DIGITAL INPUT MODULE
32 CHANNEL
24 VDC
ISOLATED
50 MA
PULSE WIDTH OUTPUT FUNCTION
TIME-PROPORTIONAL OUTPUT FUNCTION
STATUS DISPLAY
NO EXPLOSION PROTECTION
Number of input channels:64
Rated input voltage:24 V DC
Input ON voltage:20 to 26.4 V DC
Input OFF voltage :5.0 V DC or less
Input current :2.5 mA±20 % / channel
Maximum allowable input voltage:30.0 V DC
Input response time :8 ms or less
Minimum ON detection time:20 ms
Maximum ON/OFF cycle:25 Hz
Maximum current consumption:500 mA (5 V DC)
Number of inputs 16-channel, module isolation
Input signa:
No-voltage contact
ON: 1 kΩ maximum
OFF: 100 kΩ minimum
Input current 6 mA ± 20 %
Contact rating 24 V DC +20 % / -10 %
Input response time 40 ms maximum
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Output signal 4 to 20 mA
Allowable load resistance 0 to 750 Ω
Circuit-open detection Less than 0.65 mA
Accuracy ±48 µA
Data update period 10 ms
Drift due to ambient temperature change ±16 µA/10 ˚C
4 to 20 mA
16 isolated
standard switch-overresponse
in redundant configuration
1500 V AC, for 1 minute
0 to 750 Ω
Less than 0.65 mA
±48 µA
±16 µA/10 ˚C
230 mA (5 V DC)
540 mA (24 V DC)
Number of input channels: 16, isolated channels
Allowable input voltage :±5 V
Input resistance:1 MΩ or larger
Maximum currentconsumption:350 mA (5 V DC)
Measurement current:RTD: 1 mA
Resistance ofsignal source plus wiring:150 Ω or less
AAB841S00
DISCONTINUED BY MANUFACTURER
INPUT / OUTPUT MODULE
ANALOG
8-CHANNEL INPUT / 8-CHANNEL OUTPUT
NON-ISOLATED
1-5 V INPUT SIGNAL
4-20 MA OUTPUT SIGNAL
MIL 40-PIN
