.
          Preserve the host software and record the actual module firmware before selecting a spare. The catalog lists 80 KB firmware size and two 128 KB RAM blocks, but those capacity entries do not prove software revision or application compatibility. Confirm that the existing dual-port memory exchange is supported by the intended replacement.
          Review how the board is mounted and connected in the host equipment. The documented 100 by 100 mm board size is distinct from the IM 181 carrier dimensions. Confirm the required module, carrier and accessory scope on the order; neither a physical fit nor a shared five-volt supply establishes complete interchangeability.

          Features:

          • Exact module versus carrier identity
          • Actual firmware and host-program comparison
          • Host assembly and accessory-scope review
          The Siemens 6ES7180-0AA00-0XA0 requires replacement verification based on its complete order number, installed hardware, signal configuration and project documentation.
          DOCUMENTATION STATUS

          Browse the Manuals, Datasheets, Official Documents, Links

          Important Notice: Official documents are provided through manufacturer links. Accessories, manuals, cables, calibration data, software, certificates, and other items are not included with this equipment unless listed in the stock item description.

          Features:

          • Exact-model manufacturer data and relevant original manual pages
          • Verified manufacturer product reference; separate installation document not supplied
          • Accessories and supplied documentation follow the written quotation
          Documentation for the Siemens 6ES7180-0AA00-0XA0 includes an independent technical summary and selected original manufacturer pages; check the applicable document edition against the delivered product and approved installation documentation.

          Also searched as

          6ES7135-0HF01-0XB0 6ES7134-4FB00-0AB0 6ES7972-0BA50-0XA0 6ES7132-4BB00-0AA0 6ES7134-4JB01-0AB0

          Important notice

          Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
          This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
          BUYER INFORMATION

          Commercial terms without hidden steps

          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
          • 01

            Shipping & delivery

            Dispatch
            Eligible stock: same / next day
            Carriers
            DHL, FedEx or UPS
            Ship from
            Xiamen, China
            Packed size
            Confirm final packed dimensions
            Shipping weight
            Confirm final packed weight
          • 02

            Payment & customs

            Payment
            Bank transfer (T/T)
            Currencies
            USD · EUR · GBP · RMB
            Credit cards
            Not accepted
            HS reference
            8517623990
            Origin
            Confirm supplied-unit origin
          • 03

            Warranty & returns

            Warranty
            12 months from AMIKON
            Inspection
            Label, condition and packing checks
            Returns
            Prior RMA authorisation required
            Compatibility
            Confirm before order
            OEM warranty
            Does not apply
          Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.

          • Part checked

            Full suffix recorded

          • Condition checked

            Label and appearance

          • Packing checked

            Antistatic protection

          • Tracking supplied

            Established couriers

          • Sandy Lin

            Dedicated account manager · 15+ years
          FREQUENTLY ASKED QUESTIONS

          Questions buyers ask about 6ES7180-0AA00-0XA0

          Direct answers about identity, compatibility, stock, warranty, payment and shipping.

          • Is 6ES7180-0AA00-0XA0 the IM 180 module or the PC carrier?

            It is the IM 180 master interface module. Siemens lists the IM 181 PC carrier separately as 6ES7181-0AA01-0XA0. The two items have different functions; the carrier is not the PROFIBUS interface module itself.

          • How does IM 180 communicate with the host?

            The catalog specifies a dual-port RAM interface between IM 180 and the host system. Confirm the existing host implementation and associated software before replacement; the catalog entry does not establish a universal plug-and-play host interface.

          • Which processor and PROFIBUS ASIC are used?

            The documented architecture combines an 80C165 processor operating at 40 MHz with an ASPC 2 communication ASIC. OTP-EEPROM and RAM complete the module's principal components.

          • Can this board be used in an ISA-bus PC?

            Siemens documents the separate IM 181 carrier board for accommodating IM 180 in an ISA-bus PC. The catalog also identifies historical driver and demonstration-software accessories; it does not confirm compatibility with current Windows versions.

          • Does the 80 KB firmware entry identify the software version?

            No. It is the firmware-size entry in the 2005 technical table. It does not identify the firmware loaded on a particular supplied module, a license entitlement or compatibility with an existing host program.

          • Are the 100 by 100 mm dimensions the shipment size?

            No. Siemens labels these as board dimensions. Export packaging dimensions and gross shipping weight require separate measurement or shipment records and should not be inferred from the bare board.
