DC power driver board

Manufacturer: Siemens AG
Main Power: 24-80V DC
Control Voltage: 24V DC (±10%)
Switching Frequency: 16kHz PWM
Power Dissipation: 35W max
Isolation Voltage: 1500V AC

Flat ribbon cable

flat ribbon cable
BOP20 8-pole
total length approx. 200 mm

Control Unit

SINAMICS S120
Control Unit CU310 DP
with PROFIBUS interface
without CompactFlash card

ACTIVE LINE MODULE

SINAMICS S120 ACTIVE LINE MODULE
INPUT: 3AC 380-480V, 50/60HZ
OUTPUT: DC 600V, 60A, 36KW
FRAME SIZE: BOOKSIZE INTERNAL AIR COOLING
INCL. DRIVE-CLIQ CABLE

THYRISTOR MODULE

Current Rating:1700A
Voltage Rating:1200V
Gate Trigger Voltage:3V typical
Gate Trigger Current:200mA typical
On-State Voltage Drop:1.6V typical at rated current
Critical Rate of Rise:100A/μs
Isolation Voltage:2500V AC

BASIC OPERATOR PANEL

BASIC OPERATOR PANEL
SINAMICS G120
BOP-2
LCD
MONOCHROME
2-LINE DISPLAY
FOR USE WITH G120 INVERTERS
IP55

IGD3/R2 DRIVER BOARD

Control side (logic): +15V / -8V
Auxiliary power: 24V DC
Peak gate current: Up to ±15A
Gate voltage range: +15V
Switching Frequency: Up to 20 kHz
Isolation Voltage: ≥2500V RMS

Control Unit

SIMOTION Drive-based Control Unit D435-2 DP/PN
programmablemotion controller
STANDARD performance
interfaces: 12 DI, 16DI/DO, 6 DRIVE-CLiQ
2 PROFIBUS, 3 PROFINET ports
2 ethernet,2 USB, 1 option slot
incl. dual fan / battery module and battery

Output interfaces Module

OUTPUT CARD
FOR MULTI-PARALLEL CIRCUIT
SIMOVERT MASTERDRIVES
Digital Outputs:24V DC
Analog Outputs:0/4-20mA
Supply Voltage: 24V DC
Relay contacts: 250V AC
Transistor outputs: 24V DC
Voltage: ±10V, 12-bit resolution
Current: 0/4-20mA

Communication interface board

Communication interfaces Module
for multi-parallel Circuit
Data Transfer Rate: Up to 12 Mbps
Interface Type: RS-485
Supply Voltage: 24V DC
