ABB Advant OCS and Advant-800xA

Processor module

Processor module
Memory 80MB
Interfaces: 2 Ethernet
RS232/485, CAN.
Display (PM5650-2ETH)
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC
Memory Size: 369256 kB
Memory Type User Data:RAM

GCOM Communication Interface

Power Consumption: 1.5 - 2.5 W
Isolation:500 V AC (ports to backplane)
ESD Protection:±15 kV (IEC 61000-4-2)

INTERFACE BOARD

Data Rates:9.6 kbps – 12 Mbps
Power Supply:24 V DC
Power Consumption:≤ 2.5 W
Isolation:500 V AC
Function:PROFIBUS DP-V1 Slave Interface

Analog Input Module

Function:32-Channel Analog Input Module
Voltage: ±10 V DC, 0–10 V DC
Current: 0–20 mA, 4–20 mA
Resolution:15 bits + sign
Accuracy:±0.1% of full scale @ 25°C
Update Time:8 ms (all channels)
Common-Mode Rejection:>120 dB @ 50/60 Hz
Overvoltage Protection:±35 V DC
Power Supply:24 V DC

INPUT MODULE

INPUT MODULE
32POINT
DIGITAL
SDR SDRAM
4 SOCKET

LOGIC CONTROLLER

LOGIC CONTROLLER
32 CHANNELS
18-30 VDC
2 VDC
OUTPUT RATING: 0.01 A MINIMUM
AT 24 VDC 1.0 A MAXIMUM
24 VDC CONTINUOUS
SURGE: 2.5 A PER CHANNEL
ISOLATION: 1K VDC
10 MA PER CHANNEL

COMMUNICATION UNIT

Data Throughput: Up to 10,000
RAM: 512 KB
Voltage: +5V DC
Consumption: 10 W (typical)
Isolation:1500V AC
Fiber optic: Up to 4 km
Max Nodes: Up to 250 devices per loop

Modbus TCP Interface Module

Data Types:16-bit & 32-bit integers
Voltage: 5 V DC
Power Consumption: Typically 1.5 W
Isolation:1500 V AC galvanic

CPU Module

Model:PM590-ETH
Order Code:1SAP150000R0270
Type:Compact PLC Processor with Integrated Ethernet
Series:AC500-eCo
Power Supply:24 V DC (±20%)
Consumption: 6 W (typical)
CPU:32-bit RISC Processor
Isolation :1500 V AC

CEX-Bus Interconnection Unit

Bus Protocol:CEX-Bus
Data Rate:10 Mbps
Fiber Type:62.5/125 μm multimode
Redundancy:Dual-path redundancy
Node Capacity:Up to 32 nodes
Power Supply:24 V DC (±10%)
Power Consumption;≤ 5 W
Isolation:2500 V AC

Softstarter

Type:Thyristor-Based Soft Starter
Rated Current:142 A
Motor Power (400V):75 kW
Input: 208–690V AC (±10%), 50/60 Hz
Control Circuit: 100–250V AC/DC
Current Limit: Adjustable (200–500% I_e)
Pump Stop: Anti-water-hammer control

Control Card

Power Supply:24V DC
Voltage: 15–30V DC
Current: 3–8 mA
Rating: 2A @ 250V AC
Resolution: 10-bit
Load Impedance: ≥500Ω (voltage)
Baud Rate: 9600–115200 bps
Isolation:1500V AC

Digital Output Module

Output Signal: 24V DC
Load Current per Channel:0.5A to 2A
Max Switching Voltage: 30V DC
Isolation Voltage: 500V AC/DC
Response Time: <1ms

INTERCONNECTOR

Contact Configuration:96-position (48x2 rows)
Contact Material:Gold-plated copper alloy
Current Rating:1A per contact (max)
Voltage Rating:60V DC max
Contact Resistance:<20mΩ (initial)
Insulation Resistance:>100MΩ @500V DC
Mating Cycles: >500 insertions

Procontrol System Coupling Module

Voltage: 24 VDC (±15%) or 110–240 VAC
Power Consumption: 5–10 W
Operating Temperature: -20°C to +60°C.
Humidity: 5–95% non-condensing.

LCDC Module

LDMTR-01
63940135F
Input/Output Module

Analog Input Module

LDSTA-01
63940143B
Analog Input Module
16 digital inputs (24V DC)
Configurable as sinking/sourcing

I/O Module

LDMUI-01
61320946C
Analog Input Module

Analog Input Unit

Power Supply:24V DC ±10%
Power Consumption:5W (typical)
Current:4-20mA/0-20mA
Voltage:0-10V/±10V
RTD :Pt100
Sampling Rate:10ms/channel
Common Mode Rejection:>100dB @ 50Hz
Input Impedance:250Ω

Transducer Board

Power Supply:24V DC ±10%
Power Consumption:5VA (max)
Isolation:2kV AC (input-to-output)
Voltage Input:0-690V AC
Current Input:0-5A AC (via CTs)
Frequency Range:45-65Hz
Input Impedance:>1MΩ (voltage)
Analog Outputs:2x 4-20mA
Accuracy:±0.5% of span
Load Capacity:≤500Ω

Power Supply

Input Voltage Range:85–264V AC
Frequency Range: 47–63Hz
Inrush Current: ≤20A
Efficiency: ≥90%
Output Voltage: 24V DC
Output Current: 5A
Power Rating: 120W
Overload Protection: 105–150% of rated current

INTERFACE BOARD

Channels: 16
Voltage: 24V DC
Isolation: 1500V AC
Type: 4-20mA/0-10V
Resolution: 16-bit
Field-to-system: 2500V AC
Channel-to-channel: 500V AC

Trigger Pulse Amplifier

Voltage: 5-15V DC
Frequency: Up to 10kHz
Pulse Voltage: 24V DC
Peak Current: 2A
Pulse Width: 60-120μs
Input-to-output: 4kV AC
Channel-to-channel: 2kV AC
Operating Voltage: 220V AC ±15%
Power Consumption: 15W max
Backup Power: Optional 24V DC input

IGBT Kit

Module Type:High-capacity IGBT Kit
Configuration: Dual-switch structure
Voltage Rating: 3300V/4500V
Current Rating: 1600A-3000A
Switching Speed:<150ns turn-off time
Power Class: ≥5MW

MB300E Communication Processor

Voltage: 24 V DC
Power Consumption: ≤ 5 W
Serial Ports: RS-232/RS-485
Ethernet Port: 10/100 Mbp
Fieldbus Support: Profibus DP
Processor: 32-bit RISC-based
Flash Memory: 16 MB
Data Throughput: Up to 10,000 signals
