Emergency Shutdown Device

Ethernet-6 Ports:10/100 Mbps
Protocol :TCP/IP
Input Range:18-36 Vdc Voltage
Power Consumption:24 W Typical/35 W Maximum
Closed StateImpedance:57 KΩ Maximum
Open StateImpedance:187 KΩ Minimum
Internal WettingVoltage:10-15 Vdc
Input Resistance:150 KΩ Typical
Faulted InputTolerance:±40 V

KL3031X1-BA1 RTD Input Module

Vibration Monitors

DC Input :18~36 Vdc, max 7.5 W
Scale Factorrange:5 to 1000 mV/g
Full scale range: 2 to 80 g peak
Current SinkSource:3.3 mA ± 5%
Open CircuitVoltage:-21 to -24 Vdc
ConfigurableBandpass filter:0.2 Hz to 20 kHz
Supply Voltage :-22.8 to –25.2 Vdc
Maximum RatedCurrent:15 mA

330103 3300 XL 8 mm Probe

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Example: 0 6 = 60 mm
Maximum case length: 250 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Rack Interface I/O Module

RIM I/O Module with Modem Interface
Voltage: 24V DC (±10%)
Consumption: ≤15W
Analog Inputs:4–20mA
Digital Inputs:24V DC dry contact
RS-485:Modbus RTU @ 115.2kbps max

TRANSDUCER

0 1 ¼-28 UNF integral stud
0 5Multiple approvals (CSA, ATEX, IECEx,)
Sensitivity 2.5 mV/m/s2 (25 mV/g) ±5%.
AmplitudeLinearity ±1% to 735 m/s2 (75 g) peak.
TransverseSensitivity Less than 5% of axial.
Amplitude ofResonantPeak20 dB maximum

Interconnect Cable

Shielding:100% foil/braid shielding
Impedance: 50Ω ±10%
Max Signal Frequency: Up to 20 kHz
Operating Range: –55°C to +250°C
Flexibility: 500+ flex cycles
Bend Radius: 8x cable diameter

Control Transformer Module

Input Voltage:120V AC ±10%
Output Voltage:24V DC regulated
Power Rating: 100VA (typical)
Efficiency: >85% at full load
Isolation: 1500V AC input-to-output
Thermal Protection: Shutdown at >85°C

Dual Differential Expansion Monitor

Sensor Input:-24V DC @ 4mA
Analog Output:4-20mA
Relay Outputs:3 per channel
Communication:RS-485 Modbus RTU (optional)
Measurement Range:±4mm (±0.16 in) standard
Resolution:0.1% of full scale
Frequency Response:DC to 10Hz (-3dB)
Channels:2 fully independent monitoring channels
