OEI-BOARD
Power Supply:24V DC (-15%/+20%)
Power Consumption:6W typical
Optical Interfaces:2× 100BASE-FX (1300nm)
Electrical Interface:1× 10/100BASE-TX
Isolation:1500V AC
Data Rate:100Mbps full-duplex
Communication Gateway
MLink Hardware Version 2
Internal: Modbus TCP
Fieldbus: Profibus
Modbus RTU/TCP, PROFINET IO
Analog Input Module
SPARE PART
INPUT MODULE
PMOD ASSEMBLY
ANALOG INPUT
8 CHANNEL
VOLTGAGE W/ TEMPERATURE SENSOR
CONTROL BOARD
Input Voltage:24V DC (±10%)
Power Consumption:≤50W (max)
Relay Outputs:2x SPDT (5A @ 230V AC)
Digital Inputs:2x (24V DC)
Profibus‑DP master module
Protocol: Profibus-DP
Data Transfer Rate: 9.6 kbps to 12 Mbps
Max. Number of Slaves: Up to 125 devices
Cable Length:Up to 1200 m
Connector Type: 9-pin D-sub
Bus Voltage: 5V logic
Combined overcurrentand earth-fault relay
Protection Functions:3-Phase Overcurrent (OC)
Rated Frequency:50/60 Hz
Rated Current (Iₙ):1 A or 5 A
Auxiliary Supply:24/48/110/125 V DC
Rated current:1 A
continuously:4 A
Input impedance:<100 mΩ
Fieldbus H1 Card
FIELDBUS H1
SERIES 2
POWER RATING / 300MA / 12VDC
FIELDBUS POWER / 12MA/PORT / 9-32VDC
-40-70DEGREE C
DELTAV KJ3242X1-BA1 FIELDBUS
12P2471X052
SISNet Terminator Assembly
1-wide SISNet Terminator Assembly
(right-hand extender card and two termination resistors)
KJ4001X1-NA1 Horizontal LocalBus Dual Right Cable Extender
KJ4001X1-NB1 Horizontal LocalBus Dual Left Cable Extender
