CPU BOARD

Expandable: Up to 16 MB
Serial Ports 2× RS-232/485
Voltage: +5 VDC (±5%)
Clock Speed:25 MHz
Default DRAM:4 MB
NVRAM:128 KB

PCB ASSY MOTION CONTROL

Input Voltage: +24 VDC (±10%)
Power Consumption: 45W
Isolation: 1500 VAC between logic
Protections: Overcurrent
Positioning Resolution:±0.1 µm
Velocity Range:0.001–2.5 m/s
Jerk Control:Programmable S-curve profiles
Synchronization:Multi-axis coordination (±5 ns skew)

EX TOUCH PANEL

Power Supply: 24 VDC
Power Consumption: ≤ 65 W
Size: 12.1" (diagonal, 4:3 aspect ratio)
Resolution: 1024 × 768 (XGA)
Brightness: ≥ 400 cd/m² (adjustable)
Touch Accuracy: ±1 mm (typical)
Touch Points: Single-touch (resistive)

VME Embedded Controller Board

32 MHz MC68040 Microprocessor
with Floating-Point Coprocessor
8 MB DRAM
512 KB SRAM
(4) IndustryPack Ports
Ethernet Transceiver Interface
with 32-Bit Local Bus DMA

PLC MODULE

Processor:32-bit RISC CPU
Memory:2–4 MB RAM
Digital: 16–32 channels
Backplane Interface:Parallel bus
Power Requirements:+5V DC (logic)
Power Consumption:≤ 8W

Exchange Control Board

Supply Voltage: 24 V DC
Power Consumption: ≤ 5 W
Isolation:1.5 kV
Power (green)
Bus activity (yellow)
Fault/error (red)
Per-port status for call stations

Proximity Probe HousingAssemblies

00 Probe not required
00 Without fittings
00 No outer sleeve, retainer, or retainingnut
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
 5/16 to 3/8 inches
02 3/4-14 NPT

Proximity Probe HousingAssemblies

30 3300 XL 8 mm probe,
with connectorprotector, multiple approvals
05 0.5 m (20 in)
15 Minimum length 1.5 in (38 mm)
031=3.1 in (78.74 mm)
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

Controller Board

PDS-BX02E0954
Various I/O
5V DC, 12V DC
communication

Auto Mains (Utility) Failure Control Module

DSE 6120 MKII is an
Auto Mains (Utility) Failure Control Module
developed to provide a wide range of
operating and monitoring features for
single diesel and gas gen-sets
